Suvirinimo aparatas MAGNUM MIG 224S MAG Alu SYNERGY DUAL PULS, 230V, LCD, 3in1

Trumpai apie prekę

Prekė: Suvirinimo aparatas MAGNUM MIG 224S MAG Alu SYNERGY DUAL PULS, 230V, LCD, 3in1. Kategorija: Pusiau automatiniai suvirinimo aparatai.

• Gamintojas: Magnum
• Modelis: 224 SDP

⏩THE MOST IMPORTANT ADVANTAGES

✅ MIG/MAG welding current 30 – 200 A

✅ MMA / TIG welding current 20 – 180 A

✅wire handling 0,6 / 0,8 / 0,9 / 1,0 / 1,2 mm

✅MIG/MAG, MMA and TIG Lift in one device

✅synergic mode facilitating the selection of welding parameters

✅possibility of welding black steel, stainless steel, acid-resistant steel, aluminum and its alloys

✅possibility of soldering

✅synergic programs for aluminium and soldering

✅single and double pulsation welding current

✅digit control of welding parameters

✅readable control panel with display

✅regulation of welding current and wire feed speed

✅correction of voltage, arc length and inductance

✅2T/4T/SPOT operating modes

✅ spot welding with time adjustment

✅test gas outflow

✅Test Wire Extension

✅MMA with VRD and Anti Stick

✅IGBT inverter technology

✅230 V power supply

✅ Protection class IP21S

✅net weight 12 kg

⏩WHAT WILL YOU FIND IN THE PACKAGE?

☑ welding machine MAGNUM MIG 224 S-DP — 1 pc.

☑ MIG/MAG MB24/3 work handle with red Teflon guide - 1 pc.

☑ MMA working cable 2 m - 1 pc.

☑ cable with mass clamp 2 m - 1 pc.

☑ set of rollers for steel and aluminium - 1 set

☑ blue steel guide - 1 pc.

⏩FREQUENTLY ASKED QUESTIONS

• Does this welding machine have synergy? Yes. MAGNUM MIG 224 S-DP has MIG/MAG synergistic modes that facilitate the selection of parameters for material, wire diameter and gas shield.
• Can welding parameters be corrected? Yes. The user can adjust the arc length, voltage and inductance, so you can adjust the nature of the device to the material and your own welding technique.
• Does this welding machine have a single and double pulse? Yes. The MIG 224 S-DP offers Single Pulse and Double Pulse modes, i.e. single and double pulsed welding.
• Is it suitable for aluminum? Yes. The device has AlSi and AlMg programs for welding aluminum alloys in argon sheath.
• Can stainless steel be welded with it? Yes. The welding machine has an SS program for welding stainless steels.
• Can it be soldered? Yes. The model has a CuSi program for soldering and CuAl for soldering aluminum sheets.
• Can copper be welded with it? Yes. The device has a Cu program for welding copper and its alloys.
• Does it work without gas in Flux? Yes.
• Can I weld with MMA wrapped electrode? Yes. The device supports MMA / STICK method.
• Does MMA have auxiliary functions? Yes. VRD and Anti Stick are available in MMA mode.
• Does the device have 2T/4T mode? Yes. In MIG/MAG mode, you can choose 2T, 4T or SPOT, i.e. spot welding.
• Can I set the gas time before and after welding? Yes. Pre Gas and Post Gas settings are available, i.e. gas outflow before and after welding.
• Does the welding machine have a gas and wire extension test? Yes. The device has a test gas outflow and a test wire extension.
• What power supply does it run on? The welder operates on AC 230 V, 50/60 Hz power supply. The required protection is 20 A class C.
• What range of current does it offer? The MIG/MAG welding current range is 30 to 200 A, and MMA / TIG 20 to 180 A.
• What wire diameters does it support? The device supports 0,6 / 0,8 / 0,9 / 1,0 / 1,2 mm wire, depending on the selected program and material.
• How much does the welding machine weigh? The net weight of the device is 12 kg.

⏩Professional MIG 224 S-DP Dual Pulse Synergistic Welding Machine

MAGNUM MIG 224 S-DP is a modern semi-automatic welding machine for users who expect precision, stable arc and high quality welds in various operating conditions. The device combines MIG/MAG, MMA and TIG Lift welding, offering a wide range of applications in workshop, service, production, locksmith and automotive work.

The MIG 224 S-DP is equipped with advanced synergistic programs that significantly facilitate the selection of welding parameters. After selecting the material, wire diameter and thickness of the element, the device automatically adjusts key settings, which allows you to start work faster and achieve repeatable, aesthetic effects.

⏩Welder will be a good choice for:

• professional locksmith, repair and production workshops,
• car workshops and work on aluminum elements,
• users who want to work with black steel, stainless steel, aluminum and soldering,
• people expecting single and double pulse functions,
• welders who want to use synergies, but at the same time be able to correct parameters,
• users who need one MIG/MAG, MMA and TIG Lift machine,
• ambitious DIYers who want to take it to the next level than with a simple migraine,
• customers looking for a compact 230 V device with a wide range of applications.

⏩WELDING PROGRAMS AND METHODS

• MIG/MAG synergistic - MAGNUM MIG 224 S-DP enables MIG/MAG welding in synergistic mode. The user chooses the type of material, wire diameter and gas shield, and the device automatically selects the most important operating parameters, such as wire feed speed and welding voltage. In addition, the arc length and inductance can be corrected, thanks to which the welder can adjust the nature of the device to the material, welding position and his own technique.
• Single Pulse / Double Pulse - The device offers welding with single and double current pulsation. Single Pulse mode improves control over the welding process and reduces material overheating, while Double Pulse allows for even more aesthetic welds, especially with aluminum and stainless steel. Double pulse is one of the strongest functions of this model useful where the appearance of the weld, temperature control and stable handling of the welding lake count.
• GMAW - black steel - The GMAW mode is designed for welding black steel in a CO2 shield or Ar + CO2 mixture. This is the basic program for typical workshop, locksmith, construction and repair work.

⏩Synergic programs for materials:

✅C.S - carbon steel / black steel,

✅SS - stainless steel,

✅AlSi - aluminium with silicon,

✅AlMg - aluminium with magnesium,

✅CuSi - soldering,

✅CuAl - soldering of aluminium sheets,

✅Cu - copper and its alloys.

⏩Professional wire feeder

The use of a high-quality, 2-roll wire feeder ensures smooth and stable feeding to the welding torch. This solution translates into precise control of the welding process and maintaining stable operating parameters.

• Power supply: AC 230 V / 50 – 60 Hz

• Welding methods: MIG/MAG, MMA, TIG Lift

• MIG/MAG welding current: 30 – 200 A

• MIG/MAG welding voltage: 14 – 25 V

• MMA/TIG welding current: 20 – 180 A

• Idle voltage: 60 V

• Wire diameter: 0,6 / 0,8 / 0,9 / 1,0 / 1,2 mm

• Security required: 20 A class C

• Efficiency: 60%

• Degree of protection: IP21S

• Net weight: 12 kg

• Technology: inverter IGBT

• Functions: synergy, Single Pulse, Double Pulse, 2T/4T/SPOT, VRD, Anti Stick, Pre Gas, Post Gas, Gas Test, Wire Extension Test

Choose a brand whose history dates back to the beginning of the twenty-first century. Magnum is the leading brand of welding equipment in Poland.

A wide range of Magnum devices meets the needs of not only novice users, but also more advanced ones. Depending on the selected model, it can be dedicated to workshop applications as well as for heavy industry.

Customers choose the Magnum brand most often due to its high quality, affordable price and reliability.

Specifications
