Grandininis keltuvas 1000 kg 3 m

Trumpai apie prekę

Prekė: Grandininis keltuvas 1000 kg 3 m. Kategorija: Grandinė.

• Gamintojas: Steinberg Systems
• Modelis: SBS-FZ 1000/3M

⭐⭐⭐⭐⭐

Steinberg Systems ®

✅ Model: SBS-FZ 1000/3M

✅ Catalog No.: 10030375

✅ Product Condition: New

➡ The most important features of the product:

• Capacity – load capacity up to 1000 kg
• Versatility – range up to 3 m
• Manual operation – works without power
• Belaying – two swivel hooks made of steel
• Strength – strong steel chain with a diameter of 6 mm

✅ Technical specification:

• User manual - Yes
• Maximum lifting height - 3 m
• Maximum lifting capacity - 1000 kg
• Material - Alloy steel, Cold rolled steel sheet
• Colour - Red
• Brake -
• Clutch -
• Transmission -
• Chain type - G80
• Rope material -
• Package height [cm] - 21
• Package length [cm] - 25
• Package width [cm] - 18
• Package weight [kg] - 9.7
• Product height [cm] - 13
• Product length [cm] - 23.5
• Product width [cm] - 14.5
• Product weight [kg] - 9.26
• Number of packages - 1

✅ Chain winch - 1000 kg - 3 m

The Steinberg Systems chain winch is a device used for lifting and lowering various objects on construction sites, in workshops, industrial plants and for unloading and handling goods. The SBS-FZ 1000/3M is a reliable equipment with high performance and safety.

✅ Chain hoist – characteristics

High strength is the strength of the chain lift from Steinberg Systems. The range of up to 3 m allows you to place the equipment under the ceiling, which allows you to work in rooms of standard height. The device is able to lift a load of up to 1000 kg. Robust chain type G80 with a diameter of 6 mm links, despite its light weight, is characterized by extremely high load capacity. The chain hoist is made of high-quality steel, so it is durable, resistant to wear and tear, and has a long lifespan.

Operational safety is ensured by two solid steel swivel hooks. The handle on which we hang the load has been equipped with a safety ratchet to protect against the ejection of the lifted / lowered object. With the help of a second hook, a gear is placed on the supporting structure. In the event of accidental release of the chain, the safety mechanism is activated and the operation of the equipment is interrupted. The load-bearing chain is blocked and the weight stops at a given height.

Manual operation is cost-free and very convenient. It makes the chain winch suitable for use wherever there is no access to a power source. Lifting and lowering weights only requires pulling the hand chain (also referred to as maneuvering). In this way, it sets in motion a gear with a load-bearing chain, whose role is to maintain weight.

Chain winch SBS-FZ 1000/3M is a equipment valued in industries where it is necessary to transport various loads. If you want to remove the engine from the car, unload the goods, move the steel structure, use the simplest solution – the Steinberg Systems product!

✅ Contents of the shipment:

• Chain winch
• User manual
