Belaidis prieigos taškas COMFAST CF-E320N V2.0, 2.4GHz, 300Mbps, 2x 3dBi

Trumpai apie prekę

Prekė: Belaidis prieigos taškas COMFAST CF-E320N V2.0, 2.4GHz, 300Mbps, 2x 3dBi. Kategorija: WiFi maršrutizatoriai ir prieigos taškai.

• Gamintojas: Comfast
• Modelis: CF-E320N V2.0

WiFi Marketing Platform

Based on OpenWRT:

• High stability thanks to U-boot architecture
• Compatible with most WiFi marketing systems
• Possibility to personalize marketing campaigns:

  Captive

  Authorization via social media

  Targeted advertisements

  Collection of demographic data

Watchdog Features

Intelligent supervisory system:

• Automatic detection and repair of faults
• Three modes of restoration:

  Automatic reset when system is suspended

  Planned restarts for optimal performance

  Instant response to critical errors

Software updates

• Hassle-free firmware updates
• Possibility of remote management
• Backward compatibility
• Secure update process

Applications:

• Hotspots in shopping centers
• Hotel networks
• M2M (Machine-to-Machine) systems
• IoT infrastructure that requires high availability

Professional protection against atmospheric discharges

Integrated anti-overvoltage solutions:

• Specialized surge arresters in ports:

  Powering

  Network (WAN/LAN)

• Built-in lightning capacitors:

  Absorb voltage spikes

  Protect electronic circuits

  Protect against induced surges

Intelligent management of WiFi channels

Automatic interference avoidance:

• Dynamic channel change (1, 3, 6, 12)
• Continuous analysis of interference in the radio environment
• Seamless roaming between access points
• Zero packet loss during switching

OrangeOS Multi-Function Platform

Four in one:

Advanced multi-WAN router

• Load balancing
• Overlapping capacity
• Automatic failover

Intelligent bandwidth management

• QoS (Quality of Service)
• Bandwidth control
• Prioritization of traffic

AC management system

• Plug & Play for Access Points
• Central configuration
• Network health monitoring

Marketing authentication system

• Local Authorization Portal
• Personalized login pages
• Integration with CRM systems

Safety features

• Integrated firewall
• Advanced management of network behavior
• VPN support (virtual private networks)
• Protection against DDoS attacks

Plug & Play function

Automatic configuration:

• Automatic detection and connection to access points
• Intelligent optimization of network parameters
• Instant access to the Internet when connected

Advanced Group Opportunities

Managing a fleet of devices:

• Access point grouping function
• Unified configuration for all APs in a group
• Collective software updates
• Real-time status monitoring:

  Network load

  Data flow

  Information about connected clients

Friendly management interface

Key advantages:

• Intuitive configuration panel
• Compatibility with multiple platforms
• Possibility of remote management
• Network state visualization:

  Cover map

  Band utilization charts

  Connection statistics

Benefits for administrators:

• Reduced network deployment time
• Simplified technical support
• Ability to manage thousands of devices
• Comprehensive network monitoring

The system is ideal for: hotels, campuses, shopping malls and other extensive WiFi installations.

Version comparison

• Parameter, CF-E320N, CF-E320N V2
• Processor, MT7620N, QCA9533
• RAM, 64MB DDR, 64MB DDR
• Flash Memory, 8MB, 16MB
• Standards WiFi, 802.11b/g/n, 802.11b/g/n
• Antennas, 2 built-in 3dBi, 2 built-in 3dBi

Radio parameters

• Output Power: 110mW (19dBm)
• Reception Sensitivity: -96dBm
• Frequency band: 2.4GHz-2.4835GHz

Physical interfaces

• Network ports:

  1 × WAN 10/100Mbps

  1 × LAN 10/100Mbps

Physical characteristics

• Package Dimensions: 330 × 224 × 45 mm
• Weight: 0.30 kg
• Protection Class: IP41
• Surge protection: 6kV

Working environment

• Parameter: Value
• Working temperature: -10°C ~ 65°C
• Working humidity: 10%~90% RH (non-condensing)
• Storage temperature: -40°C ~ 70°C
• Storage humidity: 5%~90% RH (non-condensing)

Note: The V2 version offers better performance with the newer QCA9533 chipset and doubled Flash memory compared to the basic version.
