Prieigos taškas TP-LINK EAP660 HD

Trumpai apie prekę

Prekė: Prieigos taškas TP-LINK EAP660 HD. Kategorija: WiFi maršrutizatoriai ir prieigos taškai.

• Gamintojas: TP-Link
• Modelis: EAP660 HD V1

AP TP-LINK EAP660 HD

TP-LINK

AP TP-LINK EAP660 HD

Key features

• Lightning-fast Wi-Fi 6 speeds : Simultaneous speeds of up to 1148 Mbps on the 2.4 GHz band and 2402 Mbps on the 5 GHz band, for a total of up to 3550 Mbps.†
• Stable operation in heavily loaded environments : 4x higher performance than the previous generation standard means that many more devices can connect simultaneously. ‡
• Possibility to use Omada SDN : The platform provides access to maintenance-free ZTP§ configuration, central cloud management and intelligent monitoring.
• Centralized management : Management is extremely convenient thanks to cloud access and the easy-to-use Omada app.
• Seamless Roaming : Video streams and ongoing voice calls are not interrupted when users change locations. △
• PoE power supply support : Selecting a location for the device and its installation are not difficult thanks to PoE power supply support (802.3at standard).
• Secure Guest Network : Multiple authentication methods available (SMS/Facebook Wi-Fi/Voucher, etc.) ) and numerous technologies that protect access to wireless networks.

Ultra-high-performance AX3600 business access point for high-traffic environments

Four times more throughput for demanding environments

With OFDMA* and MU-MIMO Uplink and Downlink** technology, the EAP660 HD can achieve up to four times the throughput of Wi-Fi 5 (802.11ac) devices in high-traffic environments, allowing you to connect more devices‡. Use the potential of network equipment and significantly improve the operation of your company.

Hotels - High-quality Wi-Fi connections available in large areas

Restaurants - Wide Wi-Fi coverage in data-intensive environments

Shopping Centers - Social Marketing for the O2O Model

Offices - Seamless wireless and wired connections

Stations - Wi-Fi network with high data traffic

Eight data streams for lightning-fast speeds

New 802.11ax technologies, such as 1024QAM modulation and long OFDM symbols, enable the EAP660 HD to achieve previously unattainable speeds: 2402 Mbps on the 5 GHz band and 1148 Mbps on the 2.4 GHz band, for a total of 3550 Mbps†. Eight spatial streams translate into more users using the network simultaneously, and therefore more efficient work.

Omada SDN - an even smarter cloud solution for business networks

Omada's software-defined network infrastructure (SDN) platform integrates the operation of network devices, including access points, switches and gateways, providing access to a functional business network with higher performance, better security and greater reliability.

Centralized cloud management:

Comprehensive central management of the entire network, divided between various entities, from a single interface – anywhere, anytime.

2.5 GE PoE+ Port - Optimal Wired Connectivity

The access point is equipped with a 2.5 GE port, which is why it effectively covers the needs of devices connecting to the network for fast and efficient Wi-Fi connections. Thanks to the support of PoE+ 802.3at power supply, finding a suitable location for the AP is also not difficult.

Seamless roaming

The 802.11k/v roaming feature allows clients to automatically switch between access points that provide the fastest speeds when the user changes location - without interrupting ongoing activities, even those that are sensitive to interruptions, including VoIP and video conferencing.

Advanced features mean greater network performance

Bandwidth control

Dual-band devices are automatically connected to the wider 5 GHz band, giving them access to faster connections.

Bandwidth load balancing

A network heavily loaded with data traffic operates smoothly and without interruptions even when many devices are connected to it.

Airtime Fairness

Improves network performance by reducing inefficient use of bandwidth.

Guest network protection via Facebook Wi-Fi or SMS authentication login

Advanced security measures are used to protect guest networks. The welcome page grants Internet access only to authorized users. Authentication via SMS or Facebook simplifies your welcome page so that visitors who want to use your corporate network don't have to wait long to connect.

