Universalus nuotolinio valdymo pultas vartams, 280–868 MHz, kintamas kodas

Trumpai apie prekę

Prekė: Universalus nuotolinio valdymo pultas vartams, 280–868 MHz, kintamas kodas. Kategorija: Nuotolinio valdymo pultai.

• Gamintojas: RETOO
• Modelis: E069

UNIVERSAL RADIO TRANSMITTER | FREQUENCY 280-868 MHZ | CLONING FUNCTIONS

Looking for a simple and convenient way to remotely control your alarm, gate, or blinds without having to buy multiple remotes, our SELF-COPYING REMOTE IS THE PERFECT SOLUTION

✅ RELIABLE AND CONVENIENT SOLUTION

Easy-to-use self-copy remote control, which copies the signal of most remote controls (for gates, controllers, alarms, cars).

The remote control is made of durable plastic, which is resistant to mechanical damage and weather conditions.

The self-copying remote control has a special electronic system that allows you to easily and quickly program it to work with any device operating at frequencies in the range of 280 - 868 MHz.

✅ SPECIFICATION

➔ Frequency: 280-868 MHz

➔ Type: 4-channel

➔ Battery: included

➔ Range: approx. 50 m

➔ Dimensions: approx. 65x40x15 mm

➔ Includes a hanger, which you can conveniently attach the remote control, e.g. to your keys or pocket

✅ UNIVERSAL

It is a replacement for most remote controls for opening garage doors or doors and other devices operating on frequencies in the range from 280 to 868 MHZ.

✅ ADVANTAGES:

➔ Easy to use remote control, small, convenient and durable

• The remote control can be easily and quickly programmed to any device, just press a few buttons. You don't need any additional tools or cables.

➔ Pilot buttons resistant to abrasion

• The remote control is made of solid plastic, which is resistant to mechanical damage and weather conditions. The self-copying pilot will not be destroyed even when falling or flooding.

➔ No sharp edges

➔ Product of the highest quality - made of solid raw materials

➔ Requires preparation - is ready to use immediately after quick and easy copying of the function (instructions below)

➔ 4in1 remote control - you can copy functions from up to four different remote controls operating at different frequencies!

➔ The product does not emit unpleasant odors unlike other substitutes

➔ Long-lasting battery life - optimized energy-saving mechanisms minimize the need for frequent replacement

✅ EXCELLENT QUALITY

The materials used in the production of this remote control are of the highest quality, which translates into long-lasting and trouble-free use of the remote control. The keys are abrasion resistant.

✅ SAFETY

Equipped with unique security codes that eliminate the risk of unauthorized access to your garage door. Resistant to radio interference, which ensures stable and reliable operation.

✅ EASY TO USE

A very easy way to program. The 4 buttons make it easy to manage all the functions of your device.

We always check that everything works perfectly!

• Holding the top right button pressed, press the left button 4 times, the red LED should start flashing (every 2-3 seconds ).
• Then press the button on the second remote control (from which the code is to be copied) several times until the LED on our remote starts blinking.
• Now select which button to save the copied signal to.
• Repeat the action for the next buttons you want to copy
• This everything!!! The code is copied!!! Just remember that both remotes must be very close to each other and the batteries must be working.

⚠ Some gate motors need to copy the signal from the remote control and additional pairing with the gate drive for proper operation. To do this, you need to follow the instructions for pairing the pilots of the manufacturer, in most cases such instructions are available on the network. ⚠

✅ PRODUCT COMPATIBILITY:

This remote control has a self-copy function, that is, you can copy functions from any remote control to gate, garage, car and other objects operating in the frequency from 280 to 868 MHz.

Examples of brands of remote controls that can be copied using this device:

ACM (AMC) TX2, TX2 COLOR, TX4

ADYX TE4433H BLUE, 433-HG BRAVO

AERF COMPACT, HY-DOM, MERCURI B, MERCURI C, SABUTON, MARS, SATURN, ST3/N, TERRA, TMP-1,TMP-2, UNITECH

ALLMATIC (AMC) BROWN, BROWN RED, BRO.OVER, PASS, MINIFASS

APERIO GO, GO PRO, GO MINI

APERTO (SOMMER) TX02-434-2, TX02-868-2 BLUE, 4025 TX02-868-2, 4022 TX02-434-2, 4020, TX03-434, TX-03-868-4, 4013, TX03-434 -4

APRIMATIC (AMC) TR2/TR4, TM4, TXM

ATA PTX4 BLUEM PTX4 PINK

AVIDSEN 104251, 104250, 104250 OLD, 104250 RED, 104257, 104350, 654250

BALLAN FM400, FM400E, FM404B, 4013

MARANTEC D101, D12, DIGITAL302, DIGITAL304

BENINCA (AMC) TO.GO.WV, TWV, ROLLKEY, APPLE, LOT WCV, CUPIDO, TO.GO.QV, IO, LOT2WCV, LOT1W, LOT2W, LOT4W, LOT1WM, LOT2WM, T2W, T4W

