Suvirinimo aparatas MIG/TIG/MMA IDEAL EXPERT MIG 250 4x4 PFC Synergic

Trumpai apie prekę

Prekė: Suvirinimo aparatas MIG/TIG/MMA IDEAL EXPERT MIG 250 4x4 PFC Synergic. Kategorija: Pusiau automatiniai suvirinimo aparatai.

• Gamintojas: IDEAL
• Modelis: IDEAL EXPERT MIG 250 PFC
• Ilgis: 760 mm
• Plotis: 320 mm
• Aukštis: 580 mm

Microprocessor-controlled semi-automatic welding machine for MIG-MAG, FLUX, MMA, TIG welding and soldering of galvanized sheets. Welding current 250A. Power supply 230V. Welding wire diameter 0,6-1,2mm. 4-roll wire feeder. Synergy.

WELDING MIGOMAT MIG TIG MMA IDEAL EXPERT MIG 250 4x4 PFC SYNERGIC

EXPERT MIG 250 4X4 PFC is an inverter synergistic semi-automatic welding machine designed for MIG/MAG, TIG LIFT, MMA and FLUX arc welding. The device has been designed for a wide range of applications: from maintenance work to car body repairs. EXPERT MIG 250 is used for soldering galvanized sheets, welding stainless steel, carbon and low alloy steels and aluminum. Welding is carried out in an inert gas shield, active or mixture, and with reverse polarity without gas. The welding parameters recording function makes it easy to work on various materials without having to re-adjust the device when changing gas and wire. By using a 4-roll wire feeder, the device performs very well with 5 meter welding torches. The device is equipped with :2-bar, 4-bar and spot welding. We also have the ability to adjust: welding inductance, welding voltage correction, gas before, gas after, wire burning and soft start.

The device has a manual mode and 21 MIG/MAG synergistic programs with the possibility of adjusting:

- gas before welding,

- gas after welding,

- access to wire,

- burning wire,

- spot welding time,

- interruptions in spot welding.

PHYSICAL PARAMETERS:

The device has a fan cooling system which significantly increases its efficiency, is equipped with overload protection, over and undervoltage protection, to work with a generator (+/- 15%) which increases its reliability. PFC (Power Factor Correction) – increased power factor, 30% less power consumption from the mains.

POWER SUPPLY PARAMETERS:

Single-phase power supply 230V. The device is equipped with a power plug.

TECHNICAL DATA:

- power supply network protection: 25 A,

- rated supply voltage: 230 V; 50Hz (1ph),

- power: 7,8 kW,

- maximum current: 250 A,

- current at 100% operation: 195 A,

- current at 60% operation: 250 A,

- diameter of aluminium wire: 1,0 - 1,2 mm,

- diameter of wire for soldering: 0,8 mm,

- diameter of self-shielding wire: 0,8 - 1,2 mm,

- diameter of steel wire: 0,6 - 1,2 mm,

- diameter of stainless steel wire: 0,6 - 1,2 mm,

- diameter of welding electrode: 1,6 - 6 mm,

- degrees of welding current adjustment: incrementally,

- welding current adjustment range: 40 - 250 A (MIG/MAG) / 10 - 250 A (MMA/TIG),

- wire spool size: 15 kg,

- degree of protection: IP 23,

- weight of the device / set: 27 / 32 kg,

- dimensions L x W x H: 760x320x580 mm.

EQUIPMENT:

- IDEAL MIG EXPERT MIG 250 4x4 PFC SYNERGIC welding machine,

- MIG welding torch 24 3m,

- mass cable 3m,

- power plug.

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	IDEAL
Parametry	Power consumption	5.6 kVA
Parametry	Supply voltage (V)	230
Parametry	Duty cycle time	60%
Parametry	Maximum electrode diameter	4 mm
Parametry	Wire diameter (mm)	0,8-1,2
Parametry	Device weight	20 kg
Parametry	Welding range	40–250 A
Parametry	Height	580 mm
Parametry	Length	760 mm
Parametry	Width	320 mm
Parametry	Length of ground cable	300 cm
Parametry	Welding cable length	300 cm
Parametry	Product weight with unit packaging	27 kg
Parametry	Manufacturer code	EXMIG250PFC
Parametry	EAN (GTIN)	5903991100061
Parametry	Packaging status	original
Parametry	Model	IDEAL EXPERT MIG 250 PFC
Parametry	Welding methods	MIG/MAG,MMA,TIG
Parametry	Additional features	infinitely adjustable welding current,EURO handle
