Universalus nuotolinio valdymo pultas vartams, 240–930 MHz, kopijuojantis kodus

Trumpai apie prekę

Prekė: Universalus nuotolinio valdymo pultas vartams, 240–930 MHz, kopijuojantis kodus. Kategorija: Nuotolinio valdymo pultai.

• Gamintojas: no brand
• Modelis: PILOT DO BRAMY SAMOKOPIUJACY 240-930MHz

Universal 4-channel self-copying remote control with fixed and variable code 240-930MHz

This remote control is ideal for people who have one working remote control and want to make a second spare.

It is perfect for garage doors, alarms, roller shutters and cars whose remote controls are fixed-code and operate at a frequency of 280-868MHz.

The remote copy signals in devices such as:

⭐Garage door

⭐Gates to the property

⭐Smart Home Products

⭐Home use products

⭐The remote control is suitable for copying the signal not only of entrance gates, but also of other devices

⭐Homemade, such as e.g. automatic blinds or remote lighting switches.

The signal duplicator from the remote controls is made of solid materials, thanks to which will serve you for a long time of use. The remote control has a housing with ABS chrome inserts, making it resistant to wear and tear.

What characterizes our product?

High quality and low price distinguish us from the competition. You can be sure that you will receive the goods in full value.

• Colour: black
• Material: ABS
• Dimensions: 6,5 x 3,8 x 1 cm
• Frequency: 240-930MHz

• Battery: 6V
• Type of code: fixed and variable
• Channels to program: 4 pcs
• Intensity: < 12V
• Range: up to 100m
• 3 functions: copy, delete and restore function

✔ Copying remote controls with fixed, variable code

✔ High compatibility with remote controls from other manufacturers - copying over 300 different brands of remote controls

✔ Operating frequency range: 240-930MHz

✔ Ability to program each button for a different remote control

✔ Housing made of splash-proof material

✔ Automatic scanning of the original remote control and adjusting to the detected frequency

✔ Four channels, to copy a total of five codes

✔ Long working range - 100M

The remote control may not work in some cooperative systems where automation is used by a larger number of users. In some cases, the administrator may block the control panel.

Some gate motors need to copy the signal from the remote control and additional pairing with the gate drive to work properly. To do this, you need to follow the instructions for pairing the pilots of the manufacturer, in most cases such instructions are available on the network.

1. CLEANING THE PILOT'S MEMORY

• A) Press button 1 and 2 at the same time until the LED flashes 3 times.
• B) Release button 2 (still holding button 1), then slowly press button 2 – three times. The LED will flash quickly.
• C) Release both buttons – the remote is ready to copy.

2. COPYING PILOTS WITH FIXED CODE

• Press and hold the 1 button of the original remote control, then press and hold the 1 button of the copy remote until the LED in the self-copying remote will indicate the success of the process. Repeat the above process in the same way for the other buttons. The remote is ready to use after the copy process.

3. COPYING PILOTS WITH VARIABLE CODE

• Press and hold the 1 button of the original remote control, then press and hold the 1 button of the copy remote until the LED in the self-copying remote will indicate the success of the process. When you duplicate button 1, the rest of the buttons will generate automatically. Follow the instructions of the original receiver to connect the new self-copy remote.

4. PROGRAMMING STAGES FOR BFT MITTO2 & MITTO4 PILOTS (OLD VERSIONS)

• 1. Cleaning memory
• 2. Press and hold the button 1 of the self-copying remote until the LED flashes twice and goes out, press the button 2 once while holding the button 1 all the time, the remote is in copy mode.
• 3. Press and hold button 1 and 2 BFT simultaneously (code sending mode), the LED in the self-copying remote will flash twice and go out, release the BFT buttons and then press the selected BFT button, the LED in the self-copying remote will flash three times and light up permanently, this means completing the BFT copying.
• NOTES: Keep the button 1 of the self-copying remote pressed from stage 2 to stage 3. Transfer code between the self-copying remote and BFT: Press button 1 and 4 at the same time.

5. RESUMING THE CODE

• If you deleted the code accidentally, you can return to it by pressing and holding the buttons 3 and 4 on the remotes at the same time, after 10 seconds the LED flashes twice and turns off – this means that the code of the self-copying remote has been restored.

UNIVERSAL REMOTE CONTROL FOR SELF-COPYING GATES 240-930MHz

List of gate manufacturers and types of pilots with whom the pilot cooperates:

