Komutatorius Lanberg 8x1Gb/s, nesuvaldomas, gigabitinis, 12V, metalinis korpusas

Trumpai apie prekę

Prekė: Komutatorius Lanberg 8x1Gb/s, nesuvaldomas, gigabitinis, 12V, metalinis korpusas. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Lanberg
• Modelis: DSM1-1008

Lanberg desktop switch – why do you need a switch at all?

At home and in the office, the number of devices “on the cable” is growing rapidly: computer, NAS, TV, console, decoder, Wi-Fi point, recorder, IP camera. If your router runs out of ports LAN or you want to improve the stability of wired connections, a good switch is the easiest way to expand your network without rebuilding your installation. Such a switch distributes traffic between devices, ensuring fast connections and predictable operation where Wi-Fi can be whimsical.

Switch Lanberg DSM1-1008 (and twin model DSM1-1005) is another iteration of Lanberg's compact desktop switches - designed to meet the real, evolving needs of users: simplicity (Plug & Play), stability, work culture and durability. In short: you plug in power and cables, and the device just works – without unnecessary configuration.

Unmanaged simple switch that does the job

The DSM1-1008 is a small size unmanaged desktop switch, prepared for home use and in SOHO and SMB environments. As an unmanaged model, it does not require logging into the panel, setting VLANs or rules – you get maximum usability “on the spot”. This is a great approach when you just want to add more ports and have peace of mind.

In practice, this means that the device is ideal for home applications and small offices: for expanding the network for a computer, printer, TV, NAS, access point or monitoring equipment. Silence also counts in this class: passive cooling and lack of a fan is comfort, especially when the switch is on the desk.

Plug & Play and switch-side automation

The DSM1-1008 operates on a Plug & Play basis, and the switch provides switching support for 8 RJ-45 ports: fast connection setup and stable operation without excessive user intervention. It is this automation that makes installation simple: you plug in the wires, and the device itself embraces the basics.

Desktop 8x port – fast network expansion without combination

At the heart of the DSM1-1008 is the 8x Gigabit RJ-45 connectors – 8 ports for your desk, shelf or backend. This is exactly what it usually takes to “unclog” the router and conveniently connect several wired devices in one place, without splitters and without compromise.

If you want a simple scenario: router → switch → 8 ports at your disposal – this type of switch is the most universal. You get 8 gigabit transmission paths in a small desktop enclosure, without redundant features that raise the price.

8 Gigabit Ethernet ports in practice

• 8 ports allows you to connect a set of key wired devices at one point.
• 8x Gigabit helps maintain high responsiveness of the local network with simultaneous movement of several devices (copies of files on NAS, 4K streaming, updates, remote work).

Gigabit and bandwidth – when liquidity in the LAN counts

In the DSM1-1008, the maximum link speed is 1 Gbps per port (1000 Mbps), and the entire device offers 10 Gbps switching bandwidth and 7 Mbit buffer. In practice: the LAN is ready for typical workloads in the home and office, and the switch does not become a bottleneck with several active devices and multiple simultaneous transmissions.

It is also worth appreciating the MAC 2K address table – switch “learns” devices (MAC auto-learning), which improves frame forwarding and stabilizes network operation in everyday scenarios. These are solutions that you will appreciate especially when you connect devices with different traffic characteristics (NAS, TV, PC, DVR) to port.

MDI/MDI-X and merger negotiation

The DSM1-1008 automatically adjusts the connection to the cabling (MDI/MDI-X), so it works for both straight or crossed cables – without separate uplink ports and without guesswork. In addition, the link is quickly combined thanks to automatic connection negotiation and support for network functions on the switch side: in practice, you get 8x 1 gbps along with automatic connection negotiation, and the configuration remains on your side "zero-one": you plug into the correct port and it works.

Flow control, or fewer problems with overload

Built-in flow control (Flow Control) allows you to manage traffic so as to reduce the risk of clogging the link – control of data flow avoiding thus congestion on the port in the case, when one of the receiving devices temporarily does not keep up with the reception. This is a practical data flow control function, especially for larger transfers or networks where several ports are sometimes charged simultaneously.

What changes the 12V power supply compared to models

gigabit ethernet desktop 5V?

In older, compact designs, queries such as ethernet desktop 5V or gigabit ethernet desktop 5V are often encountered – because many earlier models were powered by 5V. The DSM1-1008 enters the segment as an unmanaged gigabit ethernet desktop 12V and has this practical rationale: 12V is a popular standard in many installations and technical environments.

In practice, 12V voltage is present in many places - found in alarm installations and older CCTV solutions. This makes it easier to maintain a “single standard” of power supply surrounded by several devices. Arguments such as increased operating stability and better current efficiency of the device through the use of higher voltage are also often given – especially in environments where power supply is common to several elements of the system.

Metal housing – stability, durability and better cooling

What immediately distinguishes the DSM1-1008 is the housing made of steel – a real plus in everyday use. The metal switch is more resistant to accidental impacts, “wandering” around the desk or working in more technical environments (backroom, telecommunication cabinet, service office). In practice, the steel housing is also a more pleasant stability of the setting – nothing bends and the whole gives the impression of “equipment for years”.

In addition, steel helps dissipate heat, and the passive cooling solution means that the device can cool silently – without a fan, without buzzing and without sucking up dust. In practice, this means: quieter, cleaner and more stable. This is important when the desktop switch is 24/7 and has constantly active ports.

Assembly and setting

As a desktop, the DSM1-1008 naturally lands on a desk, shelf or cabinet. If you organize the wiring “technically”, you can also arrange installation under the countertop or in the building (e.g. at the cable bundle) – the metal housing tolerates such settings well, and access to ports remains convenient.

Meet the Lanberg DSM1-1008 switch – when is it the best choice?

Select DSM1-1008 if:

• you need 8 gigabit ports in a small, aesthetic desktop format (i.e. 8 ports always at hand),
• you want to “connect and forget” – unmanaged solution without configuration for home and office networks,
• you care about silence and work culture (passive cooling, without fan),
• you value durability and resistance – metal switch and steel housing make a difference,
• You are looking for a switch for your home, office, back office or small infrastructure.

This device is a solid foundation for a wired LAN: fast ports, automation, stability and a design that tolerates everyday use well. If your network is growing – this switch is a small element that makes a big difference (and a natural choice in the category of switches unmanaged from Lanberg).

Specification

• Number of Ethernet ports: 8
• Port Specification: 8x 1000BASE-T
• Maximum network link speed: 1 Gbps
• Type of network connection: Ethernet
• Management: Unmanaged
• Housing type: Desktop
• PoE support: No
• Buffer: 11 Mbit
• Capacity: 10 Gbps
• MAC address table: 2K
• Cooling: Passive
• Power Requirements: 100~240V AC 0.3A, 12V DC 1A
• Support Plug & Play: Yes
• Working signal: LED
• Wired standards: IEEE 802.3ab 1000Base-T
• Functions: Automatic MDI/MDI-X, Flow control, MAC auto-learning
• Material: Metal
• Software: No
• Length: 138 mm
• Width: 78 mm
• Height: 25 mm
• Weight: 0.23 kg
• Recommended ambient temperature: 0 - 40 °C
• Recommended ambient humidity: 10 - 90 %

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer	Lanberg
Parametry	Product weight with unit packaging	0.362 kg
Parametry	Number of ports	8
Parametry	Number of LAN (RJ-45) ports	8
Parametry	LAN port operating standard	1/10/40 Gb/s
Parametry	EAN (GTIN)	5901969447767
Parametry	Manufacturer code	DSM1-1008
Parametry	Packaging status	original
Parametry	Certificates of conformity	CE
