Vaizdo registratorius D-TEG SMARTY BX1500 Plus 120

Trumpai apie prekę

Prekė: Vaizdo registratorius D-TEG SMARTY BX1500 Plus 120. Kategorija: Vaizdo registratoriai.

• Gamintojas: no brand
• Modelis: BX1500

Vehicle route recording "black box" - GPS module, video recorder, overload sensor and wide-angle camera in one compact device. Great device for all types of vehicles! Designed to provide visual evidence of an event or record of a route. The D-TEG recorder can be treated as a “Black Box” of the vehicle in which the most important data is stored. By using an SD card instead of a traditional hard drive, the device provides high reliability and is also perfect for monitoring the fleet without incurring additional costs associated with GSM telephony. All this can be achieved with the help of a mobile Smarty recorder. The recorder has a built-in high-resolution HD camera recording images in 1280x960 (15fps) or 640x480 (up to 30fps). The minimum illumination for the camera is 1.0 lux, which gives good image quality even in a lot of darkness, although in reality the passing lights or street lamps provide sufficient visibility for the camera. In addition, the software allows you to manually adjust the contrast and brightness of the image. The small size of the device allows for simple and non-invasive installation on the front or rear window, as well as on the dashboard or rear shelf. Installing the recorder in front of the interior mirror makes it virtually invisible from inside and outside the vehicle and ensures optimal visibility for the camera. The built-in 3-axis G overload sensor not only activates the event record on the card, but also shows data indicating sudden accelerations, braking, sharp turns, etc. As a result, this allows for an overall assessment of the driver’s driving style.

Registration takes place in continuous mode or is activated by an overload sensor according to the defined sensitivity. If the device operates in event mode, the recorder buffers the so-called pre-alarm, from which 20 seconds (10s before and 10s after), 30 seconds (15s, 15s), 40 seconds (20s, 20s) are recorded when the sensor is activated.

The device also has a built-in small battery, which in case of power loss allows you to save from the buffer. The set includes a 4GB SD card, it is possible to use SDHC cards with a capacity of up to 32GB, which provides constant video recording up to 148 hours (1fps 640x480), up to 9 hours (15fps 1280x960). This is determined by the defined resolution and frame rate. If the card is full depending on the configuration, the device can start overwriting the oldest data. D-TEG analysis software allows for easy and quick configuration of the device and provides options such as:

• GPS logs (up to 31 days of recording)
• Playback of recordings
• Exporting recordings
• Generating reports
• Checking GPS speed and position
• Viewing the route on Google Maps and Google Earth

The software is available in Polish.

The set includes:

• BX1500+ recorder
• 4GB SD card with software
• set of 4 cable clasps
• power cable - 12 to 24 V
• video cable (microjack-chinch) (possibility of connecting the recorder to the monitor)
• instruction manual

Technical specification:

• TV System: NTSC
• Power Consumption: 3,6W
• Camera Options: Memory Card, Video Output
• Minimum lighting: 1 LUX
• Operating Temperature: -10 ~ +60
• Dimensions: 80mm x 50Ø
• Power Supply: DC 12~24V
• Viewing angle: 120° (horizontal 88°, vertical 65°)
• Resolution: 1280 x 960 / 640 x 480 (HQ / LQ)
• Transducer: CMOS
• Number of lines: 480 TVL
