Lauko belaidis WiFi kartotuvas, 300 Mb/s, prieigos taškas

Trumpai apie prekę

Prekė: Lauko belaidis WiFi kartotuvas, 300 Mb/s, prieigos taškas. Kategorija: WiFi maršrutizatoriai ir prieigos taškai.

• Gamintojas: no brand
• Modelis: WIFI CPE Bridge

In the era of high-speed broadband, inevitably coming multi-gigabit transmissions on 5G networks of GSM operators, do you have the impression that your old WiFi works slower than the Internet? The answer to the growing need to transmit more data at higher speeds is based on Qualcomm QCA9531:

COMFAST CF-E314N V2

POE ports acting as a power supply for another POE device, and huge software functionality at an affordable price (to build bridge functionality you need to buy a second piece, or use your own access point)

• 5in1 is a standalone: accesspoint, bridge, router, repeater, switch
• support for VLAN buses (tagging and native trunk) - compatibility with other manufacturers' devices in the 802.1Q standard
• 2 LAN POE ports 48V 100/10 MBps with POE Passthrough, including one LAN/WAN port
• Link speed up to 300MBps in the 2.4GHz band; operating standards b/g/n
• antennas 14dBi 2.4GHz
• in bridge mode range up to 5KM (only for point-to-point topology in favorable conditions for two identical devices)
• directional radiation characteristics, beam width 60° horizontally, 30° vertically
• possibility of extending with further elements of the system (in point-to-multipoint topology)
• Switch IP packets from LAN/WAN to WIFi up to 95Mbps
• Support for 64/128-bit encryption WPA2-PSK
• waterproof class IP65
• WiFi channels outdoor and indoor 0,1,2,3,4,5,6,7,8,9,10,11,12,13,14,19,20,21,22,23,24,25,26,27,28,29,30,31,32,33,34,35,36,37,38,39,40,41,42,43,44,45,46,47,48,49,50,51,52,53,54,55,56,5,58,59,60,61,62,63,64,65,66,67,68,69,70,71,72,237,238,239,240,241,242,243,244,245,246,247,248,249,250,251,252,253,254,255
• very simple management of browser software SINMAX in English
• Compatible with Windows 7, Windows 7 64bit, Windows 8, Windows 8.1, Windows 10, Windows 10, Windows 11, Linux, MAC OS

The device enables comfort and superfast connection of a large number of users to the computer network including the Internet (via the operator's router). Place the access point in the free port of the switch or router of the operator, connect users to it. Communicate with an endless range of devices: TV, IP camera, phone, other computer, printer, fax machine, camera, tablet, game console, home theater, SMART household appliances or surveillance cameras

• access point CF-E314N V2 5IN1 with SINMAX system 1 pc (to build the functionality of the bridge you need to buy a second piece, or use your own access point)
• instruction manual in Polish from the distributor in Poland
• FAQ guide for beginners - also in Polish
• mounting kit (screws, pins, clamps)
• 48V 802.11af 100Mbps POE injector
• 230V cable
• LAN port cover
• mail technical support throughout the use of the device and at the first start-up
• RJ-45 cables do not belong to the set, hence we recommend purchasing them additionally on your own (we recommend at least 2 such cables of good quality)
• cameras and mounting masts shown in the pictures are not part of the offer

Matte finish of the body, and contrasting LEDs attract attention with their elegance and ensure the highest quality of electronic components. Miniaturized to the limit housing and in it a powerful processor Qualcomm QCA9531 clocked 650MHz with 64MB DDR RAM - recommended for users who value unprecedented, branded design, stability, as well as the possibility of system expansion.

• In this model, the number of internal antennas has been doubled. Thanks to this, working with the device is more convenient, the wireless network reaches further, and the signal does not fade so quickly. For users who need a bridge with higher parameters, we recommend the wide family of bridges COMFAST
• On a daily basis, you enjoy spectacular speeds in the n standard. And when you unexpectedly need to connect to an older type of network, you are still compatible with old routers a

Wireless connectivity increases productivity and comfort at a lower price (you save a lot of money on the cable). How many times have you needed internet in remote garages or in a neighboring building? Increase work efficiency and reduce its costs. Replace for short computer cables with WiFi communication. Simplify your life with the CF-E314N V2

Attract new customers with Internet access in closed building complexes, e.g. public facilities, shopping malls, playgrounds, "eagles", restaurant gardens, parks, parking lots, gardens, swimming pools, auditoriums, sports halls, aquaparks. Streamline the production process by providing high-speed internet in production or warehouse halls.

• WiFi speed N up to 300Mbps - with speeds in 2.4GHz to download huge amounts of data (4K TV, online gaming) you do not have to wait so much! Experience less buffering, the highest transmission speed

To build the functionality of the bridge, you need to buy a second piece, or use your own access point

To build the functionality of the bridge, you need to buy a second piece, or use your own access point

To build the functionality of the bridge, you need to buy a second piece, or use your own access point

• 5in1 : accesspoint, bridge, station, switch, repeater
• 2 LAN POE ports 48V 100/10 MBps with POE Passthrough, including one LAN/WAN port
• WiFi 802.11 b/g/n with WPA2-PSK encryption
• WEP/WPA1 encryption: no
• Speed up to 300MBps in the 2.4GHz band
• antennas 14dBi 2.4GHz
• transfer counters
• automatic resume of lost connection
• sensitivity -96dBm
• Transmission power: 27dBm (500mW)
• support for bridge WDS
• can be mounted on the wall or on a pipe
• own DHCP: yes
• own NAT: yes
• remote access by IP address
• watchdog
• Power consumption only 8W
• Operating environment: Permissible operating temperature:-40℃~+55℃; Permissible storage temperature:-50℃~+70℃; Permissible air humidity:10%~90% non-condensing; Permissible storage humidity:5%~95% non-condensing
• dimensions 262mm x 80mm x 53mm
• weight 316g

Specifications
