Išorinis 5G tinklo vartai TP-Link ER701-5G-Outdoor

Trumpai apie prekę

Prekė: Išorinis 5G tinklo vartai TP-Link ER701-5G-Outdoor. Kategorija: WiFi maršrutizatoriai ir prieigos taškai.

• Gamintojas: TP-Link
• Modelis: ER701-5G-Outdoor

ER701-5G-Outdoor

• 5G NR up to 7,01 Gbps (SA) / 4,5 Gbps (NSA)
• Support for 2 Nano SIM card slots ensures business continuity of the corporate network
• 1 RJ45 2,5G PoE In port (PoE adapter included)
• 9 internal cellular network antennas and 1 internal Wi-Fi network antenna - The Wi-Fi interface is used for local management purposes only.
• Setting antennas with the app for optimal 5G network performance
• One-click setup in Omada SDN
• Can be mounted on a Pole, Wall or Window
• Centralized management in the cloud
• Protection class IP66

NOTE:

The Wi-Fi interface is used for local management purposes only.

TECHNICAL SPECIFICATIONS

CELLULAR NETWORK

Network Mode:

• 5G NR: N1/N3/N5/N7/N8/N20/N26/N28/N38/N40/N41/N75/N76/N77/N78 (2100/1800/850/2600/900/800/850/700/2600/2300/2500/1500/1450/3700/3500 MHz)
• 4G FDD-LTE: B1/B3/B5/B7/B8/B20/B26/B28/B32 (2100/1800/850/2600/900/800/850/700/1500 MHz)
• 4G TDD-LTE: B38/B40/B41/B42/B43 (2600/2300/2500/3500/3700 MHz)
• 3G WCDMA: B1/B5/B8 (2100/850/900 MHz)

Speed:

• 5G NR:

  SA Downlink: 7.01 Gb/s, Uplink: 1.25 Gb/s

  NSA Downlink: 4.5 Gb/s, Uplink: 730 Mb/s

• 4G LTE:

  Downlink: 1.6 Gb/s, Uplink: 211 Mb/s

SIM Card Size:

• Dual Nano SIM Slots (Dual SIM)

TRANSMISSION SECURITY

DPI:

• Deep Packet Inspection

Access Control:

• Source/Destination IP Address Based Access Control

Filtering:

• Web Group Filtering (Standalone Mode Only)
• URL Filtering
• Web Protection (Standalone Mode Only)

ARP Attack Defense:

• GARP Packet Sending
• ARP Scanning (Standalone Mode Only)
• IP-MAC Binding

Network Attack Defense:

• TCP/UDP/ICMP Flood Defense
• TCP Scan Blocking (Stealth FIN/Xmas/Null)
• WAN Ping Blocking

HARDWARE FEATURES

Ports:

• 1 x 2.5G RJ45 Port

Network Cabling:

• 10BASE-T: UTP category 3, 4, 5 cable (max 100m), EIA/TIA-568 100Ω STP (max 100m)
• 100BASE-TX: UTP category 5, 5e cable (max 100m), EIA/TIA-568 100Ω STP (max 100m)
• 1000BASE-T: UTP category 5, 5e, 6 cable (max 100m)
• 2500BASE-T: UTP category 5, 5e, 6 cable (max 100m)

Buttons:

• Reset

Power Supply:

• 802.3at PoE: 42–57V 0.6A
• Passive PoE: 48V 0.375A

Flash Memory:

• 4GB eMMC Flash

DRAM Memory:

• 2GB LPDDR4x

LED Indicators:

• System, Network Type, Signal Strength

Dimensions (W x D x H):

• 7.2 × 4.3 × 1.4 inches (183 × 110 × 36 mm)

Antennas:

• 9 Internal Cellular Antennas
• 1 Internal Wi-Fi Antenna

SIM Slot:

• Dual Nano SIM Slots (Dual SIM)

Mounting:

• Wall Mount
• Pole Mount
• Window Mount

Max Power Consumption:

• 15.3 W (802.3at PoE or Passive PoE)

PERFORMANCE

• Concurrent Sessions: 500,000
• New Sessions Per Second: 6,100

WIRELESS TRANSMISSION FEATURES

Wireless Speed:

• 2.4 GHz: 150 Mbps

Wireless Devices:

• 802.11n: 6.5 Mbps to 150 Mbps (MCS0–MCS7, HT20/40)
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11b: 1, 2, 5.5, 11 Mbps

Advanced Features:

• Encryption: WPA/WPA2 Personal
• SSID: 1
• Transmitter On/Off
• SSID Broadcast On/Off
• Auto Channel Selection
• Transmit Power Control (dBm)

BASIC FUNCTIONS

WAN Connection Type:

• 5G / 4G / 3G

DHCP:

• DHCP Server
• DHCPv6 PD Server (Standalone Mode Only)
• DHCP Option Customization
• DHCP Address Reservation
• Multi-IP Interfaces
• Multi-Net DHCP

Stateful ACL:

• Yes

Quality of Service:

• Yes

Bridge VLAN:

• Yes

SMS:

• SMS Receive / Send

VLAN:

• 802.1Q VLAN

ADVANCED FUNCTIONS

Bandwidth Control:

• IP-Based Bandwidth Control

NAT:

• Multi-Net NAT
• Virtual Server
• Port Triggering
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG
• UPnP

Routing:

• Static Routing
• OSPF

Session Limit:

• IP-Based Session Limit

AUTHENTICATION

Network Authentication:

• No Authentication
• Simple Password
• Hotspot (Local User / Voucher / SMS / RADIUS)
• External RADIUS Server
• External Portal Server
• LDAP

MANAGEMENT

Omada App:

• Yes

Centralized Management:

• Omada Cloud SDN
• Omada Hardware Controller
• Omada Software Controller
• Omada App

Cloud Access:

• Yes

Services:

• Dynamic DNS (DynDNS, No-IP, Peanuthull, Comexe, DDNS Configuration)

Support:

• Web Interface
• Remote Management
• Configuration Export/Import
• SNMP v1/v2c/v3
• Diagnostics (Ping, Traceroute)
• NTP Synchronization
• Port Mirroring
• CLI (Standalone Mode Only)
• Syslog

Panel Features:

• Auto Device Discovery
• Network Monitoring
• Alerts
• Unified Configuration
• Reboot Schedule
• Captive Portal

OTHERS

Default Enabled Services:

Web Server

• HTTP/HTTPS Management
• Port: 80/443 (TCP)

TDP Server

• Device Discovery
• Port: 20003 (UDP)

DHCP Server

• IP Assignment
• Port: 67 (UDP)

DNS

• Name Resolution
• Port: 53 (TCP/UDP)

Certifications:

• CE, NCC, BSMI, RoHS

Package Contents:

• ER701-5G-Outdoor
• Passive PoE Adapter
• Mounting Kit
• Sealing Kit
• Quick Installation Guide

System Requirements:

• Windows 98SE/NT/2000/XP/Vista/7/8/8.1/10/11
• Mac OS, NetWare, UNIX, Linux

Working Environment:

• Operating Temperature: -22°F to 140°F (-30°C to 60°C)
• Storage Temperature: -40°C to 70°C (-40°F to 158°F)
• Operating Humidity: 5–95% non-condensing
• Storage Humidity: 5–90% non-condensing
• Surge Protection: 6 kV