Technical specifications

HARDWARE FEATURES Ports 1 x 2.5 Gbps Ethernet port (supports IEEE802.3at PoE) Buttons Reset Power • PoE 802.3at • 12 V DC Power Consumption EU: 18.5 W Dimensions (W x D x H) 243 x 243 x 64 mm (9.6 x 9.6 x 2.5 in) Antenna Type Internal, omnidirectional: • 2.4 GHz: 4 x 4 dBi • 5 GHz: 4 x 5 dBi Mounting Ceiling/Wall mount (mounting kit included) WIRELESS FEATURES Wireless Standards IEEE 802.11ax/ac/n/g/b/a Operating Frequency 2.4 GHz and 5 GHz Transmission speed • 5 GHz: up to 2402 Mbps • 2.4 GHz: up to 1148 Mbps Wireless features • 1024-QAM • 4 times longer OFDM symbol • OFDMA • Multi-SSID (up to 16 SSIDs, 8 for each band) • On /off Wireless Transmission• Automatic Channel Selection• Transmit Power Control• QoS (WMM)• MU-MIMO• Seamless Roaming• Band Steering• Load Balancing• Airtime Fairness• Beamforming• Rate Limiting• Reboot Schedule• Wireless Schedule• Wireless Statistics based on SSID/AP/ClientWireless Transmission Security• Captive Page Authentication• Access Control• MAC Address Filtering• Wireless Client Isolation• SSID to VLAN Mapping• Rogue AP Detection• 802.1X Support• WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise EncryptionTransmission Power• CE:< 20 dBm (2.4 GHz, EIRP)< 23 dBm (5 GHz, EIRP)• FCC:< 26 dBm (2.4 GHz)< 26 dBm (5 GHz)MANAGEMENTOmada AppYesCentral Management• Omada Cloud-based Controller• Omada Hardware Controller (OC300)• Omada Hardware Controller (OC200)• Omada Software ControllerCloud AccessYes (via OC300, OC200, Omada Cloud-based Controller, or Omada Software Controller)Email NotificationYesLED On/OffYesMAC Access ControlYesSNMPv1, v2c, v3System LogLocal and RemoteSSHYesWeb-based ManagementHTTP/HTTPSL3 ManagementYesMulti-site ManagementYesVLAN ManagementYesOTHERCertificationsCE, FCC, RoHSPackage Contents• EAP660 HD• Power Adapter• Mounting Kit• Installation GuideSystem RequirementsMicrosoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux Operating Environment • Operating Temperature: 0℃~40℃ (32℉~104℉) • Storage Temperature: -40℃~70℃ (-40℉~158℉) • Humidity: 10%~90%, non-condensing • Storage Humidity: 5%~90%, non-condensing

Access point architecture: Gigabit Ethernet

Max power: 23 dB

Processor (chipset): no data

Access point device type: Access point

Antenna Application: Internal

Antenna gain: • 2.4 GHz: 4× 4 dBi • 5 GHz: 4× 5 dBi

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	TP-Link
Parametry	Mode of operation	Access Point
Parametry	Internal modem	no modem
Parametry	Management	app
Parametry	Number of LAN (RJ-45) ports	1
Parametry	LAN port operating standard	10/100/1000 Mbps
Parametry	Antenna	built-in
Parametry	Product weight with unit packaging	0.15 kg
Parametry	EAN (GTIN)	6935364089719
Parametry	Manufacturer code	EAP660 HD(EU) V1
Parametry	Model	EAP660 HD V1
Parametry	The highest standard supported	802.11ax (Wi-Fi 6)
Parametry	Certificates of conformity	CE
Parametry	Batteries included	no
Parametry	Wireless operation standard	802.11ax (Wi-Fi 6),802.11ac (Wi-Fi 5),802.11n (Wi-Fi 4)
Parametry	Band	2,4 GHz,5 GHz
