Freza Mafell FM 1000, 9M0001

Trumpai apie prekę

Prekė: Freza Mafell FM 1000, 9M0001. Kategorija: Frezos.

• Gamintojas: Mafell
• Modelis: 9M0001

The subject of the sale is:

Milling drive Mafell FM 1000

Technical data:

• Nominal input power (W): 1000
• Nominal speed - no load (1/min): 4000-25000
• Clamp Flange/Handle (mm): 43/6
• Dimensions (W) (mm): 254x79x73
• Noise level (DB(A)): ≤ 75
• Weight (kg): 1,65

Application:

• Portal milling machines
• milling hammers
• cutting tables
• grinding equipment

Scope of delivery:

• 1 universal clamping sleeve 8 mm
• 1 nut
• 1 key to service
• 1 power cable 4 m

Product Features:

Labyrinth seal: spindle protection and bearing permanently with the smallest particulate matter, dust and chips

Spindle lock: for simple and convenient tool change, the spindle can be locked at the push of a button

Double bearing spindle: closed double ball bearing is used for better absorption of axial forces

Settlement handle: A universal clamp holder is used to hold standard tools,

Adjustable digital electronics: The speed can be infinitely adjusted to suit any application. In addition, digital electronics are equipped with a gentle start-up, reduction of idling speed, constant rotational speed under load and overload protection

Top-beating accuracy: MAFELL milling motors impress with the highest beating accuracy < 0,05 mm at a distance of 25 mm (in a cone < 0,01 mm). Responsible for this extraordinary precision is the filigree coordination of all elements and the fact that the fittings and spindle are produced and balanced in one piece
