Skardos perfokatorius 34,0 mm 109340 RUKO

Trumpai apie prekę

Prekė: Skardos perfokatorius 34,0 mm 109340 RUKO. Kategorija: Įrankių rinkiniai.

• Gamintojas: Ruko
• Modelis: 109340

Technical data:

• Ø hole (mm): 34,0mm
• screw size (mm): M12x1,5
• screw length: 55mm

Description of the item:

• 3 cutting tips
• for sheets with a thickness of 3,0mm
• for fast, clean perforation of steel sheets and plastics without burrs

Execution:

• Special tool steel
• Operation with a flat wrench or hydraulic tools.
• Delivery with die, stamp and pressure screw

Application:

• For punching holes in various materials such as stainless steel sheets, copper sheets, brass, aluminum, iron and plastic
• It is particularly suitable for work in hard-to-reach places such as control cabinets, dashboards, etc.

Hint:

• The pressure screw and die should be lubricated before starting work. The diameter of the drilled hole should be about 1 mm larger than the pressure screw.

Screw punches:

In one operation, in just a few moves, without much effort, a finished hole can be made without the need for finishing.

Better contact of the tool with the surface thanks to entering the material at three points simultaneously, which reduces deformation of the cut elements. This also prevents premature failure of the screw.

The bearing makes maintenance easier and faster. Energy expenditure is reduced by approx. 67%.

Before using the hole punch, the lead screw should be lubricated with drilling spray or paste (e.g. RUKO ).

The metric lead screws in RUKO punches are of the highest quality and are therefore designed for extreme loads. In case of damage, they can always be replaced temporarily with standard fine-pitch screws available on the market.

They can be used with both screw wrenches and hand and foot hydraulic presses.

To extend the life of the tool - recommended use of lubricants.

paste, liquid or spray for cutting and threading.

General description of sheet metal die:

Sheet metal die is used for fast and precise cutting of specific shapes, holes and forms from sheet metal (steel, aluminum, stainless steel, copper) in the punching process, mainly in serial production. It works by pressing a specially profiled stamp to the material on the die with great force, which cuts off the desired element, ensuring high repeatability and material savings.

Benefits:

• Speed: Significantly speeds up the production process compared to manual cutting.
• Precision: Provides highly accurate dimensions and shapes.
• Automation: Allows easy automation of manufacturing processes.
• Material saving: Optimal use of raw material.

RUKO OHG was founded in 1974 and specializes in the production of high-quality tools for drilling, dredging and cutting metal.

Today, RUKO GmbH Präzisionswerkzeuge is one of the world’s leading manufacturers of precision metal cutting tools.

RUKO OHG was founded in 1974 and specializes in the production of high-quality tools for drilling, dredging and cutting metal.

Today, RUKO GmbH Präzisionswerkzeuge is one of the world’s leading manufacturers of precision metal cutting tools.

RUKO is a renowned German company, founded in 1974, specializing in the production of high-quality, precision cutting tools for metalworking, such as drill bits (including gradual, rolled, ground), taps, dredges and foraminifera, known for innovation and excellent value for money for professionals, based in Holzgerlingen (near Stuttgart).
