Tinklo jungiklis UGREEN, 5 portų, Gigabit Ethernet, 1 Gbps

Trumpai apie prekę

Prekė: Tinklo jungiklis UGREEN, 5 portų, Gigabit Ethernet, 1 Gbps. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Ugreen
• Modelis: 6941876246885

⭐⭐⭐⭐⭐

The UGREEN CM633 network switch is the ideal solution for home and office networks, providing a stable and fast connection without delay. With 5 gigabit RJ45 Ethernet ports supporting 10/100/1000 Mbps auto-negotiation, you can connect multiple devices such as computers, Smart TVs, game consoles or network printers. Store-and-Forward technology and full non-blocking bandwidth guarantee maximum transmission efficiency, without packet loss and speed limits.

⚙ Specification:

• Manufacturer: UGREEN
• Model: CM633
• Manufacturer code: 15641EU
• PoE (Power over Ethernet) support: No
• Network standards: IEEE 802.3/u/x/ab
• Number of ports: 5 × RJ45
• Speeds: 10/100/1000 Mbps (self-negotiation)
• Supported functions: Auto MDI/MDIX; Support full and half-duplex transmission mode; Dynamic learning and statute of limitations for MAC address entries; Full non-blocking bandwidth
• LEDs: 1 × power indicator; 5 × connection and activity indicator (Link/Act)
• Transmission medium: 10Base-T: Cat 3 cable or later (max. 100 m); 100Base-TX: Cat 5 cable or higher (max. 100 m); 1000Base-T: Cat 5 cable or higher (max. 100 m)
• Capacity: 1 Gbps
• Transmission method: Store-and-Forward
• Package forwarding speed: 10 Mbps: 14 880 pps/port; 100 Mbps: 148 800 pps/port; 1000 Mbps: 1 488 000 pps/port
• MAC Address Table: 2K entries
• Caching jumbo frames: 9K
• Input: AC 100-240V 50Hz/60Hz
• Output: DC 5.0V = 1.0A Max
• Working temperature: 0°C – 40°C
• Working humidity: 10% – 90% RH, non-condensing
• Storage temperature: -40°C – 70°C
• Storage humidity: 5% – 90% RH, non-condensing

✅Advantages:

✔ 5 gigabit Ethernet ports (RJ45): Support 10/100/1000 Mbps speed with automatic negotiation – ideal for connecting computers, consoles, TV or printers.

✔ High bandwidth – up to 1 Gbps: Guarantees smooth data transmission without delay, even under heavy loads (e.g. streaming, file transfer).

✔ Store-and-Forward and non-blocking technology: Provides full transmission performance without packet loss and speed limits.

✔ Full and half-duplex mode support: Allows simultaneous transmission and reception of data, which increases network efficiency.

✔ Auto MDI/MDIX function: Eliminates the need for patch cables – works with standard Ethernet cables.

⭐High performance and stability ⭐

UGREEN CM633 is a switch that adapts to your needs. Each of the five ports automatically detects the connection speed and operates at the maximum possible bandwidth. With support for full and half-duplex mode, the device can simultaneously send and receive data, which increases network efficiency. The Auto MDI/MDIX function eliminates the need for special patch cables – just connect a standard cable and the switch will adjust the configuration itself. The bandwidth of 1 Gbps means that even during intensive use, e.g. Whether streaming video or transferring large files, the network runs smoothly, without lag or speed drops.

⭐ Robust design and intelligent cooling ⭐

UGREEN CM633 is distinguished by a metal housing with a ventilation system that effectively dissipates heat and increases the durability of the device. Noiseless operation makes the switch perfect for both the office and at home.

⭐ Simple installation and energy saving ⭐

Thanks to the Plug & Play function, the device does not require complicated configuration – just connect the wires, and the switch will automatically recognize the connected devices and adjust the transmission parameters. In addition, energy-efficient technology dynamically adjusts power consumption, reducing energy consumption without affecting network performance.
