Pusiau automatinis suvirinimo aparatas Paton StandardMIG 160A MIG MAG MMA TIG LIFT

Trumpai apie prekę

Prekė: Pusiau automatinis suvirinimo aparatas Paton StandardMIG 160A MIG MAG MMA TIG LIFT. Kategorija: Pusiau automatiniai suvirinimo aparatai.

• Gamintojas: Paton
• Modelis: StandardMIG-160
• Ilgis: 435 mm
• Plotis: 250 mm
• Aukštis: 298 mm

✔ Paton brand equipment is the No. 1 for customers who are not professionals, but want to weld like the best welders.

✔ The Paton plant has its own production of welding machines, which, unlike most welding equipment on the Polish market, does not take place in China, but in its own factory, which is located in Ukraine in Kiev.

✔ 5 years of DOOR-to-DOOR service period, also for companies.

✔ You don’t have to be a professional to weld like a professional!

Are you still using your welding machine and worried about its durability? With PATON you do not have to worry about anything - whether you buy a device for yourself or for the needs of the company, PATON gives you 5 years of free DOOR-to-DOOR service period.

What does this mean?

After buying a welding machine, you can be sure for 60 months that no matter what happens to the device - we will pick up the welding machine from you and repair it within 5 years from the date of purchase.

The Paton StandardMIG-160 device was made on the basis of the latest inverter technology, from components made in Europe.

The device uses state-of-the-art protection such as protection against excessive voltage, excessive current, overheating of the device, etc.

The welding machine can be successfully used for welding carbon steel, stainless, alloy, iron, black steel and aluminium using the following methods:

• MIG/MAG in protective gas shielding
• MIG/MAG without gas shield (self-shielded wire)
• MMA wrapped electrode
• TIG DC

• highest reliability confirmed by the longest DOOR-to-DOOR service period
• easy setting of the welding machine
• digital setting method
• ability to remember 16 memory programs
• application from amateur to professional
• possibility of separating the wire feeder from the source in MMA and TIG welding methods
• welding without gas with self-shielding wire
• equipment of the highest quality - handles included are German manufacturer ABICOR BINZEL

Professional Wire Feeder

A characteristic feature of Paton feeders is a very powerful and high-quality additionally sealed metal wire feeding mechanism, as well as an integrated EURO connector, which has become a standard around the world.

Few novice welders are aware of the fact that the right power and speed of wire feeding is one of the factors determining the quality of our welding in the MIG MAG method.

With the highest quality Paton feeder, the wire will be fed perfectly, exactly as you set it.

Features that will make you do everything

Paton MIGOMATES have the possibility of soldering, thanks to the function of changing the inductance in three degrees.

Inductance control allows for accurate adjustment of parameters to the thickness of the welded material.

PULSE FUNCTION

✔ PULS in TIG method – gives the welder full control of the heat introduced into the material – a great function for welding stainless steel and acid-resistant steel,

✔ PULS in MMA method – thanks to this it is easier to transfer the material from the electrode to the welding lake, better quality of the welded joint,

✔ PULS in the MIG/MAG method – easier detachment of metal droplets from the end of the electrode wire, the ability to adjust pulsating current parameters. MIG welding with pulsation is useful for welding stainless steels, acid-resistant steels and aluminum alloys. In addition, pulse welding provides better parameters when soldering CuSi3

❓ FAQ - Frequently Asked Questions

❓ What welding methods does this migomat support?

The PATON StandardMIG-160 welding machine is a semi-automatic welding machine that supports several methods:

• MIG/MAG – welding with gas shielded wire (steel, stainless steel, aluminium),
• MIG/MAG without gas (FCAW) – self-shielding wire welding, ideal for field work,
• MMA – classic welding with a wrapped electrode,
• TIG Lift – TIG welding with ignition by rubbing (after connecting the TIG handle).

It is a universal device for workshop, garage, construction and assembly work.

❓ What is the maximum welding current and what materials can be welded?

The StandardMIG-160 offers welding currents up to 160 A and smooth adjustment in the range of 8 –160 A.

Allows welding:

• structural steel up to 5 mm,
• stainless steel up to 4 mm,
• aluminium up to approx. 3 mm (after using the appropriate wire and gas).

The welder has a 45% duty cycle at 160 A, which ensures the possibility of long-term operation without overheating. It is an ideal choice for workshop work, repairs, steel and bodywork structures. At lower currents (e.g. 120 – 130 A) welding machine can work practically continuously.

❓ What wires can be used in this migraine?

The welder supports wires:

• steel, stainless and aluminium,
• with a diameter of 0,6 to 1,0 mm,
• for 5 kg spools (⌀ 200 mm)

If necessary, self-shielding wire (FCAW) can be used without the use of gas – just change the polarity in the device.

❓ Does the welding machine have a pulse function?

Yes — PATON StandardMIG-160 has a pulse welding function.

Pulse mode works in all methods:

• MIG/MAG,
• MMA,
• TIG.

The pulse function allows for cleaner, more precise and aesthetic welds, especially when welding thin materials, aluminum and stainless steel. In addition, it reduces the amount of chipping and reduces the heating of the material, which protects the elements from deformation.

❓ What is the service and warranty?

PATON welding machines are manufactured in Europe and not in China, which guarantees high quality, durability and reliability. The StandardMIG model is covered by 5-year service care, implemented in Poland – in an authorized service in Rzeszów. This is a guarantee of fast and professional technical support.

❓ What power will the unit power the migomat? How long can the extension cord be used?

The StandardMIG-160 welder can be powered from a generator set, provided that:

• the unit has voltage stabilization (AVR),
• its continuous power is a minimum of 4 to 4,5 kW,
• The recommended power is 5 kW with AVR if you plan to weld at full power (160 A).

The 3,5-4 kW unit with AVR is sufficient for typical workshop work with currents up to 120-140 A.

The welder can work with longer extension cords:

• up to 95 meters with a cross-section of 2,5 mm²,
• up to 230 meters with a cross-section of 6 mm².

Detailed technical data:

• Power supply: 50/60 Hz, 230 V
• Nominal mains current required: 19-21 A
• Nominal welding current: 160 A
• Maximum welding current: 200 A
• Work Cycle: 45% at 160А, 100% at 107A
• Power supply voltage change intervals: 160 – 260 V
• Welding current adjustment intervals: 8 – 160A
• Welding voltage adjustment intervals: 12 - 24V
• Diameter of wrapped electrode: 1,6 – 4,0 mm
• Diameter of solid wire: 0,6 – 1,0 mm
• Number of pressure rollers: 2
• Hot-Start function: Adjustable
• Arc-Force function: Adjustable
• Anti-Stick function: Automatic
• Idle voltage reduction system: On/Off
• Idle current voltage: 12 / 75 V
• Arc current voltage: 110 V
• Nominal power consumption: 5,5 – 6,1 kVA
• Maximum power consumption: 8,0 kVA
• Energy efficiencý: 90%
• Cooling: Automatic
• Working temperature range: –25 ... +45 ºС
• Compliant standards: EN 60204 – 1:2006 EN 60974 – 1:2012 EN 60974 – 10:2014
• Dimensions (length, width, height): 420 х 245 х 298
• Weight: 11 kg
• Degree of protection: IP33

The purchased set includes:

• PATON™ StandardMIG-160 migomat welder
• Electrode holder 3m
• Mass holder 3m
• Wire feeder rollers 1x (0,6 – 0,8), 1x (1,0 – 1,2) V
• Quick coupler for gas
• Cardboard packaging
• User manual
