USB šakotuvas HMC-5H, 5 jungtys, 5 Gbps, 3x USB

Trumpai apie prekę

Prekė: USB šakotuvas HMC-5H, 5 jungtys, 5 Gbps, 3x USB. Kategorija: Dokavimo stotelės.

• Gamintojas: Axagon
• Modelis: HMC-5H

The 5Gbps AXAGON HMC-5H 5in1 multiport USB-C hub extends the laptop's capabilities by five ports. You can easily and quickly connect a monitor and, three USB devices to your computer at the same time using a double-sided USB-C connector. You can also power your laptop with Power Delivery technology. With a 1m cable, you can conveniently arrange the devices you need to work according to your needs. The port replicator thus performs the function of a universal 5in1 docking station for modern laptops.

The USB hub offers three USB 5 Gbps outputs with a standard USB-A connector. The hub can also handle the constant connection of multiple external drives at the same time. Thanks to the high-speed USB 3.2 Gen 1 interface, the transfer is supported at speeds up to 5Gb/s. The hub can also charge mobile phones and tablets connected to the USB hub ports with current up to 1.5A/5V. You can easily charge m.in from the hub. Android smartphone, Apple iPhone, Apple iPad, etc.

The USB-C connector is reserved exclusively for power supply and simultaneous charging of laptops using Power Delivery 3.0 technology with power up to 100W. Connect the appropriate USB-C Power Delivery charger to the hub and connect the hub to a laptop that supports Power Delivery. This will also release one USB-C port on your laptop.

HDMI output delivers high picture quality up to Ultra HD 4K/30Hz resolution and supports multi-channel audio transmission.

For video outputs to work properly, the laptop must be equipped with a USB-C port with DisplayPort alternative mode (DP Alt Mode) or Thunderbolt 3, Thunderbolt 4 and later

The elegant aluminum housing provides not only mechanical strength, but also passive cooling. Thanks to Plug And Play and Hot Plug functions, connecting devices to the hub is very simple, without complicated installation and you can also connect and disconnect peripherals while the computer is running. The hub is not afraid of connections with phones with a USB-C connector. You can connect a pendrive, keyboard, mouse, monitor, TV or projector to your phone.

Input (connection to laptop):

USB 5Gbps (USB 3.2 Gen 1 / USB 3.0), USB-C female connector.

Compatible with USB 3.2 Gen 2, USB4 and Thunderbolt 3/4.

Input (power supply):

USB Power Delivery 3.0 100W port (power only), USB-C female connector.

Powering the notebook from the AC adapter via a USB-C hub.

PD power must be supported by both laptop (phone) and mains charger.

USB Output:

3x USB 5Gbps port, USB-A female connector.

The USB-C hub allows you to connect multiple external drives simultaneously.

Charge mobile devices (including iPad) up to 1.5A from USB-A hub ports.

Video output:

1x HDMI port, HDMI A female connector.

4K 4096 x 2160 resolution with refresh rates up to 30Hz.

2K/WQHD 2560 x 1440 resolution at frequencies up to 60Hz.

FHD 1920 x 1080 resolution at up to 120Hz.

Support for the above max. supported resolutions and frequencies requires a connection to a computer with DisplayPort version 1.4.

To ensure proper operation of the video output, the hub must be connected to a USB-C port with DisplayPort alternative mode (DP Alt mode) version 1.4 or later or to a USB-C port with Thunderbolt 3/4 support. We also require a suitable operating system. The video output function will not be available when these requirements are not met.

Hot Plug (Hot-Plug-Detect) support.

TMDS (Transition Minimized Differential Signalling) support.

Full support for HDCP 1.4 and 2.3 (High-bandwidth Digital Content Protection).

Support 2-channel audio sampling rate up to 48 kHz and audio up to 24-bit - depending on source and end device, i.e. laptop/phone and TV/monitor/AV receiver.

Further properties:

Possibility to connect the device behind the run thanks to Hot Plug support.

Total Plug and Play support.

Support for standby mode.

Power supply via bus- USB bus power or from PD charger.

The durable aluminum housing is designed to better cool the hub.

Quality shielded cable guarantees high communication speed and minimal unwanted interference.

121 x 35 x 10 mm.

Weight 75 g.

Length of USB-C cable male 100 cm.

Supported operating systems:

Microsoft Windows 10/11 and later, macOS, Linux, Android and Chrome OS.

Compatibility depends on the operating system and device manufacturer support.

DisplayPort Alternate Mode (DP Alt Mode) is only supported on updated operating systems and also depends on the support from the device manufacturer (notebook, phone).

Graphics card drivers can also affect the proper functioning of the product. We recommend that you download the latest version of the drivers.

• I/O Ports: 1 x HDMI Type A, 3 x USB 3.0 Type A, 1 x USB Power Delivery
• Docking: No
• Included Accessories: USB-C hub with integrated 100 cm cable, Multilingual manual CZ / DE / DK / ENG / ESP / FIN / FR / GR / HR / HU / IT / NL / PL / PT / RO / RU / SK / SWE / BG / CN / TR / ARA, Packaged in a cardboard box with hanging hole.
• Color: Gray
• Dimensions: 121 x 35 x 10 mm
• Weight: 75 g
