Pjūklo staklės Bosch GCM 254 D, 1800W, 254mm

Trumpai apie prekę

Prekė: Pjūklo staklės Bosch GCM 254 D, 1800W, 254mm. Kategorija: Kampiniai pjūklai.

• Gamintojas: Bosch
• Modelis: 0601B53000

The equipment of the offered slash includes:

• Optimline Wood saw blade, 254 x 30 mm, 40 teeth
• metal clamping clamp
• dust bag

Technical parameters:

• Engine power: 1.800 W
• Rotation speed: 4.800 rpm
• Disc diameter: 254 mm
• Disc hole diameter: 30 mm
• Bevel adjustment: 47° to the left / 52° to the right
• Tilt setting: 45° to the left / 45° to the right
• Weight of the device: 17,9 kg

Maximum dimensions of the workpiece:

• Bevel 0° / Tilt angle 0° - 90 x 310 mm
• Bevel 45° / Tilt angle 0° - 90 x 210 mm
• Bevel 0° / Tilt angle 45° (left) - 45 x 310 mm
• Bevel 0° / Angle 45° (right) - 35 x 310 mm
• Bevel 45° / Tilt angle 45° (left) - 45 x 210 mm
• 45° bevel / 45° angle of inclination (right) - 35 x 210 mm

The company's bevels are high-quality tools that are among the best on the market. All components and components as well as extremely efficient engines have been optimally matched to each other enabling fast, easy and very efficient operation. Thanks to these advantages, BOSCH is almost without exception ahead of the competition.

The high-power 1800 W motor ensures efficient operation and guarantees a fast cutting speed.

Double-sided tilt angle adjustment.

Very durable and robust thanks to the special design of the engine and transmission.

Easy and convenient to adjust the bevel angle on the front of the device.

Main handle with the possibility of easy locking in four different positions.

Compact design and built-in transport handle allows for easy and convenient transport of the device.

All operating elements for angle and bevel settings on the front of the slash and a large main handle make slash operation easy and safe.

Built-in spindle lock for mounting and disassembling the disc with only one key (key is included).

Precise cutting and stable operation thanks to the use of a toboggan parallel guide.

The base is made of high quality cast aluminum.

The built-in projector of laser lines increases cutting precision, 2 laser lines displayed on the workpiece show very precisely where the material will be cut.

Depth limiter for slotted cuts - slotted cutting function allows for very precise cutting of the processed material to the desired depth.

The dust extraction system guarantees healthy working conditions and a clean workstation.

Professional saw blade Optiline for Wood 254 mm in serial equipment – for very fast cuts in wood and wood-based materials

Metal mounting clamp in the equipment - allows you to fix and lock the workpiece on the slash, so that during cutting the material does not move and guarantees accurate cutting in the selected place

Integrated table extensions for large-size materials

Special holes for fixing the slash on BOSCH work tables - mounting holes allow you to fix the slash on work tables without the need for additional adapters, the user can choose from as many as 3 different models of BOSCH work tables - GTA 3800, GTA 2600 or GTA 2500 W (tables are available at our other auctions)

Low weight (only 18,5 kg) guarantees high mobility and convenient transport of the device

Delivery includes:

• Bevel with feed company BOSCH
• Metal clamping clamp
• Saw blade 254 x 30 mm
• Dust bag
• Instruction manual in Polish

Specifications
