Priekinis dviračio žibintas RAVEMEN UR1700, 1700 lm, IPX6, USB-C, LED

Trumpai apie prekę

Prekė: Priekinis dviračio žibintas RAVEMEN UR1700, 1700 lm, IPX6, USB-C, LED. Kategorija: Apšvietimas.

• Gamintojas: Ravemen
• Modelis: UR1700
• Spalva: black

➡ Product Description

Product name: RAVEMEN UR1700

Light Source Type: LED

Maximum brightness: 1700 lm

Maximum lighting range: 195 m

Battery capacity: 3600 mAh

Charging time: 1.7 h

Charging Socket: USB-C

Waterproof rating: IPX6

Product Dimensions: 60 mm * 48 mm * 38 mm

Product weight: 180 g

Certificates: CE, RoHS

Additional Features: sharp light cut-off line, smart on and off, wireless control, battery level indicator, mode memory

Mode / Brightness / Battery life

Far and near light

• High mode: 1700 lm | 1.5 h

• Medium mode: 800 lm | 2.5 h

• Low mode: 400 lm | 4 h

Near light

• High mode: 800 lm | 3 h

• Medium mode: 400 lm | 5 h

• Low mode: 200 lm | 7 h

• Energy saving mode: 100 lm | 18 h

• Flickering: 400 lm | 23 h

Note: The above parameters were measured under standard laboratory conditions. Actual results may vary depending on the environment.

【Quick start】

➡ Wireless remote control pairing

The remote is factory paired with the lamp. Press and hold the power button for 1.5s to turn on the lamp, then remove the insulation film from the remote control and press any button on the remote control to check the lamp response. If the lamp does not respond, perform pairing according to the following steps:

1、First turn on the lamp, then press and hold the power button for about 5s (the lamp will turn off first and then start flashing quickly) to go into pairing mode.

2、Press both buttons on the wireless remote simultaneously for about 5 seconds to pair with the lamp. After successful pairing, the lamp will stop flashing. Blue light when you press any remote control button means correct pairing. If pairing fails, repeat the above steps.

➡ Power button

Press and hold for 1.5 s to turn the lamp on or off. A single press changes the lighting modes cyclically, a double press switches between far and near light and the near light itself.

➡ Automatic on and off mode

When the lamp is off, press and hold the power button for about 3 seconds until the lamp is turned on and flickering quickly, then release the button immediately. (Five quick flashes means mode activation, three slow flashes mean mode disabling.) When the mode is active, the lamp turns off automatically after 2 minutes of stillness and turns on again when vibration is detected.

➡ Mode memory function

The lamp remembers the last selected mode when turned off.

➡ Battery Level Indicator

When the lamp is turned off, a single press of the power button activates the battery level indicator:

Green light: more than 45%;

Red light: 15-45%;

Flashing red light: low battery, charge the device as soon as possible.

➡ Charging via USB-C

Standard charging time: 1.7 h. Maximum input voltage: 5 V, DC/2 A.

The device has built-in overcharge protection.

Note: 1、Some chargers may not work with the lamp due to differences in charging protocol. In this case, try using a different charger or charging cable. 2、Do not charge the lamp in the rain and always close the rubber cap of the charging socket.

➡ Charging indicator

Flashing red light: charging is in progress; Continuous green light: battery fully charged.

Specifications
