Vaizdo įrašymo įrenginys DVR-208Q-M1 HiLook, skirtas 5MP kameroms

Trumpai apie prekę

Prekė: Vaizdo įrašymo įrenginys DVR-208Q-M1 HiLook, skirtas 5MP kameroms. Kategorija: Garso įrašymo įrenginiai.

• Gamintojas: HiLook
• Modelis: DVR-208Q-M1

Analog recorder supporting cameras with resolutions up to 5 Mpx. In addition, if you already have older AHD or TVI cameras, they will also be supported .

All recordings are available in the Playback section, where using the intuitive menu, you will be able to play a given video with accuracy to the day, hour and second.

Download the Hik-Connect app on your smartphone to get access to the DVR and all cameras connected to it. No matter where you are, all you need is an Internet connection.

• Number of channels (4in1): 8
• Number of IP channels: 4
• Resolution max. camera: 5Mpx for TVI/CVI/AHD
• Decoding: 3K lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps
• Video compression: H265+/ H265/ H264+/ H.264
• Dual stream: Yes
• Smart functions: Motion detection 2.0 on all 4in1 channels
• Ethernet interface: 1x RJ45 10M/100M
• Video outputs: 1xHDMI, 1xVGA
• Remote operation: Hik-Connect/HiLook Vision, IVMS-4200, Web Interface
• Network protocols: DNS, TC/IP, DHCP, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
• Max. number of HDDs: 1
• Max. Capacity: 10TB
• USB connectors: 2x USB 2.0
• Power Supply: 12VDC
• Weight: < 1kg

HiLook monitoring systems can be controlled, configured and operated using the intuitive mobile application HiLook App for smartphones and tablets and the iVMS-4200 program for PCs. Thanks to this, the user has constant control and supervision over the monitored space from anywhere on earth with access to the network. The application and program allow you to:

• live image preview
• remote playback of recordings
• creating motion detection scenarios and rules
• control of rotary cameras
• receiving notifications about events within the system

The application uses the P2P cloud, so that the system does not have to have redirected ports on the router.

The advantage of the recorder is the proprietary technology Motion Detection 2.0, allowing filtering false motion detection alarms and classifying objects on video recordings (human / vehicle).

The recorder supports an efficient image compression standard, designated H.265. This standard is a direct successor to the popular H.264 technology and allows for almost double the bandwidth load. This translates into significant space saving on the hard disk and extending the archiving time of recordings on the disk.

Recorder specification:

• People/Vehicle Analysis: Deep learning-based motion detection 2.0 is enabled by default for all analog channels. It can classify people and vehicles and significantly reduce false alarms caused by objects like leaves and lights. A quick search by object or event type is supported.
• Video compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Coding resolution: When 1080p Lite mode is not enabled: 3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF
• Recording speed Main stream:
• When 1080p Lite mode is not enabled: For access to 3K stream: 3K lite@12fps; 4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps 5 MP Stream Access:5 MP lite@12fps; 4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps For 4 MP stream access: 4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) 1080p stream access:1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N). When 1080p Lite mode is enabled: 3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) Substream: WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N)
• Video Bitrate: 32 Kbps - 6 Mbps
• Dual-stream: Yes
• Type of streaming Video: Video + Audio
• Audio compression: G.711u
• Audio Bitrate: 64 Kbps
• Video inputs: IP 2-channel (up to 10-channel) Enabled Enhanced IP mode: 4-channel (up to 12-channel), each up to 4 Mbps
• Resolution up to 6 MP Support for H.265+/H.265/H.264+/H.264 IP cameras
• Video inputs: BNC 8-channel BNC interface (1,0 Vp-p, 75 Ω), supporting coaxial connection
• HDTVI: 3K@20 fps, 5 MP@20 fps, 4 MP@30 fps, 4 MP@25 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps
• AHD: 5 MP@20 fps,4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
• HDCVI: 5 MP@20 fps,4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
• CVBS: Yes
• HDMI output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• VGA outputs: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• Video output modes: HDMI/VGA, HDMI + VGA
• Audio input: 1-channel, RCA (2,0 Vp-p, 1 KΩ) 8-channel via coaxial cable
• Audio output: 1ch, RCA (Linear, 1 KΩ)
• Double-sided audio: 1-channel, RCA (2,0 Vp-p, 1 KΩ) (using the first audio input)
• Synchronous display: 8-channels
• Link bandwidth: 96 Mbps
• Remote connections: 64
• Network protocols: TCP/IP, PPPoE, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
• Network interface: 1, self-adjusting RJ45 10M/100M Ethernet interface
• Interface: SATA x1
• Hard drive: Support drives up to 10TB (not included)
• USB interface: 2x USB 2.0
• Power Supply: 12VDC, 1.5A
• Power consumption: < 12W (Without HDD)
• Ambient conditions: -10 °C to +55 °C, Air humidity 10% - 90%
• Dimensions: 265 × 225 × 48 mm
• Weight: < 1kg (Without HDD)
