Automobilinis žirklinis keltuvas INVENTO 3T 400 V 1 m

Trumpai apie prekę

Prekė: Automobilinis žirklinis keltuvas INVENTO 3T 400 V 1 m. Kategorija: Žirkliniai keltuvai.

• Gamintojas: Invento
• Modelis: INVSLS30

Technical data:

• Lifting capacity 3 000 kg
• Lifting height 1 000 mm
• Minimum height 110 mm
• Platform length 1 400 mm - 1 940 mm
• Platform width 520 mm
• Distance between shears 700 mm
• Overall width 1 760 mm
• Lifting time 60 s
• Electrical power supply 400V/50 Hz
• Power 2,2 kW

Invento SL S30 is a subliminal lift designed for lifting vehicles weighing up to 3 tons to a height of 1 m. Ideally suited for tire and mechanical workshops facilitating the replacement of brake pads and discs.

Key information about the lift:

• Electromagnetic safety lock with automatic unlocking
• small dimensions of the device
• synchronized platform traffic
• adjustable platform length 1 400 mm - 1 940 mm
• mobile set for easy movement of the lift to another place
• Rubber pads included
• 10L hydraulic oil included!

The Invento SL S30 is equipped with the necessary safety features required by the CE documentation. This guarantees long and safe work in the workshop. The lifter is designed for installation in indoor, closed rooms without obstacles. Operating temperature in the range from -10°C to 40°C.

Preparation of the substrate:

The lift must be placed on a sufficiently durable concrete surface. The surface must be suitable for maintaining maximum pressure, even under adverse operating conditions. The surface must also be perfectly leveled.
