Trumpai apie prekę
Prekė: Pusiau automatinis suvirinimo aparatas Magnum MIG 200A 200/2 KN IGBT MMA 230V/400V. Kategorija: Pusiau automatiniai suvirinimo aparatai.
- Gamintojas: Magnum
- Modelis: MIG 200/2
- Ilgis: 655 mm
- Plotis: 330 mm
- Aukštis: 460 mm
MIG, MAG, FLUX, MMA | Power supply: 230V / 400V | Maximum welding current: 200A
The MAGNUM MIG 200/2 MMA KN is a semi-automatic welding machine made in inverter technology, it can be powered from both 230V and 400V networks.
The device allows arc welding with hot melt wire MIG/MAG, self-shielded wire FCAW (change the polarity in the welding machine: minus (-) on the welding torch, plus (+) on the mass), and electrode wrapped MMA. It is designed for all kinds of welding work in locksmith workshops, repair workshops.
The power source was built on IGBT transistors providing a minimum of electromagnetic interference, enabling increased efficiency and reliability of the power source, lower energy consumption and rapid adjustment of the current to changes in parameters during welding.
The device has smooth adjustments of welding parameters, is equipped with an overload thermal protection system, preventing excessive overheating.
The professional wire feeder with "euro connector" socket used in the device allows you to connect different types of welding brackets.
The welding machine has the ability to adjust the inductance (arch hardness) - this function optimizes the characteristics of the MIG/MAG arc depending on the thickness of the welded elements, useful when welding thin elements (prevents them from burning out) and soldering galvanized elements.
Features and Benefits:
- switchable power supply 230/400V
- regulation of inductance
- welding without gas
- MMA welding
- smooth adjustment of parameters
- strong solid chassis
- digital display
TECHNICAL DATA:
- Power supply: 230 V / 50 Hz
- Efficiency: 60%
- Welding Current: 200 A
- Idle Voltage: 60 V
- Wire spool: max. 5 kg
- Wire diameter: 0.6 mm - 1.0 mm
- Power protection 230 [V]: 20 A (C)
- Power protection 400 [V]: 16 A (C)
- Cooling device: AIR
- Handle Cooling: GAS
- Weight: 14 kg
INCLUDED IN THE SET:
- Device Magnum MIG 200/2 KN
- Welding torch MIG EURO MB 15 3m
- MMA electrode holder
- Mass cable
- adapter 230/400V
- User manual
Specifications
| Group | Name | Value |
|---|---|---|
| Parametry | Condition | new |
| Parametry | Invoice | With VAT invoice |
| Parametry | Brand | Magnum |
| Parametry | Power consumption | 8 kVA |
| Parametry | Duty cycle time | 60% |
| Parametry | Maximum electrode diameter | 4 mm |
| Parametry | Wire diameter (mm) | 0,8-1,0 |
| Parametry | Device weight | 14 kg |
| Parametry | Welding range | 30–200 A |
| Parametry | Height | 460 mm |
| Parametry | Length | 655 mm |
| Parametry | Width | 330 mm |
| Parametry | Length of ground cable | 200 cm |
| Parametry | Welding cable length | 300 cm |
| Parametry | Product weight with unit packaging | 20 kg |
| Parametry | Manufacturer code | U MI 200/2 KN #ZESTAW1AK |
| Parametry | EAN (GTIN) | 5907195563622 |
| Parametry | Packaging status | original |
| Parametry | Model | MIG 200/2 |
| Parametry | Welding methods | MIG/MAG,MMA |
| Parametry | Supply voltage (V) | 230,400 |
| Parametry | Additional features | transport wheels,infinitely adjustable welding current,EURO handle,LCD display |