• ACM: TX2, TX2 COLOR, TX4
• ADYX : TE4433H BLUE, 433-HG BRAVO
• AERF: COMPACT, HY-DOM, MERCURI B, MERCURI C, SABUTON, MARS, SATURN, ST3/N, TERRA, TMP-1, TMP-2, UNITECH
• ALLMATIC: BROWN, BROWN RED, BRO.OVER, PASS, MINIPASS, TECH3
• APERIO: GO, GO PRO, GO MINI
• APERTO (Sommer): 4020-TX03-434, TX02-434-2, TX02-868-2
• APRIMATIC: TR, TM4, TXM
• ATA: PTX4 BLU, PTX4 PINK
• AVIDSEN: 104251, 104250, 104250 OLD, 104250 RED, 104257, 104350, 654250
• BALLAN: FM400, FM400E
• BENINCA: TO.GO.WV, TWV, ROLLKEY, APPLE, LOT WCV, CUPIDO, TO.GO.QV,
• BENINCA: IO
• BFT: MITTO, MITTO M, MITTO RCB, MITTO A, TRC, GHIBLI, MURALS, KLEIO
• CARDIN: TRQ S449, XRADO TRQ S449 GREEN (PRECODE),TXQ S449, TXQ S449 GREEN, TRQ S486, TXQ S486, S437 TX,
• CASALI: JA33 AMIGO, GENIUS/CASALI A252RC
• CAME: T432, T434, TOP432, TOP432A, TOP434A, TOP432, TOP432NA, TOP434NA, TOP432M, TOP434M, TAM432SA, TOP432SA, TOP432NA, TWIN2, TWIN4, TOP432S
• CHAMBERLAIN / LIFT MASTER MOTOR LIFT: 953ESTD, 371 LM, 971LM, 84330E, 94334CE,94333E/94334E/94335E, 9747E,1A5639-7, 1A5477, 1A6487, 132B2372,94330EML/9333EML/ 94335EML,84330EML/84333EML/84335EML,8747EML
• CLEMSA: MUTANCODE, T, T-8, E-CODE N, MASTERCODE MV
• DASPI: ZERO RC
• DEA SYSTEM: PUNTO 278, GOLDR, GENIE R 273, GENIE R-GT2N, MIO TR, GT2M, TRN
• DITEC: BIXLP, GOL4, BIXLG
• DOORHAN: TRANSMITTER 4
• DOORMATIC: MILENY, MILENY-EVO
• ECOSTAR: RSC, RSE, RSZERREKAIRIS, ROLLER 2, ROLLER 433, ROLLER 868, SOL433, SOL868, VEGA 433, VEGA 868
• ERREKA: IRIS, ROLLER 2, ROLLER 433, ROLLER 868, SOL433, SOL868, VEGA 433, VEGA 868
• FAAC: TML 433SLH, DL 868 SLH,XT 868 SLH, XT 433 SLH, T 868 SLH, T 433 SLH, XT 868 SLH BLACK, XT 433 SLH BLACK,
• FADINI: JUBI-SMALL, JUBI 433
• GENES: GITR-3, GIT, GICT390, GIFT390-1, G3T-BX, G1T-BX, GM3T, GICTD, GIFTD
• GENIUS: AMIGOLD, AMIGO, KILO, BRAVO, ECHO
• GIBIDI / JCM: Au1600, AU1600 WOOD, AU1680, AU1680 WOOD, DOMINO
• JCM: GO, GO PORTIS, GO NORTON, NEO, TWIN
• KBLUE: ETH-TEL01
• KEY: 900TXB-42R, TXB 44R, SUB 44R
• KING GATES: CLIPPER, STYLO
• BLADE: KUA, KUA E, KUA S
• LABEL: SPYCO
• LIFE: FIDO
• LINEAR: MCT-11, ACT-21, ACT-22, STING RAY ACT-31, STING RAY ACT- MERLIN 2.0E945M, E943M, E940M
• MERLIN / PROLIFT: C945, C940, C943, M842, M844
• MHOUSE: TX3, TX4, GTX4
• MOOVO: MT4G
• NICE: SMILO, FLOR-S, VERY-VR, FLOR-S ERA
• NICE: ONE (ON), ON ERA, INTI, ERGO, PLANO, ONE (ON FM)
• NORTON: NEO, TXCD, GO NORTON, GO MINI NORTON
• NOVOFERM: MCHS, MICRO-NOVOTRON 502, MINI-NOVOTRON 504, MICRO-NOVOTRON 502, MICRO-NOVOTRON 504, MICRO-NOVOTRON 31, MICRO-NOVOTRON 51, MINI-NOVOTRON 30, MINI-NOVOTRON 50, MNHS,
• O&O: TX, T_COM R4-2, T_COM R8-2, TWIN, TX (NEO)
• PECCININ: TX MENBRANA
• PRASTEL: MTE, MPSTLE, MPSTP2E, TCE,BFOR,TRQ-P, SLIM-E
• RIB: LITHIO
• ROPER: NEO, GO ROPER, GO MINI ROPER
• SABUTOM: BROOVER, BROSTAR
• SEA: HEAD, SMART DUAL ROLL, SMART-3 ROLLING CODE, COCCINELLA
• SEAV: BE HAPPY RS
• SECULUX: NEO
• SILVELOX: Mhz 2007, QUARZ SAW
• SIMINOR: CVXNL, MITTO, SIM433
• SOMFY: K-EASY, K-EASY NEW, K-EASY OLD, MITTO, KEY GO RTS, TELIS RTS, KEYTIS RTS, KEYTIS RTS NS, ALARM
• SOMMER: 4010, 4011, 4014 TX03-434-2, 4013 TX03-434-4, 4020 TX03-868-4, 4026 TX03-868-2, 4022 TX02-434-2, 4025 TX02-868-2, 4031 TX08 -868-4
• STAGNOLI: KALLISTO, VENUS AV223
• TAU: 250K-SLIMRP, 250K-SLIMR,250T-4RP
• TELCOM: FM400E, FM400
• TOR LIFT: TORMIT4
• V2: TSC, TXC, TRC, HANDY, PHOENIX, PHOX 433
• VDS: ECO-R, TRQ P
• Wiśniowski: PULSAR RTS
