Pramoninis jungiklis Digitus DN-651129

Trumpai apie prekę

Prekė: Pramoninis jungiklis Digitus DN-651129. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Digitus
• Modelis: DN-651129

The DIGITUS industrial gigabit switch is designed to operate in harsh environments where it is exposed to moisture, temperature fluctuations and vibration. With a temperature range of -40°C to 80°C, the gigabit switch with IP40 housing can be used in the most adverse conditions. Redundant power supply ensures constant availability in highly sensitive areas such as transport, manufacturing, traffic and security surveillance. With 16 Gigabit Ethernet ports, it is designed for a variety of possible applications. Attention!

Technical data:

• Auto-Uplink on each port: no
• Certificate of resistance: IP40
• Further specifications: bold Mounting plate throughput: /bold 56 Gb/s bold Forwarding capabilities:/bold 42 Mpp bold Packet buffer: /bold 4,1 Mbps Full duplex flow control IEEE802.3x bold Network protocols:/bold IEEE802.3, IEEE802.3i, IEEE802.3u, IEEE802.3ab,IEEE802.3z, IEEE802.3x bold Input Voltage:/bold 12 - 52 V DC, redundant power supply bold Power consumption: /bold less than 10 W bold High voltage protection:/bold +/- 4kV bold Supports air discharge: /bold +/- 12 kV bold Supports contact discharge:/bold +/-8 kV bold Industrial standards: /bold IEC 61000-4-4(EFT) IEC 61000-4-5 (overvoltage),Shocks IEC 60068-2-27, Fire IEC 60068-2-32, Vibration:IEC 60068-2-6 bold Average working time: /bold 300 000 h bold Operating temperature: /bold -40 ℃ ~ 80 ℃ g id=''5007'' Storage temperature:/g -40 ℃ ~ 80 ℃ bold Operating humidity: /bold 5% ~ 95% (non-condensing) bold Jumbo frame size: /bold 9KB Housing:aluminium bold Industrial use: /bold Yes bold Managed: /bold NIE bold Mounting type: /bold DIN rail bold Suitable for outdoor use:/bold NO bold PoE (power over Ethernet): /bold NO bold Protection against vandalism: /bold NO bold VLAN: /bold NO
• Product depth: 135 mm
• Number of MAC addresses: 8000
• Number of Ports: 16 Ports
• Number of ports 10/100/1000 MBit/s: 16 x
• Number of Ethernet Ports: 16
• Interface: RJ45
• Jumbo Frames: yes
• Manufacturer Color: Blue
• Maximum ambient temperature: 80 °C
• Minimum ambient temperature: -40 °C
• Operating Voltage: 52 V
• Power Consumption: 10 W
• Basic functionality: Unmanaged switch
• Product Width: 175.6 mm
• Transmission rate: 10 / 100 / 1000 MBit/s
• LAN transfer rate: 10 MBit/s, 100 MBit/s, 1000 MBit/s
• Port Type: RJ45
• Weight: 900 g
• Product height: 45.5 mm
• Power supply: from the mains, from the mains (redundant), through the DC input, through the DIN rail power supply

• User manual
