Žemės ūkio purškimo dronas DJI T25 Agras 4600W 35L GPS

Trumpai apie prekę

Prekė: Žemės ūkio purškimo dronas DJI T25 Agras 4600W 35L GPS. Kategorija: Dronai ir multikopteriai.

• Gamintojas: DJI
• Modelis: Profesjonalny Dron DJI T25 Agras Rolniczy Oprysków

Drone DJI Agras T25 - Agricultural Drone

✅ DJI AGRAS T25 redefines standards for compact agricultural drones.

✅ Lightweight and agile, can be easily operated by one person.

✅ It can carry load for spraying weighing up to 20 kg or spreading load weighing up to 25 kg.

✅ DJI AGRAS 25 has a lightweight, folding design.

✅ Optimized for standalone operations, its dimensions after unfolding have been reduced by 21% compared to its predecessor.

✅ It is equipped with a camera with ultraw high resolution and adjustable angle of view, which can record images of crop fields and orchards in real time.

Specification:

✅ Max. diagonal axis spacing: 1925 mm

➡ 2585×2675×780 mm (folded arms and propellers)

✅ 1475×1540×780 mm (folded arms and folded propellers)

➡ 1050×690×820 mm (folded arms and propellers)

✅ Maximum configurable flight radius: 2000 m

➡ Maximum wind resistance: 6 m/s

✅ Stator size: 100×28 mm

➡ KV: 59 rpm/V

✅ Power: 4600 W/engine

➡ Propeller rotation diameter: 1270 mm

✅ Drop size: 50-500 μm

Flight in Surface Route

✅ During flight in this mode you can map about 13 ha in 10 minutes.

➡ During measurement and mapping of the entire area, the drone can automatically identify boundaries of plots and obstacles, as well as quickly plan routes.

Flight in Circular Route

✅ During the flight in this mode you can map about 13 ha in 3 minutes.

➡ This is the mode intended for areas where there are no obstacles in their center.

Large Screen Control Apparatus

✅ Equipped with an 8-core processor, has powerful processing power and smooth operation.

➡ Intelligent route planning reduces the number of unrealized flights with full payload and significantly improves operational efficiency.

✅ A large, 7-inch high-brightness screen increases the field of view and allows you to capture every detail.

➡ The user can switch to manual mode, which facilitates control in complicated scenarios.

Smart Ecosystem for Agriculture

✅ Agras T25 in combination with the Mavic 3M drone enables advanced agricultural missions, such as automatic monitoring of fields, control of territory leveling, identification of seedlings, growth analysis and variable operations on application maps.

➡ Based on the conditions of growth of crops and in combination with maps of agricultural land, agricultural drones can perform precise activities, such as variable fertilization and control of nutrients of crops.

Dual Radar and Vision System

✅ T25 is equipped with active phase radar, which doubles the number of radio frequency transceiver channels, which ensures higher detection accuracy.

➡ In combination with two binocular vision system, the T25 can accurately record terrain details and obstacles. To further enhance operational security,

The ✅ T25 is also equipped with a rear phase radar, which provides 360-degree omnidirectional detection and intelligent manoeuvres.

➡ During work in orchards with a high slope of the terrain, T25 can perform fully automated operations, following the changing shape of the territory.

Magnetic Vortex Pump

✅ Magnetic vortex pump provides a double flow rate of pump of up to 24 liters per minute, which is a 100% increase compared to the previous generation.

➡ Thanks to this, meets the requirements of operations on agricultural land, in horticulture and in high temperature conditions.

Double Spray Nozzle

✅ Double nozzles for spraying enable adjustment of the size of fog drops in the range from 50 to 500 microns, which allows adaptation to various chemical substances.

Improved Electromagnetic Valve

➡ The new electromagnetic valves provide precise start and stop, eliminating the risk of leakage.

Contents of the Set:

✅ Agras T25 drone

➡ Toolbox

✅ Apparatus

➡ Harness

✅ USB-C cable

DRONE

➡ Weight

✅ 24.4 kg (without battery)

✅ 32 kg (with battery)

➡ Maximum take-off weight

✅ Spraying: 52 kg (at sea level)

✅ Spreading: 58 kg (at sea level)

➡ Max. wheelbase diagonally

✅ 1925 mm

➡ Dimensions

✅ 2585×2675×780 mm (folded arms and propellers)

✅ 1475×1540×780 mm (folded arms and folded propellers)

✅ 1050×690×820 mm (folded arms and propellers)

➡ Hover accuracy range (with strong GNSS signal)

✅ D-RTK included: Horizontal: ±10 cm, Vertical: ±10 cm

✅ D-RTK off: Horizontal: ±60 cm, Vertical: ±30 cm (radar module on: ±10 cm)

➡ RTK/GNSS operating frequency

✅ RTK: GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galileo E1/E5b, QZSS L1/L2

✅ GNSS: GPS L1, GLONASS F1, BeiDou B1I, Galileo E1, QZSS L1

➡ Maximum customizable flight radius

✅ 2000 m

➡ Maximum wind resistance

✅ 6 m/s

DRIVE SYSTEM – ENGINES

➡ Stator size

✅ 100×28 mm

➡ KV

✅ 59 rpm/V

➡ Power

✅ 4600 W/engine

DRIVE SYSTEM – PROPELLERS

➡ Material

✅ Carbon Fiber Nylon Filament

➡ Dimension

✅ 50 inches

➡ Propeller rotation diameter

✅ 1270 mm

➡ Quantity

✅ 4 pieces

SPRAYING SYSTEM – TANK

➡ Material

✅ Plastic (HDPE)