BESIDE BEZAP, HIT

MONSEIGNEUR ARC

BFT (AMC) MITTO, MITTO M (MITTO 2M / MITTO4M), MITTO RCB (MITTO RCB02 / MITTO RCB04), MITTOA (MITTO 2A / MITTO 4A), MITTO B,TRC (TRC2/TRC4), GHIBLI, MURALS, KLEIO, TEO1, TEO2, TEO4, RB4

CAME T431, T434, TOP432A, TOP434a, TOP432, TAM432SA, TOP432NA

CARDIN (AMC) TRQ S449 (TRQ449100 / TRQ449200 / TRQ449300 / TRQ449400), TRQ S449 GREEN (PRECODE), TXQ S449 (TXQ449200 / TXQ449300 / TXQ449400), TXQ S449 GREEN, TRQ S486 (TRQ48) 6200 / TRQ486400), TXQ S486 (TXQ486200 / TXQ486200 / TXQ486400), S437 TX, XRADO, S449, S476TX2， S476TX, S486

CASALI JA33 AMIGO, GENIUS / CASALI A252RC OPENOUT TMQ

CASIT ERTS92B, ERTS92T, ERTS476D, ERTS20DQ, ERTS476D, ERTS476Q

CELISA S10 1, S10 2

CENTURION CLASSIC, SMART

CHAMBERLIN / LIFTMASTER / MOTORLIFT 953ESTD, 371LM (315MHZ), 81LM, 971LM (390MHZ), 84330E, 94334CE, 94333E / 94334E / 94335E, 9747E, 1A5477, 1A6487, 132B2372 ， 94330EML / 94333EML / 94335EML, 84330EML / 84333EML / 84335EML, 8747EML

CLEMSA MUTANCODE, T, T-8, E-CODE N, MASTERCODE MV

CPS TCP3, CPS1, CPS2, CPS4

DASPI (AMC) HAPPY2, POPS 2, ZERO RC (ZERO 2RC, 4RC)

DEA TR MIO, 133 1, 433 2, GENIE, PUNTO S2, PUNTO 278， GOLDR, GENIE R 273, GENIE R-GT2N

DELMA MIXARD 433 1, MIXARD 433 2, KING 433 2

DICKERT MAHS433 01, MAHS433 04

DITEC (AMC) GOL, GOL4C, BIXLS2，BIXLP2, BIXAG4，BIXLG

DOORMATIC SAW

DOITRAND MPSTF2E, JAUNE

DOORHAN TRANSMITTER 4

DUCATI TSAW1, TSAW2, TSAW3, 124, TE2

ECOSTAR RSE, RSC, RSZ

ELBE 501, 502, 504, 502A, 504A

ERREKA IRIS, ROLLER 2, ROLLER 433, ROLLER 868, SOL433，SOL868, VEGA 433, VEGA 868

ELCA IRIS, ASTER, ASTER 1000, ASTER 1001

FAAC (AMC) , T 868SHL, T 433SHL, XT433RC, TE433HG

FADINI (AMC) FADINI JUBI, JUBI SMALL, ASTRO 43 SMALL, 433 M2 ASTRO 433-2, ASTRO 433-4, JUBI2/JUBI4

FERPORT TAC1, TAC2, TAC4, TAC 1K, TAC 2K, TAC 4K, TAC2KR

GIBIDI GIBIDI OPEN TMB, OPEN OUT, AUO1590, AU1600, DOMI- NO AU1680 WOOD, GIBIDI AU1610, GIBIDI AU1680, AU1810, AUO3000, AUO3000 DOMINO, DTC 4334, DTS4334-AUO400

GULLIVER MDW

GENIUS (AMC) AMIGO, AMIGOLD, KILO, BRAVO, ECHO

GENIE (AMC) GITR-3, GIT, GICT390, GIFT390-1, G3T-BX, G1T-BX, GM3T, GICTD, GIFTD

HORMANN HSM2, HSM4

JAY UBEI X 1SL1, UBET 21, UBET 41, UBET 61

KBLUE ETH-TEL01

KEY 900TXB-42R, SUB44, TXB-44R, TXG-44R

KINGGATES STYLO, CLIPPER

KLING KUA, KUAE, KUA S

LABEL SPYCO, RJW4E

LEB TMW

LIFE FIDO2 / FIDO4 / VIP2 / VIP4 / VIP2R / VIP4R / STAR2 / STAR4 / BRAVO2 / BRAVO4

LINK LR2035

LINEAR MCT-11, ACT-22, ACT-21, STING RAY ACT-31, STING RAY ACT-34B

MA TX1, TX2, TX3

MHOUSE (AMC) GTX4, GTX4C, TX4

MOOVO (AMC) MT4G

MERLIN/PROLIFT M230T (PROLIFT), M430R (PROLIFT)

