Tinklo jungiklis Hikvision DS-3E1528-SI-24T4F

Trumpai apie prekę

Prekė: Tinklo jungiklis Hikvision DS-3E1528-SI-24T4F. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: no brand
• Modelis: 56647

Product Description:

Hikvision DS-3E1528-SI-24T4F Switch

Model: DS-3E1528-SI-24T4F

Key Features

16-Port Gigabit Smart PoE Switch - Features:

16 × 10/100/1000 Mbps PoE ports, 2 × 10/100/1000 Mbps RJ45 ports, 2 × 10/100/1000 Mbps SFP ports

Total PoE Power Budget: 230 W

Supports 802.1Q VLAN

Supports 802.3bt Hi-PoE – max. 90 W per port

Supports STP/RSTP (Loop Prevention) and Broadcast Storm Control

Cable Diagnostics for fault localization

Supports SNMP, QoS, and DHCP Snooping

6 kV Surge Protection

Technical Specifications

Model DS-3E1528-SI-24T4F

Chassis Metal

Net Weight 2.3 kg (5.07 lb)

Gross Weight 2.82 kg (6.22 lb)

Dimensions (W × H × D) 440 mm × 44 mm × 220.8 mm (17.32” × 1.73” × 8.69”)

Operating Temperature 0°C to 45°C (0 °F to 113 °F)

Storage Temperature -40 °C to 85 °C (-40 °F to 185 °F)

Operating Humidity 5% to 95% (non-condensing)

Relative Humidity 5% to 95% (non-condensing)

Power Supply 100–240 VAC, 50/60 Hz, 0.7 A max

Installation Method Rack (mounting brackets included)

Max. Power Consumption 20 W

Idle Power Consumption 5 W

Surge Protection 6 kV

Network Parameters

Network Ports 24 × Gigabit RJ45 ports, 4 × Gigabit fiber ports

MAC Address Table 8 K

Switching Capacity 56 Gbps

Packet Forwarding Rate 41.66 Mpps

Internal Buffer 4.1 Mbits

PoE Power Supply

PoE Standard /

PoE Power Pins /

PoE Ports /

Max. Port Power /

Software Functions

Port Isolation Ports 1–28: Port isolation mode for enhanced network security

Link Aggregation Static link aggregation, up to 8 aggregation groups

QoS Port-based prioritization, SP and WRR modes

Loop Prevention Supports 802.1D STP

VLAN 802.1Q, VLAN ID 1–4094, Trunk and Access modes, max. 4094 VLANs

HPP Remote management via Hik-Partner Pro

System Maintenance

Management Via Web Browser

DHCP Client Supported, enabled by default

Super IP 10.180.190.200

Management Software Hik-Central Pro, Hik-Partner Pro

Cable Diagnostics Detects cable breaks, shorts, and length

LLDP Supports 802.1ab

SNMP SNMP v1/v2c

Port Mirroring Supported

Port Bandwidth Limiting Supported

Storm Control Limits broadcast, multicast, and unknown unicast

DHCP Snooping Supported (disabled by default)

ACL Up to 64 ACL entries, up to 128 rules

IPSG Port/MAC/IP binding, up to 256 entries

Certifications

EMC EN 55032:2015+A11:2020, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020; ICES-003 Issue 7:2020; AS/NZS CISPR 32:2015

Safety CE-LVD (EN 62368-1:2014+A11:2017), CB (IEC 62368-1:2014, AMD1:2009, AMD2:2013)

Environmental Compliance CE-RoHS (2011/65/EU), WEEE (2012/19/EU), REACH (EC No. 1907/2006)
