Silicio fotodiodas 2DU3, matomos šviesos detektorius, G9

Trumpai apie prekę

Prekė: Silicio fotodiodas 2DU3, matomos šviesos detektorius, G9. Kategorija: Maitinimo šaltiniai ir įkrovikliai.

• Gamintojas: no brand
• Modelis: AG260104029409

Function:

1. Suitable for photodetection elements, near-infrared detectors, photoelectric readings, optocouplers, sheds, laser setting identification and photoelectric switches.

2. This photocell has a wide spectral characteristic, incomparable to photomultipliers, photocells and selenium photocells.

3. It is particularly ideal for optical instruments operating in the spectral range from 300 NM to 1000 NM.

4. Enjoys stable and reliable performance.

5. Simple and flexible circuit design, this is a new generation of selenium battery.

Specification:

• Functions:
• Suitable for photodetection elements, near-infrared detectors, photoelectric readings, optocouplers, sheds, laser setting identification and photoelectric switches.
• This photocell has a wide spectral characteristic, incomparable to photomultipliers, photocells and selenium photocells.
• It is particularly ideal for optical instruments operating in the spectral range from 300 NM to 1000 NM.
• Enjoys stable and reliable performance.
• Simple and flexible circuit design, this is a new generation of selenium batteries.
• Specification:
• Condition: 100% new
• Material: plastic and electronic components
• Size: about 1,7 x 7,8 x 5,8 mm / 0,07 x 0,31 x 0,23 inches
• Color: as shown in the pictures
• Weight: 20g
• Photosensitive area (mm2): 3 * 3
• Spectral Range (nm): 300-1000
• Peak wavelength (nm): 700
• Short-circuit current E=100Lx(uA):>20
• Open circuit voltage E=100Lx(mV): 300
• VR dark current = 100mV(A):
• List of packages:
• 1 x Silicon Photodiode
