Priekinis žibintas RAVEMEN FR1100SE, 270° spindulio kampas, Powerbank funkcija, IPX4

Trumpai apie prekę

Prekė: Priekinis žibintas RAVEMEN FR1100SE, 270° spindulio kampas, Powerbank funkcija, IPX4. Kategorija: Apšvietimas.

• Gamintojas: Ravemen
• Modelis: FR1100SE
• Spalva: black

➡ RAVEMEN FR1100 bicycle headlight – Improves visibility in all driving situations! Bright LEDs, combining road lighting and daytime warning, ensure driving safety during the day, at dusk, at night, during rain, fog and snow all year round

✅ Target group: Cyclists in need of road lighting + day warning, preferring the assembly used by the bicycle computer and saving installation space

✅ Tailored weather conditions: All day and all conditions — day, dusk, night, rain, fog, snow

✅ Tailored routes: Full coverage of urban, rural and suburban roads

⚠ Note: Not all bike computers can be mounted according to this light, check supported brands of bike computers by scrolling down

⚠ Note: The light requires mounting with bike computer holder, please make sure you have the right mount bracket before purchasing

➡ Product parameters

Product name: RAVEMEN FR1100

Light Source Type: LED

Maximum brightness: 1100 lm

Battery capacity: 2500 mAh

Charging time: 2.2 h

Charging Interface: USB‑C

Waterproof rating: IPX4

Product Dimensions: 82 mm * 61 mm * 25.4 mm

Product weight: 119 g

Product Certificates: CE, RoHS

Special Features: Bicycle Computer Mount, 270° Viewing Angle, Automatic On and Off, Power Bank Function

Mode / Brightness in lm / Working time

• High brightness: 1100 lm | 1.8 h

• Average brightness: 500 lm | 3.5 h

• Low brightness: 250 lm | 7.5 h

• Warning flickering: 500 lm | 45 h

• Fast flickering: 300 lm | 21 h

• Slow flickering: 150 lm | 46 h

➡ One light for two purposes: lighting + warning

Basic safety values of FR1100:

• Night lighting and day warning, one light meets your driving needs throughout the day

• Brightness of 1100 lm suitable for different driving situations and routes: city, village, suburbs, mountains

• High brightness fast flicker mode effectively improves visibility in sun/cloud/rain/fog/snow

➡ Construction with the assembly of a bicycle computer

Top and bottom light holder are Garmin standard, support direct mounting used bicycle computers with Garmin handle, neat and space saving

✅ The following brands of bicycle computers support direct light mounting:

Garmin, iGPSPORT, Magene, CYCPLUS, Coospo, XOSS, NAVIHOOD, other bike computers with Garmin mount

✅ The following brands of bicycle computers support light mounting after replacing the upper and lower light holders:

Wahoo: Compatible handle included (included in product content)

Briton: Compatible handle included (included in product content)

❌ The following brands of bicycle computers do NOT support mounting used with this light:

SIGMA, Cateye, VDO, other bike computers with non-Garmin standard handle

➡ Light supports suspended installation

Suspended mounting method 1: AGM04 suspended mount included, requires suspended mounting with GoPro interface at the bottom of the mount (light angle adjustable)

Suspended mounting method 2: To buy AGM02 suspended bracket, requires mounting with screw holes at the bottom of the handle (light angle not adjustable)

➡ Viewing angle 270°

Wide angle lens design, better visibility from the sides

Eliminates the dead side zones of traditional lights, greatly improves the chance of being noticed from the sides

➡ Power bank function

The light can charge your phone or bike computer in an emergency

⚠ Note: Only used for temporary emergency charging of phone and bicycle computer, there is no possibility to power professional power bank

➡ IPX4 waterproof

Suitable for driving in the rain, does not require protection when used in the rain

⚠ Note: The charging port is not waterproof, be sure to close the charging port cap before using in the rain

1 * FR1100

1 * AGM04 Suspended Holder

1 * Compatible Wahoo Bike Computer Holder

1 * Compatible Bryton Bike Computer Holder

1 * USB-C to USB-C charging cable

1 * USB-C to Micro USB Charging Cable

1 * Anti-fall cord

1 * User Manual

➡️ Frequently Asked Questions

1. How do I know if my bike is compatible?

Answer: Scroll up to view the bicycle computer mounting instructions.

