Monitorius IIYAMA ProLite LH5565UHSB-B1 55" 4K IPS LED 24/7

Trumpai apie prekę

Prekė: Monitorius IIYAMA ProLite LH5565UHSB-B1 55" 4K IPS LED 24/7. Kategorija: Monitoriai.

• Gamintojas: iiyama
• Modelis: LH5565UHSB-B1
• Spalva: black

MONITOR DIGITAL SIGNAGE PROLITE LH5565UHSB-B1 55" 4K IPS LED 24/7

Create dynamic, eye-catching content designed to capture the attention of your audience. The LH5565UHSBo brightness of 800 cd/m² can be used in landscape or portrait orientation in 24/7 environments without any interference. Its versatility can be adapted to the needs of display in a given industry. The built-in Android 11 operating system allows you to easily customize the display to suit your needs and run a variety of third-party applications seamlessly, including multiple CMS platforms. The built-in iiSignage² (Content Management System) provides complete control over messages and advertisements in a completely remote and secure way. Signal FailOver ensures that content is actively displayed through selected inputs in mission-critical environments. The built-in (and removable) WiFi module makes this series ready to deliver content remotely over the network. The EShare application enables effective cooperation in the enterprise or school. You can now start wireless content sharing easier than ever before.

4K resolution

UHD resolution (3840x2160), also called 4K, is characterized by four times the number of pixels compared to the commonly used Full HD resolution. This is a guarantee of extraordinary sharpness and the highest image quality.

IPS

IPS technology guarantees higher contrast, the best color reproduction and greater viewing angles than the most popular TN or VA technology. The image will look good no matter what angle you look at it from.

iiSignage²

iiSignage² is the latest online platform for managing digital signage content, which enables their easy presentation and secure management of connected displays. The content management system (CMS) gives you complete control over the displayed message, remotely and securely. It does not matter if you display a menu in a restaurant that changes automatically adapting to the time of day or advertising content in your store or salon. Whether you have 2 or 150 monitors connected to your account - you control them all from one place. This is a real gamechanger in content management on large format monitors - additionally oh, completely FREE for iiyama monitors!

Appearance - ultra slim

Ultra Slim series monitors feature an ultra-thin housing frame. Therefore, they are especially recommended for creating stations consisting of several connected displays.

EShare - wireless presentation of content

EShare supports AirPlay, Chromecast, and Miracast technologies to make it easy to stream content from your device to the big screen. The client application is available for free download on all platforms. It will allow you to share your PC screen, macbook, tablet, phone in the form of an entire screen, extended screen or shared window. It also enables feedback communication for other recipients of content who can watch content presented on the screen from their devices.

VESA standard

You can mount the screen on any VESA-compliant wall or ceiling mount in a given size. This mount will also guarantee the possibility of mounting the monitor on a trolley, electric column or other VESA-compliant structures.

Working 24/7

The monitor is developed with 24/7 certification technology - means ready for continuous operation 24 hours 7 days a week. Only top-class equipment, built on selected components, can meet such criteria.

CLEAR IMAGE IN CONDITIONS OF HIGH SUNLIGHT

Thanks to its very high brightness, the panel is ideal for use in heavily lit rooms – such as store displays. The content displayed on the screen is perfectly legible, even if the light falls on it directly.

The display itself adjusts the backlight of the screen to changing external conditions, so that the image is always bright and clear.

Built-in Android OS

Thanks to Android, you can easily adjust the screen to your needs by installing dedicated applications on it.

Built-in apps and media player will allow you to get the most out of your screen right out of the box.

Fail Over for some content display management

FailOver is a feature that automatically detects input sources. When there is no signal on the default input (no signal), the screen will automatically switch the display to the next one configured in order and available source. FailOver allows customers to prioritize multiple inputs (including browsers, media players, and custom ones) and ensures that content is always actively displayed regardless of network availability/failure or internet.

SPECIFICATION:

• Diagonal: 54.6", 139cm
• Panel: IPS LED
• Physical resolution: 3840x2160 (4K)
• Image format: 16:9
• Brightness: 800 cd/m²
• Static contrast: 1200:1
• Response time: 8ms
• Angles of view: ▷ 178° △ 178°
• Working area width x H: 1209.6 x 680.4mm, 47.6 x 26.8"
• Horizontal synchronization: 28 - 160kHz
• Refreshing: 60Hz
• Colors: 1.07G (8 Bits+FRC) (NTSC 72%)
• Stain: 0.315mm
• Orientation: horizontal, vertical
• USB ports: 2x 2.0
• HDCP: v.2.2
• Digital signal inputs: HDMI x2, DisplayPort x1
• Audio outputs: Built-in speakers, Mini jack x1
• Control: RJ45 (LAN) x1, RS-232c x1 (2.5mm sub-mini jack), IR x1 (3.5mm stereo mini)
• Monitor control output: RS-232c x1
• DSO menu languages: EN, DE, FR, ES, IT, CN, RU, JP, CZ, NL, PL, SV, FI, DA, NB
• Buttons: Power supply
• WiFi: yes (Built-in, 802.11ac)
• Adjustable parameters: image (brightness, contrast,sharpness, black level, tone, color, noise reduction,gamma selection, color temperature, color control,enlarge, reset image settings), screen (magnification mode,custom magnification, reset screen settings),sound (balas, treble, bass, volume,maximum volume, minimum volume, mute,reset sound settings, synchronize audio output,speaker settings,), configuration 1 (on state,panel saving, RS232 routing, startup source,WOL, configuration reset, factory settings), configuration 2 (OSD extinction,OSD horizontal position, OSD vertical position, rotation, OSD information,logo and animations, logo settings, animation settings,Monitor ID, Group ID, Monitor Information, DP Version,DP monitors, HDMI version, configuration reset), advanced options (no signal image,remote control, power diode, overlay, timer switch,schedule, HDMI with One Wire, HDMI with One Wire Power Off,auto signal detection, language, transparency of OSD menu,energy saving, SDM settings, advanced options reset),Android settings (network and internet, applications and notifications,display, signage display, protection, language and input,date and time, about the device)
• Maximum working time without interruption: 24/7
• Media playback: yes
• Integrated software: Android 11 OS, iiSignage2, FailOver, EShare
• Plug&Play: DDC2B
• FailOver: Yes
• Frame width (sides, top, bottom): 14.9mm, 14.9mm, 14.9mm
• Standard VESA: 400 x 400mm
• Appearance: thin frames
• Housing: metal
• Fanless design: yes
• Pilot: yes
• Cables: power supply, HDMI, RS-232c
• Instructions: Quick Start Guide, Safety Manual
• Other: Mounting hole stickers, wire buckles
• Power supply: internal
• Power supply: AC 100 - 240V, 50/60Hz
• Energy consumption: 78W typically, 0.5W stand by, 0.3W off mode
• Energy consumption in operation mode: 78W
• Energy efficiency class: E
• Certificates: CE, TÜV-Bauart, RoHS support, ErP, WEEE, REACH, UKCA
• Product dimensions width x H x D: 1237.5 x 710 x 55mm
• Weight (without box): 14.6kg
• Weight (with box): 19.8kg
• Dimensions of the box width. x H x D: 1386 x 845 x 130mm
• Visible area diagonal: 139cm; 54.6"; (55" segment)
• MTBF: 50.000 hours (excluding backlight)
• Hardware: CPU: A73*4+A53*4, GPU: G52 MP8, RAM: 4GB, ROM: 32GB
• Working conditions - temperature: 0°C - 40°C
• Storage conditions - temperature: - 20°C - 60°C
• Energy efficiency class (Regulation (EU) 2017/1369): E

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	iiyama
Parametry	Model	LH5565UHSB-B1
Parametry	EAN (GTIN)	4948570123575
Parametry	Manufacturer code	LH5565UHSB-B1
Parametry	Color	black
Parametry	Backlight type	LED
Parametry	Screen diagonal (inch)	54.6"
Parametry	Native resolution	3840 x 2160 px
Parametry	Response time	8 ms
Parametry	Brightness	800 cd/m²
Parametry	Sensor type	IPS / PLS
Parametry	Screen coating	shiny
Parametry	Aspect ratio	16:9
Parametry	Static contrast (x:1)	1200
Parametry	Refresh rate	60 Hz
Parametry	Vertical viewing angle	178°
Parametry	Horizontal viewing angle	178°
Parametry	VESA Standard	400 x 400
Parametry	Design and additional components	built-in speakers
Parametry	Dot size	0.32 mm
Parametry	Ports	HDMI,DisplayPort
Parametry	Certificates	CE,ErP,REACH,RoHS,TUV,UKCA,WEEE
Parametry	Product width with base	123.75 cm
Parametry	Height of product with base	71 cm
Parametry	Depth of product with base	5.5 cm
Parametry	Weight with base	14.6 kg
Parametry	Product width	123.75 cm
Parametry	Product height	71 cm
Parametry	Product depth	5.5 cm
Parametry	Product weight	14.6 kg
Parametry	Product weight with unit packaging	19.8 kg
Parametry	Energy efficiency class	E
Parametry	Certificates of conformity	CE
