Akumuliatoriaus įkroviklis Power LAB LiFePO4 24V 50A

Trumpai apie prekę

Prekė: Akumuliatoriaus įkroviklis Power LAB LiFePO4 24V 50A. Kategorija: Baterijų įkrovikliai.

• Gamintojas: Power LAB
• Modelis: PL1500W

• Input voltage: 110-240V AC, 50/60Hz
• Output voltage: 24V DC (29,2V)
• Output current: 50A
• Battery type: LiFePO4
• Security:
• Before overheating
• Before short circuit
• Before reverse polarity
• Before surges

Important information

1. The charger is designed exclusively for charging LiFePO4 batteries with a rated voltage of 24V.
2. Before use, make sure the battery and charger are compatible.
3. Be careful when connecting and operating to avoid short circuit or damage to equipment.

Preparation for use

Battery check:

1. Make sure the battery is in good working condition.
2. Check the charge level and no mechanical damage

Location of the charger:

1. Set the charger on a flat, stable surface.
2. Avoid damp or dusty areas.
3. Ensure adequate airflow around the device.

Charging instructions

1. Connecting the charger:

• Connect the charger power cord to the electrical outlet (110-240V AC).

2. Connection to battery:

• Connect the red wire to the positive pole (+) of the battery.
• Connect the black wire to the negative pole (-) of the battery.
• Make sure the connections are stable and secure.

3. Start charging:

• Turn on the charger with the power button.
• The charger will automatically start the charging process and adjust the parameters to the LiFePO4 battery.

4. Process monitoring:

• The charger display will show information about voltage, current and charge level.
• If irregularities are detected, the charger will automatically interrupt the charging process.

5. Completion of charging:

• After the charging process is complete (100% on the display), turn off the charger.
• Disconnect the wires in reverse order: first black, then red.
• Disconnect the charger from the electrical outlet.

Specifications
