Elektrinis paspirtukas Mihogo Air Max, 900W, 48V 19.2Ah, 40 km/val., APP ir GPS

Trumpai apie prekę

Prekė: Elektrinis paspirtukas Mihogo Air Max, 900W, 48V 19.2Ah, 40 km/val., APP ir GPS. Kategorija: Elektriniai automobiliai.

• Gamintojas: no brand
• Modelis: Air Max 19.2AH +APP 9331194758653-MN
• Svoris: 37 kg
• Spalva: beige

26 x 2.5-inch Mihogo Air Max features a high-quality carbon fibre T800 frame for an ultra-lightweight urban Electric Vehicles (3.5 kg frame weight), equipped with a 750W motor (peak 900W), dual 9.6Ah batteries (total 19.2Ah), and a maximum speed of 40 km/h. It also features four-piston hydraulic disc brakes with a power-off function and dual-arm torque sensors.

• Ultra-light carbon fibre frame
• Four-piston hydraulic disc brakes
• Torque sensor
• High-efficiency engine
• High-performance battery 19.2AH battery
• MIHOGO APP smart application

Mihogo Air Max

Tires：26*2.5 color tire

Frame:26-inch Carbon T800 frame

Headset:Aluminum alloy hidden-wire bearing headset

Fork:Aluminum alloy hydraulic shock-absorbing front fork (suspension travel 60mm) with 100mm opening width

Battery:48V 9.6AH*2（Total 19.2AH）

Motor: 750W (peak 900W)

Maximum speed: 40 km/h

Rear Derailleur：shimano M310

Shifters：shimano SL-M315-7R

Rear Cogs：shimano 500-7speed

Chain：KMC 134links

Crank：Aluminum alloy 52T

Sensor：Torque Sensor LDS BBTS3PSD

Brakes：Four-piston hydraulic disc brake with power cut-off

Brake Levers：Aluminum alloy three-finger brake lever

Front Hub：Aluminum alloy integrated wheel with dual bearings (detachable axle M10*100*185mm)

Rims：20 inch spoke Aluminum alloy wheel

Spokes：12g

Net Weight：26.7KG

Payload：120KG

Suitable height: 155 cm-195 cm

Torque Sensor

Air uses a non-contact bidirectional torque sensor, which is highly sensitive, operates with virtually no lag, has high output linearity, and offers excellent tracking performance. Compared to traditional speed sensors and traditional torque sensors, it provides a smoother, more energy-efficient, and more comfortable driving experience. Additionally, compared to a single torque sensor system, battery range is significantly improved by 23%, and compared to a speed sensor system, range is improved by a remarkable 105%. Your journey is longer and more energy-efficient.

DUAL BATTERIES 121 MILES

Super Long Endurance: To continue challenging the super long endurance of transportation tools, the MIHOGO AIR model is equipped with front and rear hidden dual batteries for long endurance Electric Vehicles, with a total battery capacity close to 1386WH. It also has dual torque sensing drive on both sides, and the total weight of the vehicle is only 0.66 of traditional aluminum, effectively improving riding efficiency and saving electricity. The longest endurance can reach an impressive 128 miles.

central control technology

MIHOGO AIR uses a centralized intelligent control drive technology, which can stimulate the operational efficiency of the motor. The dual-battery automatic detection module can read the voltage values of the two batteries more than 1000 times per second. Users can complete the automatic switching of the two batteries without changing the battery, and the ultra-long endurance of over 128 miles is verified using this technology. The intelligent app and IPV color screen provide a stable Bluetooth connection, and the instrument panel is equipped with navigation mapping functions to meet the navigation assistance for long-distance travel.

COMPACT SMART LIGHTING DESICN

Compact Smart Lighting Design: MIHOGO AIR equips with front dual light heads for night, which increases the effective range by 57%. The rear frame lights on both side are designed with 15 inches embedded LED light for day riding and the taillight is integrated with embedded LED lights, which can ensure the safety for riding every time.

FLEXIBLE HUMAN-MACHINE POSTURE ADJUSTMENT

Flexible Human-Machine Posture Adjustment: Considering for the different requirements of riders, MIHOGO AIR has designed with 3 adjustable positions for posture and riding height throughout the entire journey and equipped with curved adjustable handle bar, which makes every user can ride the Electric Vehicles more easily. The front shock absorber can be manually adjusted for softness to adapt to different road conditions.

EVERY DETAIL IS CRAFTSMAN ART

Every Detail is Craftsman Art: MIHOGO AIR offers a close-up of every detail, with no welding on the surface of the carbon fiber frame with minimalist and lightweight hydraulic brake system, tight engineering coordination in every aspect. Mihogo Air uses hand sewn leather covers for handle and seats, which is full of artistic style.

MIHOGO APP

Stay ahead with real-time vehicle data, enjoy the convenience of a digital key, effortlessly track your Electric Vehicles location, and unlock a whole array of incredible features at your fingertips.

Smart Notifications

Receive intelligent alerts for messages and calls.

Password Lock and Proximity Unlock

Set a password for added security and enjoy automatic unlocking when your phone is nearby.

Smartphone Navigation Projection

Project your smartphone's navigation onto the dashboard.

Wheel size：kenda 20*4.0"

A-Seat tube：416MM

B-Seat tube angle：75.5°

C-Head tube：150MM

D-Head angle：72°

E-Top tubelength：465MM

F-Standover height：560MM

G-BB drop：87MM

H-Rear Center：479MM

I-Wheelbase：1150MM

J-Reach：375MM

K-Stack:440MM

L-Maximum seat height:1030MM

M-Minimum seat height:880MM

N-Rear rack height:645MM

O-Totallength:1730MM

P-Handlebar height:1200-1320MM

Q-Handlebar length:640MM

R-Rear rack length:50kg

S-sear rack outer diameter length:375MM

T-Rear rack width:165MM

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	Without VAT invoice
Parametry	Product weight with unit packaging	26.7 kg
Parametry	Gender	unisex product
Parametry	EAN (GTIN)	9331194758653
Parametry	Certificates of conformity	CE
Parametry	Year of manufacture	2025
Parametry	Shock absorption	front
Parametry	Pedals	click-in
Parametry	Derailleur type	internal (hub)
Parametry	Brakes	hydraulic disc
Parametry	Number of gears	7
Parametry	Engine power	750 W
Parametry	Motor location	in rear hub
Parametry	Charging time	7 h
Parametry	Crank	single row
Parametry	Motor type	przekładniowy
Parametry	Rechargeable battery	lithium-ion
Parametry	Maximum load	120 kg
Parametry	Maximum speed	40 km/h
Parametry	Range	100 km
Parametry	Accessory equipment	rack,fenders,meter,lighting,electrically-assisted
Parametry	Model	Air Max 19.2AH +APP 9331194758653-MN
Parametry	Kind	urban
Parametry	Manufacturer code	9331194758653
Parametry	Brand	no brand
Parametry	Weight	37 kg
Parametry	User height	155–195 cm
Parametry	Color	beige
Parametry	Frame material	carbon
Parametry	Frame size	L
Parametry	Wheel size (")	26