MERLIN 2.0 E945M, E943M, E940M

NICE (AMC) SMILO, FLO-R, VERY-VR, ERA-FLOR, ONE, ERA ONE, INTI, ERGO, ON2/4/9E, ON 868 2/4, ON 24E 868 FM, PLANO

NORTON NEO, TXCD, GO NORTON, GO MINI NORTON

NOVOTECNICA (AMC) BLXL2

NOVOFERM NOVOTRON 502-504-512MIX43-2, MTX40-2, MCHS43-2,MHS43(2- 4), MNHS433(2-4),MCHS, MINI-NOVOTRON504, MICRO-NOVOTRON 502

NOLOGO ECO DIP

O&O (AMC) T.BOM, TX, TWIN, TX2/TX4

O&G OG62, OG64

PECCININ TX MENBRANA

PORTAMATIC MPH01, MPH02

PRASTEL TC2E(4E), SLIM, BFOT, MPSTP2E, MPSTF2, MPSTF4, MPSTF2RE, MPSTF4RE, MPSTP2E, MPSTP2EBL UE

PROEM ER4C4ACS

PROGET ETY_433N2, ETY_433N4

PROTECO TX433, EUROMATIC

PUJOL MARTE, P215, TWIN, VARIO, VARIO MARS, VARIOOCEAN, NEO

QUASAR 433

RIB LITHILO

ROPER NEO, GO ROPER, GO MINI ROPER

SABUTOM BROOVER, BROSTAR

SEA SMART DIP

SECULUX NEO

SEAV BE HAPPY RS (BE-HAPPY-RS1, BE-HAPPY-RS2, BE-HAPPY-RS3), BE-SMART RSX, BE-HAPPY RH1, BE-HAPPY RH2, BE-HAPPY RH3

SILVELOX MHZ 2007, QUARZ SAW

SICE 4790207

SIMINOR CVXNL, MITTO, SIM433

SEUCURVERA SV R2C, SV R4C, SV R6C

SERAI OG/52, OG54, OG82, OG84, OG/28, OG48, OG62, OG64

SOMFY LEIS, K-EASY, K-EASY NEW, K-EASY OLD, MITTO, KEY GO RTS, TELIS, KEYTIS RTS

SOMMER SOMMER 4026 TX03-868-2, SOMMER 4020 TX03-868-4, SOMMER 4031, SOMMER 4025, SOMMER 4011, SOMMER 4035, APERTO 4025

STAGNOLI KALLISTO, VENUS AV223

TAU (AMC) 250K-SLIMRP, 250K-SLIMR, 250T-4RP

TELCOMA FM402, FM402E, FM400E, FM400

TORLIFT TORMIT4

VDS (AMC) TRQ P, ECO-R

VARWFORD EA433 4K, SMART2, SMART3

V2 (AMC) V2 PHOX 2, V2 PHOX 4, V2 PHOENIX 2, V2 PHOENIX 4, V2 TXC, V2 TRC, V2 TSC4, V2 HAND

One button remembers only one function!

.

Method 1:

• 1. Bring both remotes very close together.
• 2. Enter our remote control in copy mode - Holding the top right button pressed, press the left button 4 times, the red LED should start flashing (every 2-3 seconds ). Let go of the buttons. The remote is ready to receive the signal.
• 3. On the original remote control, hold down the button from which you want to copy the function. The LED on our replacement will start flashing. Let go of the button. Now select the button on our remote control on which you want to save the function and press it on approx. 2-3 p. The code has been saved.

Repeat steps 2-3 for the remaining buttons. You can also, at any time, recode already encoded buttons. No need to delete the whole thing. This is everything. Just remember that both remotes must be very close to each other and the batteries must be working.

.

Method 2:

• 1. Bring both remotes very close together.
• 2. Enter our remote control in copy mode - Holding the top right button pressed, press the left button 4 times, the red LED should start flashing (every 2-3 seconds ). Let go of the buttons. The remote is ready to receive the signal.
• 3. On the original remote control, hold down the button from which you want to copy the do not let go function. On our replacement, hold the corresponding button. Keep the remotes this way for approx. 5 seconds. The LED will flash and go out, which means that the function copying process has been done correctly.

Repeat steps 2-3 for the remaining buttons. Just remember that both remotes must be very close to each other and the batteries must be working.

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	RETOO
Parametry	Frequency	433 MHz
Parametry	Compatible systems	Na liście 280-868Mhz
Parametry	Manufacturer code	E069
Parametry	Product weight with unit packaging	0.15 kg
Parametry	Kind	remote control
Parametry	Certificates of conformity	CE
