Tinklo jungiklis ULTIPOWER 8 prievadų, Gigabit, PoE, 802.3af

Trumpai apie prekę

Prekė: Tinklo jungiklis ULTIPOWER 8 prievadų, Gigabit, PoE, 802.3af. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: no brand
• Modelis: 0800AF

Product Code: 0800AF

The ULTIPOWER 0800af PoE Switch is a desktop device that provides seamless network transmission. It allows you to establish connections at speeds of 10, 100 or 1000Mbps. It has 8 RJ45 ports supporting automatic negotiation of connection speeds. All ports support Power over Ethernet (PoE). The switch automatically detects PD devices operating in the IEEE 802.3af standard and supplies them with power. This allows you to extend the range of the network in places where there is no access to sockets or power lines, and where there is a need to place access points, IP cameras, IP phones, etc.

Distinguishing features:

• 8 ports 10/100/1000 Mbps
• All PoE ports, data transfer and power supply of the device using one cable,
• No assembly or configuration is required,
• PoE power up to 15,4W for each PoE port
• Support for PoE-powered devices operating according to IEEE802.3af standard
• Support auto-learning and auto-aging MAC addresses (1K size table)
• LEDs informing about the status and speed of the connection, its activity and power supply

802.3af a 802.3at

The most popular PoE 802.3af power standard is used e.g. in IP cameras. It enables power supply of devices with voltage from 44 to 57 [V] at a maximum power of 15,4 [W]. The 802.3at standard enables power supply to devices with an input voltage of 50 - 57 [V] and a power not exceeding 25,5 [W]. Examples of devices powered by the 802.3at standard are: printers, rotating IP cameras and switches.

Technical parameters:

• Name ULTIPOWER 0800af
• IEEE802.3, 802.3u, 802.3ab, 802.3x CSMA/CD, TCP/IP standards and protocols
• 10BASE-T redirect speed: 14880pps/port 100BASE-TX: 148800pps/port
• Store-and-Forward transmission method
• Ports 8 RJ45 10/100/1000Mbps ports (automatic connection speed negotiation, Auto MDI/MDIX automatic patching) including all PoE ports
• 10Base-T network cabling: UTP cable cat. 3, 4 or 5 (up to 100m) STP cable EIA/TIA-568 100Ω (up to 100m) 100Base-Tx: UTP cable cat. 5, or 5e (up to 100m) STP cable EIA/TIA-568 100Ω (up to 100m) 1000Base-Tx: UTP cable cat. 5e (up to 100m)
• LED Power, Link/Act, 100M, PoE Status Indicators
• CE Certificates
• Dimensions [mm] 285x190x45
• Working environment Permissible operating temperature: 0...40℃ Permissible storage temperature: -40...70℃ Permissible air humidity: 10...90%, non-condensing Permissible storage humidity: 5...90%, non-condensing
• AC 230 V power supply
• Other Compatible with IEEE 802.3af PoE (PD) powered devices Support for auto-learning and auto-aging MAC addresses Support for bandwidth control standard for full duplex mode (IEEE802.3x) and back pressure function for half duplex mode

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	no brand
Parametry	Number of ports	8
Parametry	EAN (GTIN)	5907634598482
Parametry	Manufacturer code	0800AF
Parametry	Packaging status	original
