Trumpai apie prekę
Prekė: Aukštų dažnių kolonėlė Tonsil GDN 20/40/14 8 Ohm juoda. Kategorija: Žemųjų dažnių garsiakalbiai.
- Gamintojas: Tonsil
- Modelis: GDN 20/40/14 8 Ohm
GDN 20/40/14 8 Ohms
GDN 20/40/14 8 Ohm woofer with cellulosic membrane.
- Impedance - 8 [Ohm]
- Frequency Response - 45 - 3500 [Hz]
- Nominal power (housing 36 dm^3, 100 hrs. continuous operation) - 40 [W]
- Maximum power - 60 [W]
- Efficiency - 90 [dB]
- Resonant frequency FS - 45 [Hz]
- Coil resistance - 6,8 [Ohm]
- Coil height - 9,6 [mm]
- Coil core diameter - 25 [mm]
- Slot height - 8 [mm]
- Slot width - 1,675 [mm]
- Outer diameter of magnet - 90 [mm]
- Inner diameter of magnet - 45 [mm]
- Magnet height - 13 [mm]
- Magnet weight - 0,31 [kg]
- Induction in slot B - 0,65 [T]
- Energy in the gap - 188,4 [mJ]
- Magnet material - ferrite
- Membrane material - cellulose
- Suspension material - foam
- Coil body material - nomex
- Coil material - copper
- Basket material - steel sheet
- Equivalent volume VAS - 0,056 [m^3]
- Mechanical goodness QMS - 6,32
- Electrical goodness QES - 0,9
- Total goodness QTS - 0.79
- Total mobile mass MMS - 0.015 [kg]
- Mechanical Suspension Vulnerability CMS - 84x10^-5 [m/N]
- BI strength index - 6,1 [Tm]
- Active surface of SD membrane - 0.021 [m^2]
- Speaker weight - 1,2 [kg]
1611
Specifications
| Group | Name | Value |
|---|---|---|
| Parametry | Condition | new |
| Parametry | Invoice | With VAT invoice |
| Parametry | Brand | Tonsil |
| Parametry | EAN (GTIN) | 5904209571192 |
| Parametry | Model | GDN 20/40/14 8 Ohm |
| Parametry | Manufacturer code | GDN 20/40/14 8 Ohm |
