Automobilio keltuvas vienos kolonos TW 125 M-G Ultra Grey Line

Trumpai apie prekę

Prekė: Automobilio keltuvas vienos kolonos TW 125 M-G Ultra Grey Line. Kategorija: Kolonų keltuvai.

• Gamintojas: Twin Busch
• Modelis: TW125M-230-G

✅ Reputable brand

Twin Busch® Germany

Single-column lifter TW 125M-G Grey Line in the New Version, is ideal for painting, bodywork, tire service and brakes. Mobile lift for professional car workshop, who care about affordable equipment while maintaining the highest quality.

The TW125M-G is one of the lowest single-column lifts on the market, offering ideal conditions for low clearance vehicles thanks to its frame height of only 85 mm and minimum ground clearance of 98 mm.

With a maximum lifting height of up to 1930 mm, this lift offers an efficient yet extremely compact solution for a wide range of workshop applications.

Single column mobile lift Twin Busch 2,5t

✅ Compare the benefits of the product!

• Mobile single-column lift with reliable hydraulic drive
• Best suited for painting, bodywork, tire and brake service
• Not requiring large usable area
• Leveraged unlocking of security ratchets
• Mechanical safety hooks
• Telescopic support arms with height adjustment support
• Aluminum motor and 24 V control
• High quality construction of a support column from a special rolled profile
• CE Certificate, Declaration of Conformity

Technical data 🛠

• Lifting capacity 2500 kg
• Maximum lifting height 1830 – 1930 mm
• Minimum clearance height 98 mm
• Lifting / lowering time 30 mm/ 35mm / sec.
• Engine power 2.20 KW
• Voltage 230V
• IP 64 protection
• Operating temperature -5° / +40°
• Application of inside/outside (conditioned)
• Oil tank 10l (HLP32 oil not supplied)
• Dimensions 2470 x 2030 x 2600
• Weight 720 kg

✔ Support arm locking mechanism

The automatic locking mechanism of the support arm ensures maximum safety.

✔ Mobile

Ideal for tight spaces, it can be easily moved like a pallet truck and can be flexibly used on any hard enough surface.

✔ Control unit

The convenient control unit (protection class IP 54, control voltage 24 V) is equipped with a limit switch limiting the lifting height and an automatic safety device ensuring safe operation.

✔ Electric motor

Efficient hydraulic unit with high quality aluminum pump, safety valve, powerful electric motor and manual drain valve.

✔ Support arms

The lift is equipped with flat and telescopic support arms.

✔ Frame height

The lift has an exceptionally flat frame with a height of only 85 mm. It is ideal for low body cars such as: Porsche.

✔ Two-stage turntables

The lift has two-stage, adjustable turntables with a small rotation height of only 98 mm.

✔ Forklift function

Optimal for tight spaces, easy to carry, like a pallet truck, can be used on any stable ground.

✔ Thin frame

The ultra-thin frame height is only 85 mm width and 98 mm height. It is ideal for low body cars such as: Porsche.

The protective cover of the pillar protects the hydraulic cylinder from sparks during welding and bending. High security and attractive appearance.

High quality powder coating of complete structure, screws also galvanized.

Recommended by the manufacturer of the substrates on which the lift should be placed are:

- Paving cube

- Concrete

- Asphalt

• Production according to ISO 9001 standards
• Current Certificate CE
• Declaration of conformity EC
• Instruction in Polish, German and English
• Satisfaction of customers
• German quality
