Tinklo jungiklis PLANET MGS-910XP pagal užsakymą

Trumpai apie prekę

Prekė: Tinklo jungiklis PLANET MGS-910XP pagal užsakymą. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Planet
• Modelis: MGS-910XP

Planet MGS-910XP on request

Planet

PoE+ switch with added value of 2,5 Gbps for a fast solution

PLANET MGS-910XP is an ideal multigigabit switch that offers data throughput of 2,5 Gbps and PoE power over UTP cables. It is designed to meet the needs of high-bandwidth network equipment such as 802.11ax and 802.11ac Wave 2 access points. It offers an ideal hardware configuration with 8 10/100/1000/2500BASE-T ports supporting 32W 802.3at PoE+ power supply each and an additional 10GBASE-X SFP+ port for fiber optic connection. The MGS-910XP eliminates bandwidth limitations when connecting a wireless network to a wired network.

With reliable switching technology and advanced networking features, the MGS-910XP optimizes the installation and power management of network devices such as wireless access points, VoIP phones and surveillance cameras. It also eliminates the need to invest time and resources in installation, as it combines power and data transmission in one device, allowing network devices to work without the limitations of the location of electrical outlets and additional AC cabling. This enables the MGS-910XP to handle massive amounts of data transferred in a secure topology by connecting to the main network backbone or high-power servers.

Unleash 2,5 Gbps bandwidth and device performance

For 6 802.11ax Wi-Fi access devices and 802.11ac wireless access points that achieve access speeds of 1,2 Gbps to 2,6 Gbps, Gigabit ports were unable to meet demand. With support for 10/100/1G/2,5 Gbps capabilities, the MGS-910XP can deliver data not only to 802.11ac wireless access points, but also takes into account both cost and performance. Users can use the CAT 5e cable in their existing environment to increase network speed to 2,5 Gbps while maintaining an economical budget. Therefore, all devices in a network environment can perform their full functions.

Flexible and extensible 10 Gb Ethernet solution

With 10GBASE-X fiber optic link capability, an administrator can now flexibly select the appropriate SFP+ transceiver depending on the required transmission distance or transmission speed to efficiently expand the network and provide wide bandwidth, range and powerful processing capabilities.

Perfectly integrated solution for IP surveillance in PoE technology

The MGS-910XP provides an ideal and secure monitoring system at a lower total cost. This device offers 8 10/100/1000/2500 Mbps ports supporting PoE+ 802.3at power, capable of delivering sufficient PoE power to 8 IEEE 802.3af/IEEE 802.3at compliant IP cameras simultaneously. It can also connect to an 8-channel recorder (NVR), has a 10GBASE-X SFP+ port to the main switch and monitoring center. Thanks to this powerful switch architecture, saved video files from PoE IP cameras can be stored in the NVR system, where the administrator can control and monitor surveillance images both on the local LAN and in remote locations.

Flexible and extensible 10 Gb Ethernet solution

With 10GBASE-X fiber optic link capability, an administrator can now flexibly select the appropriate SFP+ transceiver depending on the required transmission distance or transmission speed to efficiently expand the network, providing wide bandwidth, operating range and powerful processing capabilities.

Perfectly integrated solution for PoE-powered IP surveillance

The MGS-910XP provides an ideal, secure monitoring system with lower total costs. The MGS-910XP provides 8 10/100/1000/2500 Mbps ports supporting PoE+ 802.3at power, capable of delivering sufficient PoE power for 8 IEEE 802.3af/IEEE 802.3at compliant IP cameras simultaneously. It is also able to connect to an 8-channel DVR (NVR), has a 10GBASE-X SFP+ port to the main switch and monitoring center. Thanks to this powerful switch architecture, saved video files from PoE IP cameras can be stored in the NVR system, where the administrator can control and monitor surveillance images both on the local LAN and in remote locations.

Extending the range of Ethernet data transmission

The DIP switch provides "Standard" and "VLAN" modes of operation.

• The MGS-910XP operates as a regular switch in "Standard" mode.
• "VLAN" mode of operation includes a port-based VLAN function that helps prevent the mutual impact of multi-diffusion or IP camera broadcast storm.

Plug and play

All RJ45 MGS-910XP copper interfaces support 10/100/1000/2500Mbps automatic negotiation for optimal speed detection by RJ45 Category 5, 5e or 6 cables. They support the standard auto-MDI/MDI-X function, which allows you to detect the type of connection to any Ethernet device without the need for special straight or twisted cables.

• Redundant Power Supply: No
• Management: No
• Main Port Type: RJ45
• Main Port Bandwidth: 2.5G
• PoE Support: Yes
• PoE Power Budget: 120 W
• Number of PoE Ports: 8
• Device Type: Switch
• Quantity in Collective Package: 5 pcs
• Color: Blue
• Height: 4.4 cm
• Width: 28 cm
• Depth: 18 cm
• Weight: 1.739 kg
• Manufacturer Information: PLANET TaiwanNew Taipei City2314110F No. 96 Minquan Rd. Xindian Dist. New Taipei City Taiwan sales@planet.com.twwww.planet.com.tw +886222199518
• EU Responsible Person Information: Konsorcjum FEN Sp. z o.o.PolskaPoznań60-415Czarnkowska 13Konsorcjum Fen sp. z o. o.gpsr@fen.plhttps://b2b.fen.pl/+48 616690700

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	Planet
Parametry	Number of ports	8
Parametry	EAN (GTIN)	4711605287067
Parametry	Manufacturer code	MGS-910XP
