IP vaizdo kamera Hikvision DS-2CD2083G2-LI2U/SL, 2.8 mm, juoda

Trumpai apie prekę

Prekė: IP vaizdo kamera Hikvision DS-2CD2083G2-LI2U/SL, 2.8 mm, juoda. Kategorija: IP kameros.

• Gamintojas: Hikvision
• Modelis: DS-2CD2083G2-LI2U/SL(2.8MM)(BLACK)/PL

887,30

55661

IP camera Hikvision DS-2CD2083G2-LI2U/SL 2.8mm BLACK PL

Model: DS-2CD2083G2-LI2U/SL 2.8mm BLACK PL

The most important features

• High-quality image in 8 MP resolution
• AcuSense: Focus on classifying people and vehicles based on deep learning
• Smart Hybrid Lighting: Integrated infrared and white lights, 3 additional lighting modes
• Built-in dual microphone for high-quality real-time audio
• Clear imaging in case of strong taillight thanks to true WDR 120 dB technology
• Powerful H.265+ compression technology
• Water and dust resistance (IP67)

Technical specification

Model

DS-2CD2083G2-LI2U/SL 2.8 mm Black

Manufacturer

Hikvision

Image transducer

1/2.8" Progressive Scan CMOS

Max. resolution

3840 × 2160

Min. lighting

0,005 lux @F1.6, AGC ON; 0 lux with IR

Shutter speed

1/3 s - 1/100 000 s

Day/Night

IR filter

Camera setting

0-360° rotation, 0-90° tilt, 0-360° rotation

Lens type

Fixed focal length: 2.8 mm

Field of view 2.8 mm

H: 108°, V: 59°, D: 127°

Fastening

M12

Aperture type

Fixed

Aperture

F1.6

Depth of field 2.8 mm

1,7 m - ∞

DORI 2.8 mm

D: 84 m, O: 33 m, R: 16 m, I: 8 m

Illuminator

IR + white light

Illuminator range

Up to 40 m

Smart Light

Yes

IR wavelength

850 nm

Main stream 50 Hz

20 fps (4K), 25 fps (1800p-720p)

Main stream 60 Hz

20 fps (4K), 30 fps (1800p-720p)

Substream 50 Hz

25 fps (720p/480p/360p)

60 Hz substream

30 fps (720p/480p/360p)

Third stream

10 fps (1080p-360p)

Video compression

H.265/H.265+/H.264/H.264+/MJPEG

Bitrate video

32 Kbps - 16 Mbps

Profile H.264

Baseline / Main / High

Profile H.265

Main

ROI

1 region

SVC

Yes

Trimming the target

Yes

Audio compression

G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC

Bitrate audio

64/16/16/32-192/8-320/16-64 Kbps

Audio Frequency

8 / 16 / 32 / 48 kHz

Noise reduction

Yes

Network protocols

TCP/IP, HTTP/HTTPS, RTSP/RTP/RTCP, NTP, FTP, DHCP, DNS, DDNS, SMTP, IPv4/IPv6, TLS 1.1-1.3

Simultaneous preview

Up to 6

API

ONVIF S/G, ISAPI, SDK, ISUP

Users

32 (admin/operator/user)

Safeguards

HTTPS, 802.1X, IP filtering, strong password, logs

Network memory

US (NFS/SMB), ANR

Browsers

IE11 (plugin), Chrome 80+, Firefox 80+, Edge 89+, Safari 13+

WDR

120 dB

SNR

≥ 52 dB

Day/night mode

Auto / manual / schedule

Image improvement

BC, HLC, 3D DNR

Masks of privacy

8

Ethernet

1× RJ-45 10/100M

SD card slot

microSD/microSDHC/microSDXC up to 512 GB

Built-in microphone

Dual Matrix Microphone

Built-in speaker

2 W, 110 dB @10 cm

Reset

Yes

Basic events

Traffic (man/vehicle), sabotage, exception

Perimeter protection

Line crossing, intrusion (AI)

Power supply

12 VDC 1,25 A (15 W) / PoE 802.3at (18 W)

Material

Metal

Dimensions

Ø74,4 × 176,3 mm

Package Dimensions

234 × 120 × 117 mm

Weight

515 g

Weight with packaging

760 g

Working conditions

-30°C...60°C, ≤95% RH

Storage conditions

-30°C...60°C, ≤95% RH

Language

Polish

General functions

Heartbeat, mirror, flash log, password reset, pixel counter, anti-banding

Flashing light

SRB: red-blue, other: white

EMC

EN 55032, EN 50130-4, EN 61000-3-2/-3-3, RCM, IC, KC

Security

IEC/EN/UL 62368-1

Environment

RoHS, WEEE, REACH

Protection

IP67

Specifications