➡ Capacity

✅ 20 L

➡ Operational load

✅ 20 kg

➡ Quantity

✅ 1

SPRAYING SYSTEM – NOZZLES

➡ Model

✅ LX8060SZ

➡ Quantity

✅ 2

➡ Nozzle distance

✅ 1368 mm (rear nozzles)

➡ Drop size

✅ 50 – 500 μm

➡ Effective spray width

✅ 4 to 7 m (at a height of 3 m above crops)

✅ SPRAYING SYSTEM – PUMPS

➡ Type

✅ Rotary pump (magnetic drive)

➡ Quantity

✅ 2

➡ Single pump flow rate

✅ 0–12 l/min

➡ Maximum flow rate

✅ 16 l/min (2 nozzles)

✅ 24 l/min (4 nozzles)

DISSEMINATION SYSTEM

➡ Compatible material diameter

✅ Dry granules 0,5 to 5 mm

➡ Tank volume

✅ 35 l

➡ Load capacity of the tank

✅ 25 kg

➡ Spread width

✅ Depends on material diameter, disc speed, outlet size and flight altitude

✅ Recommended spread range: 5 to 8 m

RADAR SYSTEM

➡ Model

✅ RD241608RF (front), RD241608RB (rear)

➡ Land tracking

✅ Slope slope: up to 20°

✅ Height detection range: 1 to 50 m

✅ Stability range: 1,5 – 30 m

➡ Avoiding obstacles

✅ Detection range (multidirectional): 1 to 50 m

✅ FOV (front): horizontal 360°, vertical ±45°, up ±45° (cone)

✅ FOV (rear): vertical 360°, horizontal ±45°

✅ Operating conditions: min. 1,5 m above the obstacle, horizontal speed ≤10 m/s, vertical ≤3 m/s

✅ Safe limit distance: 2,5 m

✅ Detection direction: 360° multidirectional detection

BINOCULAR VISION SYSTEM

➡ Measurement range

✅ 0,5 – 29 m

➡ Effective detection speed

✅ ≤10 m/s

➡ Field of view

✅ Horizontal: 90°, Vertical: 106°

➡ Working environment

✅ Adequate light and visible surroundings

REMOTE CONTROL APPARATUS

➡ Model

✅ RM700B

➡ Frequency of work

✅ 2,4000 – 2,4835 GHz, 5,725 – 5,850 GHz

➡ Maximum transmission distance

✅ 7 km (FCC), 5 km (SRRC), 4 km (MIC/CE); unobstructed, uninterrupted, at an altitude of 2,5 m

➡ Wi-Fi protocol

✅ Wi-Fi 6

➡ Wi-Fi frequency

✅ 2,4000 – 2,4835 GHz

✅ 5,150 – 5,250 GHz

✅ 5,725 – 5,850 GHz

➡ Bluetooth protocol

✅Bluetooth 5.1

➡ Bluetooth operating frequency

✅ 2,4000 – 2,4835 GHz

➡ GNSS

✅ GPS + Galileo + BeiDou

➡ Screen

✅ Touch LCD Screen 7,02", 1920×1200 px, brightness 1200 cd/m²

➡ Operating temperature

✅ -20° to 50°C

➡ Storage temperature

✅ < 1 month: -30° to 45°C

✅ 1 to 3 months: -30° to 35°C

✅ 6 to 12 months: -30° to 30°C

➡ Charging temperature

✅ 5° to 40°C

➡ Working time

✅ 3 h 18 min (built-in battery)

✅ 2 h 42 min (external battery)

➡ Charging type

✅ Recommended USB-C charger 65W, 20V (e.g. DJI 65 W)

➡ Charging time

✅ 2 hours for built-in and external battery (with apparatus off)

✅ C800 SMART CHARGER

➡ Model

✅ CHX101-7000

➡ Dimensions

✅ 400 × 266 × 120 mm

➡ Weight

✅ approx. 11,4 kg

➡ Input/Output

✅ Input voltage: 100 – 240 VAC

✅ Output voltage: 59,92 V

✅ Output current: max. 100 A

➡ Charging time

✅ 9 to 12 minutes (full battery charge)

➡ Protection function

✅ Overheating, overvoltage, too low voltage, short circuit, fan stop, etc.

➡ Operating temperature

✅ -20° to 45° C

➡ Charging safety

✅ Connector protection

➡ Input/Output (Variations)

✅ 220–240 VAC, 50/60 Hz, 24 A MAX

✅ 100-120 VAC, 50/60 Hz, 16 A MAX

✅ Output: 59,92 VDC MAX, 175 A / 60 A / 9000 W / 3000 W

➡ Protective functions

✅ Before overvoltage, overcharging, low voltage and overheating

➡ Security

✅ AC cable, power cord, charging connectors

RELAY

➡ Model

✅ RL01-65

➡ Dimensions

✅ 120 × 110 × 100 mm

➡ Weight

✅ ≤575 g

➡ Input voltage

✅ 9 V 3 A / 12 V 2.5 A / 15 V 2 A

➡ Energy consumption

✅ 9 IN (SRRC), 12 IN (FCC)

➡ Capacity

✅ 6500mAh

➡ Working time

✅ 4 hours

➡ Frequency of work

✅ 2.4000 – 2.4835 GHz, 5.725 – 5.850 GHz

➡ Maximum transmission distance

✅ 5 km (SRRC), 4 km (MIC/KCC/CE), 7 km (FCC)

➡ Charging time

✅ 2 hours 20 minutes (standard charger DJI)

➡ Degree of protection IP

✅ IP55

✅ DB800 DRONE SMART BATTERY

➡ Model

✅ Intelligent aviation battery DB800

➡ Weight

✅ approx. 6.6 kg

➡ Capacity

✅ 15000mAh

➡ Nominal voltage

✅ 52,22 V
