Tinklo jungiklis PoE 24 prievadų VIDOS PS242/370

Trumpai apie prekę

Prekė: Tinklo jungiklis PoE 24 prievadų VIDOS PS242/370. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Vidos
• Modelis: PS242/370

✅ We are an authorized distributor of VIDOS, which gives you the confidence that we deliver original and new products from the official polish distribution.

✅ By buying from us, in addition to the guarantee of 100% originality and attractive price, you gain professional technical support and expert knowledge. Only such a combination will ensure complete satisfaction with the purchase.

Contents of the product

1. PoE 24-port switch VIDOS PS242/370 (1 pc. )
2. Instruction in Polish
3. Original manufacturer's completion, brand new product from the official polish distribution, device in the latest hardware version
4. Technical support by e-mail/telephone during installation and commissioning
5. Authorised distributor guarantee of 36 months based on proof of purchase

VIDOS ONE system

The flexible design of the device allows you to create your own, the best version of the set perfectly suited to the characteristics and needs of a specific installation as well as user preferences.

The system is very modern and allows you to use the most technologically advanced functions, putting it on the highest podium among this type of solutions.

VIDOS ONE works perfectly as a standalone video intercom system for small single and multi-family installations. It is also a comprehensive solution for complex housing estate installations with support for multiple entrances and a concierge. Full compatibility of all system components.

Switch PS242/370 designed to support network video intercom systems (e.g. VIDOS ONE) and network CCTV systems.

The switch is equipped with 24 Ethernet ports supporting PoE (Power over Ethernet) technologies used to power devices in the IEEE 802.3af/at standard.

Switch PS242/370 is equipped with 2 Combo Uplink ports, which consist of UPLINK port and SFP socket. It is possible to connect to the SFP socket, e.g. Fiber optic SFP module, which allows you to connect switches to each other using a fiber optic cable and increase the range to 2 km.

The PS242/370 switch uses a switch that changes the mode to CCTV or VLAN. CCTV enables isolation of ports, accelerating data transmission, thus increasing the range of transmitted signal on the PoE port to 250 m. VLAN allows cooperation with virtual networks.

The PS242/370 switch is easy to install and requires no configuration. With its exceptional performance and quality, it is an ideal device for expanding a large network, e.g. in the company, market hall, hospital, wherever the installation requires a large number of cameras or video intercoms.

Functions

• Supported standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3 af, IEEE802.3 at
• Number of ports: 24x PoE Ethernet, RJ-45 (10/100 Mbps), 2x Combo Uplink (1000 Mbps)
• Wiring: 10BASE-T: category 3,4,5 UTP cable (≤100 m), 100BASE-TX: category 5 UTP cable (≤100 m), 1000BASE-T: category 5e UTP cable (≤100 m), 1000BASE-X: MMF or SMF SFT module
• Data transfer rate: 10Base-T: 14881pps/Port, 100Base-TX: 148810pps/Port, 1000Base-T/X: 1488095pps/Port
• MAC Addressing: 16K, Automatic Learning, Automatic Patching
• Power Supply: PoE 48 VDC
• Capacity: 8,8 Gbps
• Possibility of cascade connection
• Passive cooling
• PoE ports: port 1-24
• PoE capacity: 370 W (max)
• Power: 100-240 VAC 50/60 Hz
• PoE power supply via RJ45: Mode A 1/2(+), 3/6(-)
• Operating temperature: 0st.C ... 40st.C
• Dimensions: 440 x 207 x 44 mm

Specifications
