Optinis nivelyras TOPCON AT-B4A su kalibravimu

Trumpai apie prekę

Prekė: Optinis nivelyras TOPCON AT-B4A su kalibravimu. Kategorija: Optiniai nivelyrai.

• Gamintojas: Topcon
• Modelis: AT-B4A

The optical leveler of the new Topcon AT-B4A series is a new leveler that replaced the older AT-B4 series. The magnification of the telescope is 24x, the accuracy is as follows: 2,0mm per 1 km of double leveling. The new housing makes the leveler even more resistant to harsh working conditions and vibrations and shocks - all thanks to the built-in magnetic compensator that automatically levels the instrument and facilitates work. It has a high dust and IPX6 waterproof standard. The optics has this advantage which is the minimum target axis -> 0,2m.

Advantages:

• highest precision of measurements

  optical levelers thanks to excellent Japanese optics (24x magnification telescope) the leveler ensures accuracy of 2,0 mm per 1 km of double leveling

• resistant to harsh working conditions, resistant to vibration and shock

  built-in magnetic compensator automatically levels the instrument and thus facilitates work in places with unstable and vibrating ground (e.g. on a construction site where heavy machinery passes), high standard of water- and dustproof (IPX6)

• at a minimum distance from the patch

  equipment is adapted to work with a minimum target length of 0,2 m, which allows you to level the area close to the site without having to change it

• convenience of operation

  without a range sloth of the horizontal wheel allows you to precisely aim the leveler at the patch, and the box libella with a mirror allows you to easily and quickly level the instrument

• light and small

  compact housing and lightweight and durable construction materials make the leveler can be set on a small tripod

• stable and reliable

  confidence of the instrument without any unexpected interruptions

Technical data:

• Accuracy per 1 km of double leveling 2 mm
• Magnification 24x
• Shortest target 0,2 m
• Distribution capacity 4”
• Compensator operating range +/- 15'
• Advantage of libella 10'/2 mm
• Horizontal wheel 400
• Lens diameter 32 mm
• 5/8" Heart Screw Thread
• Dust/water resistance standard IP X6
• Weight 1.7 kg

Together included:

• AT-B4A optical leveler
• Scope curtain
• rectification needle
• transport trunk
• instruction manual