2. How to choose between FR160, FR300, FR500, and FR1100?

— FR160 and FR300 are daytime running lights only, with no illumination function. They do not light up the road ahead while riding but offer excellent visibility due to their COB LED technology. Their battery life is similar, making them sufficient as warning lights.

• FR160: Maximum brightness 160 lumens, weight 55g. Lightweight and portable, ideal for users prioritizing minimal weight.

• FR300: Maximum brightness 300 lumens, weight 75g. Higher brightness, features auto on/off and power bank function. Suitable for users who value brightness and extra features.

— FR500 and FR1100 are dual-function lights (illumination + warning). They provide both a warning signal and light up the road ahead. The main difference is brightness.

• FR500: Maximum brightness 500 lumens, weight 100g. Suitable for speeds under 30km/h or users with moderate brightness needs.

• FR1100: Maximum brightness 1100 lumens, weight 119g. Suitable for speeds over 30km/h or users requiring higher brightness.

— Final selection guide:

• If you only need a warning light and prioritize lightweight design with sufficient performance → Choose FR160.

• If you only need a warning light, want higher brightness, and desire auto on/off and power bank features → Choose FR300.

• If you need to illuminate the road at night and also need a warning light for low-speed riding → Choose FR500.

• If you need to illuminate the road at night and provide a warning light for high-speed riding with high brightness requirements → Choose FR1100.

➡ Product Description

Product name: RAVEMEN FR1100

Light Source Type: LED

Maximum brightness: 1100 lm

Battery capacity: 2500 mAh

Charging time: 2.2 h

Charging Interface: USB‑C

Waterproof rating: IPX4

Product Dimensions: 82 mm * 61 mm * 25.4 mm

Product weight: 119 g

Product Certificates: CE, RoHS

Special Features: Bicycle Computer Mount, 270° Viewing Angle, Automatic On and Off, Power Bank Function

Mode / Brightness in lm / Working time

• High brightness: 1100 lm | 1.8 h

• Average brightness: 500 lm | 3.5 h

• Low brightness: 250 lm | 7.5 h

• Warning flickering: 500 lm | 45 h

• Fast flickering: 300 lm | 21 h

• Slow flickering: 150 lm | 46 h

Note: All parameters have been tested under standard laboratory conditions, actual data may vary depending on the usage environment

【Quick start】

1、Press and hold the power button for 1.5s to turn the light on/off; single press changes the light modes

2、Automatic on and off mode

On: When the light is off, press and hold the power button until the light starts flashing quickly, then release. In this mode, the light turns off automatically after 2 minutes of stillness and turns on quickly when vibration is detected

Off: When the light is off, press and hold the power button until the light starts flashing slowly, then release

3、Memory function:

Light automatically remembers mode when off, no need to adjust again when turned on again

4、Battery Level Indicator:

Green power button light is constantly on: 40%~100%

Red power button light continuously lights up: 5%~40%

Red power button light flashes: ＜ 5%

When the light is off, a single press of the power button activates the battery level indicator for 2 seconds

5、USB-C charging

Standard charging time: 2.2 h

Maximum input: 5 V, DC / 1 A

Built-in overcharge protection

Note: Some chargers may not charge the light due to different charging protocols, just replace the charger or charging cable

6、Charging indicator:

Red light flashes: Charging in progress

Green light is constantly shining: Charging completed

7、Description of waterproof:

The light has IPX4 water resistance, when using in the rain, be sure to close the charging port stopper to prevent water ingress. Do not use the light when charging in the rain. Do not use the light for a long time in the rain.

【Usage Notes】

1、Before first use, it is recommended to fully charge the light

2、Do not disassemble or modify the light body yourself, otherwise you will lose your warranty rights

3、When using in the rain, be sure to close the charging port stopper, only protect against splashing water, not from immersion

4、Built-in rechargeable battery: Prohibited heating and combustion to avoid safety risk

5、Do not allow children to contact freely, dismantle the light and built-in battery to avoid the risk of ingestion or electric shock

6、When charging, place the light in a ventilated, cool place, away from high-temperature, flammable and explosive objects to prevent overheating during charging
