Tinklo jungiklis BCS LINE BCS-L-SP0801G-1SFP(2), 9 prievadų, PoE

Kaina:
€166,38
Sandėlys:
Yra sandėlyje

Trumpai apie prekę

Prekė: Tinklo jungiklis BCS LINE BCS-L-SP0801G-1SFP(2), 9 prievadų, PoE. Kategorija: Jungikliai ir koncentratoriai.

  • Gamintojas: BCS
  • Modelis: BCS-L-SP0801G-1SFP(II)

Unmanaged PoE switch BCS-L-SP0801G-1SFP(2) brand BCS Line.

It has ports: 8x RJ45 PoE 100Mbps and 1x SFP Gigabit and 1x Uplink. Dedicated to work in the IP monitoring system.

The device provides smooth network transmission at PoE speed - 10 / 100 Mb/s.

Priority power supply for first ports: Port 1-2≤ 90W, Port 3-8 ≤ 30W, total power≤ 96W

The switch has a PoE watchdog function, which ensures safe operation of the device.

PoE technology enables simultaneous data transmission and power supply of PoE cameras over the same UTP cable. This reduces the number of cables in the installation.

Extended data transmission up to 250m at 10Mbps.

CHARACTERISTICS

  • Unmanaged PoE switch,
  • Number of ports: 8x RJ45 PoE 100Mbps, 1x SFP Gigabit, 1xRJ45 uplink Gigabit,
  • Supported PoE standard: 802.3af / 802.3at / 802.3bt / 802.3 / 802.3u / 802.3x / 802.3ab / 802.3z,
  • Bandwidth: 7.60 Gbps,
  • Power: PoE ports: Port 1-2 ≤ 90 W, Port 3-8 ≤ 30W,
  • Data transmission: Max. 250 meters at 10Mbps,
  • Power supply: 48V–57V DC.

TECHNICAL DATA Number and type of ports 8× RJ45 PoE 100Mbps, 1× SFP 1000Mbps, 1x RJ45 1000Mbps Throughput 7.60 Gbps Packet forwarding rate 4.17 Mpps Communication standard 802.3af / 802.3at / 802.3bt / 802.3 / 802.3u / 802.3x / 802.3ab / 802.3z Operating modes Standard: 100m

Long distance: 250m (10Mbps) Packet buffer memory 1 Mbit MAC board 8K PoE/BT pins 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) Total power 96W,

Port 1-2 ≤ 90 W, Port 3-8 ≤ 30W Electrostatic Protection 8kV Environment / 6kV Contact; Surge Protector 2kV DM / 4kV CM Humidity 5% ~ 95% DC Power Supply 48 ~ 57V Operating Temperature -30°C ~ 65°C Weight 550g Dimensions 150 mm × 100 mm × 30 mm

10754

Specifications

Group Name Value
Parametry Condition new
Parametry Invoice With VAT invoice
Parametry Manufacturer BCS
Parametry Product weight with unit packaging 0.55 kg
Parametry Number of ports 9
Parametry EAN (GTIN) 5904890704251
Parametry Manufacturer code BCS-L-SP0801G-1SFP(II)
