Diagnostikos sąsaja ELM 327 WiFi OBD2 ANDROID IOS iPhone

Trumpai apie prekę

Prekė: Diagnostikos sąsaja ELM 327 WiFi OBD2 ANDROID IOS iPhone. Kategorija: Diagnostikos testeriai ir sąsajos.

• Gamintojas: ELM
• Modelis: 709998238647

ELM327 WiFi OBD2 Car Diagnostic Scanner Support for iPhone/ipad for Android

Car diagnostic interface obd2 ver.2021

____ELM327 version with WiFI____

The version with wifi connection means longer connection distances, faster data transfer rates, and at the same time greater stability of operation.

This interface supports almost most cars with obd2.

Universal device.

Important information:

Wifi and Bluetooth provide wireless communication via radio signals. However, the main difference between Bluetooth and Wi-Fi is the purpose for which they were designed. This is because Bluetooth is used to connect short-range devices. Wifi, however, offers high-speed wireless Internet access.

Thanks to Bluetooth technology, we can wirelessly connect our device to a limited number of other devices (peer-to-peer connections). However, Wi-Fi provides internet access to multiple users at the same time, and it is also wireless.

The interface works with all desktop computers, laptops running Windows 95, 98, Me, XP, 2000, Vista, 7,8,10, smartphones with android, IOS, WinCE, Symbian and in every version.

Soon we will post photos from the operation of the interface with several programs from the following list of cooperating programs:SDPROG PL, TORQUE PRO - ON ANDROID SYMBIAN WINDOWS MOBILE,PCMSCAN, Maxitest, MAXIECU, ScanXL-ELM,DashCommand-ELM, GM Mode 22 Scan Tool by TerryOBD Gauge for PalmOS and Pocket PC by Dana Peters, OBD Logger by Jonathan SenkerikOBD-II ScanMaster by Vladimir Gurskij, obd2crazy.comScanTool.net, OBD Gauge for Palm OS,ScanTest for Pocket PC, ScanMaster-ELM,ScanXL, FiatEcuScan, MultiEcuScan, OPELtestPL,SDPROG PL,Piston OBD2 etc.

It can cooperate according to customer reviews with CARISTA, EOBD FACILE, BIMMERTOOOL.

The subject of sale is the device.

Interface capabilities:

• Reading and deleting detected errors (explained even in Polish - depending on the program used)
• Delete inspections and Check controls
• Preview of live engine operating parameters (rotation, temperature, pressure... from every possible sensor
• Preview of frozen frames
• Checking the meaning of error codes
• Measurement of engine power, acceleration time up to 100km/h

An example of how the interface with TORQUE works in the polish version, how to choose the interface and photos from the action

An example of working with a program downloaded from google play, the with Polish, finds errors. deletes, possible preview of data in real mode, etc.

Another program with a program downloaded from google play, the with Polish, finds errors. deletes, possible preview of data in real mode, etc.

Another program with a program downloaded from google play, the with Polish, finds errors. deletes, possible preview of data in real mode, etc.

Another program with a program downloaded from google play program finds errors, deletes, possible preview of data in real mode, etc.

_________________________________________________________

AN INTERFACE TEST IS ALSO POSSIBLE - AS YOU CAN SEE "VERY GOOD"

Subsequent discharges

Another program downloaded from google play, the with Polish, finds errors. deletes, possible preview of data in real mode, etc.

Connects and works after WiFi with bimmer-tool (BTool)

Connects and works after Wi-Fi with bimmer-tool (BTool)

Compatible vehicles:

for BMW 2001/02/03 W203 C200K (ISO)

for BMW X5 2002 (ISO) Chevrolet Aveo (ISO)

for Citroen C3 2004 (ISO) Daihatsu YRV 2005 (ISO)

for Daihatsu YRV Turbo 2006 (ISO)

for Fiat Tipo 2002 (ISO)

Ford New Focus 2006 (CAN)

for Honda Accord 2006 JDM (ISO)

for Honda Accord Euro R 2004 JDM (ISO)

for Honda City GD8 (ISO)

for Honda Civic ES 1.6A (ISO)

for Honda Integra Type R DC5 JDM (ISO)

for Honda Jazz 1.4M (ISO)

for Hyundai Accent 2004 (ISO)

for Hyundai Getz 1.3A 2004 (ISO)

for Hyundai Getz 1.6M 2004 (ISO)

for Hyundai Matrix 2004 (ISO)

for Hyundai Santa Fe 2.4A (ISO)

for Hyundai Sonata GLS (ISO)

for Hyundai Sonata 2005 (ISO)

for Hyundai Tuscani FX (ISO)

for Kia Carens 2005 (ISO)

for Kia Magentis 2005 (ISO)

for Kia Rio LS (ISO)

for the Kia Sorento SUV 2005 (ISO)

for Lexus es300

for Mazda 2 (CAN)

for Mazda 5 (CAN)

for Mazda 6 (CAN)

for Mazda Premacy 2001 (ISO)

for Mazda RX8 (CAN)

for Mitsubishi Colt 2003 (ISO)

for Mitsubishi Colt Plus 2005 (ISO)

for Mitsubishi Eclipse (GST ----- Turbo Car can be tested in 1995-2000; RS/GS ---- 1994-1996 GS can do;

speed and TPS, DTCS can be cleaned)

for Mitsubishi Lancer IX 2006 (ISO)

for Mitsubishi Pajero 3.5 V6 2006 (ISO)

for Nissan Sunny B14 (ISO)

for Nissan Sunny VIP FB15 (ISO)

for Nissan X-Trail 2.0L 2004 (ISO)

for Nissan X-Trail 2.5L 2004 (ISO)

for Peugeot 206 2001 - Show only RPM

for Peugeot 206 (ISO)

for Peugeot 307 (ISO)

for Peugeot 407 (ISO)

for Renault Megane II 2005 (ISO)

for Renault Kangoo 2006 (ISO)

for Subaru Impreza 1.6TS 2002 (ISO)

for Subaru Impreza WRX 2005 (ISO)

for Totota Camry 2.0A 2004 (ISO)

for Tototo Camry 2.4A 2005 (ISO)

for Tototo Corolla Altis 1.6A 2005 (ISO)

for Tototo Corolla GLXi G8 1999 (ISO)

for Tototo Corolla G9 2002 (ISO)

for Totota Vios 2004 (ISO)

Veichles not available:

for Mazda 323 Protege 2003 (OBD-I)

for Mitsubishi Lancer 1.6M 2006

for Nissan Sunny (N16)

for Nissan Cefiro (Teana) 2005

for Nissan sentra 1.8 2000/2005

for Nissan Cefiro (Teana) 2005

for Proton Perdana V6

for Subaru Legacy GT 2005

for Toyota camry 2002

for Toyota Wish JDM (Missing Pin 5 in DLC)

for Toyota IST JDM (Missing Pin 5 in DLC)

for Toyota altis 1.8 2004

for Peugeot 206 2000

for Suzuki Jimny 1.3 2000

Mini OBD2 Wifi scanner technical data:

SSID: WiFi_OBDII

IP address: 192.168.0.10

Port: 35000

Communication: WIFI

Main system: without PIC18F25K80

Support system: IOS, Android, Symbian, Windows

Operating Voltage: 9v~16v

Operating Current: 65mA

Standby Current: 45mA

Operating temperature: -40 ℃ ~ 85 ℃

Operating Humidity: Less than 60%

Size: 43mm*25mm*30mm

Compatible systems:

Software support platform: Windows XP, Windows 7/8, IOS, Android, Symbian.

Specifications
