Įkroviklis AMIO su ekranu geliniams akumuliatoriams, 6/12V, 4A

Trumpai apie prekę

Prekė: Įkroviklis AMIO su ekranu geliniams akumuliatoriams, 6/12V, 4A. Kategorija: Baterijų įkrovikliai.

• Gamintojas: no brand
• Modelis: 6/12V - 4A LCD

The DBC-4A rectifier can charge lead-acid batteries (regular and MF), Ca/Ca, AGM and gel batteries. It is a microprocessor rectifier, made in accordance with the IP65 standard, which means resistance to dust and splashes and low pressure water jet dousing. It has protection against:

short circuit

reverse battery connection (reverse polarity)

open circuit

protection against sparks

battery overcharging

rectifier overload

overheating of the rectifier

It has 6 charging modes:

6V to 14Ah batteries

7.2V to 2A

7.4V to 2A (low temperature charging)

12V to 14Ah batteries and deeply discharged

14.3V to 2A

14.7V to 2A (low temperature charging)

12V batteries over 14Ah

14.3V to 4A

14.7V to 4A (low temperature charging)

It shows the battery voltage and the degree of charge on an ongoing basis and adjusts the charging current depending on its needs. Once charged, it displays a FULL message and maintains the voltage on the battery.

Specification:

Supply Voltage 230V 50 Hz

Output Voltage: 6/12V

Power consumption: about 60W (1W standby)

Maximum charging voltage:

7.4V (6V batteries)

14.7V (12V batteries)

Maximum charging current:

2A +/- 10%,

4A +/- 10%

Supported battery capacities:

6V - 1,2Ah to 14Ah

12V - 1,2Ah to 14Ah and 14Ah to 120Ah

Degree of protection: IP65

6 charging programs switched by the "WORKING MODE" button

Display backlight

Gel batteries with a capacity of up to 14Ah used in motorcycles and scooters should be charged by selecting a program with the motorcycle icon on the display.

Charging with more current can damage the battery.
