Motociklų mechaninis žirklinis keltuvas 500 kg STIX

Trumpai apie prekę

Prekė: Motociklų mechaninis žirklinis keltuvas 500 kg STIX. Kategorija: Motociklų keltuvai.

• Gamintojas: Stix
• Modelis: 23-03-54067

Mechanical scissor lift STIX Tool SM-03 with lifting capacity up to 500 kg designed for lifting motorcycles during service work. Equipped with adjustable, rubberized stands and can be screwed to the ground ensures stable and controlled lifting of the vehicle. The compact design allows you to work even at low clearance.

Catalog number: 23-03-54067

Manufacturer: Stix Tool

Model: SM-03

Quantity: 1 piece

⚙ Technical parameters:

• Type: mechanical scissor lift (screw)
• Maximum lifting capacity: 500 kg
• Maximum height: 405 mm
• Maximum height with overlays: 495 mm
• Scope of height adjustment of stands: 60-90 mm
• Minimum height: 95 mm
• Platform size: 450x150 mm
• Weight: 13,5 kg
• Stand spacing: max 380 mm

➡ MECHANICAL SCISSOR LIFT 500 KG

The SM-03 is a lift based on a classic screw-driven scissor mechanism. This solution allows for precise and gradual lifting of the motorcycle without the risk of sudden descent.

The mechanical design does not require the use of a hydraulic system, which simplifies operation and reduces the risk of unsealing.

➡ LIFTING RANGE 95-495 MM – LOW STARTING PROFILE

✅ The minimum height of 95 mm allows the lift to be inserted under motorcycles with reduced suspension.

✅ Maximum height 405 mm (up to 495 mm with overlays) provides convenient access to the chassis, wheels and drive components.

✅ The platform with dimensions 450 × 150 mm provides a stable base during operation.

➡ ADJUSTABLE STANDS WITH RUBBER PADS

✅ The lift is equipped with adjustable saddles with a maximum spacing of 380 mm (counting from the means).

✅ Height adjustment in the range of 60 – 90 mm allows you to adjust the support points to the structure of the motorcycle frame.

✅ Rubber overlays increase adhesion and reduce the risk of scratching the paint.

➡ POSSIBILITY OF SCREWING TO THE GROUND – GREATER STABILITY IN THE WORKSHOP

✅ The design allows permanent attachment of the lift to the floor.

✅ This solution improves stability during work requiring the use of more force, e.g. when dismantling baked elements.

✅ The weight of 13,5 kg further increases the confidence of the device setting.

➡ WHAT DISTINGUISHES A MOTORCYCLE LIFT?

✅ Lifting capacity up to 500 kg

✅ Mechanical screw drive – controlled lifting

✅ Low profile – 95 mm

✅ Maximum height up to 495 mm with overlays

✅ Adjustable and rubberized stands

✅ Possibility of anchoring to the ground

✅ Stable steel construction

➡ WHY CHOOSE THE SM-03 MODEL?

The lift will work well when lubricating the chain, replacing brake pads, dismantling wheels and working on suspension.

The screw mechanism keeps the vehicle at the set height without the use of a hydraulic system. Adjustable support points allow you to adjust the device to fit different frame designs.

This solution is suitable for both home use and workshop station.

➡ FAQ - FREQUENCY ASKED QUESTIONS

1. Is the lift suitable for heavy touring motorcycles?

• Yes, the maximum lifting capacity is 500 kg. However, you should always choose the right support points.

2. What is the minimum height when folded?

• The minimum height of the device is 95 mm.

3. Can the spacing of the stands be adjusted?

• Yes, the maximum spacing is 380 mm (from the center of the saddles), and their height is adjustable from 60 to 90 mm.

4. Can the lift be permanently installed in the garage?

• Yes, the design provides for the possibility of screwing to the ground.

5. Are rubber pads included?

• Yes, the lift is equipped with rubber overlays on the stands.

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	Stix
Parametry	Manufacturer code	23-03-54067
Parametry	Minimum lifting height	95 mm
Parametry	Maximum lifting height	495 mm
Parametry	Lifting capacity	500 kg
Parametry	Product weight with unit packaging	15 kg
Parametry	EAN (GTIN)	5907747637108
