Suvirinimo aparatas MAGNUM MIG 208, 200A, 230V, MMA/TIG LIFT, FLUX, IGBT, aliuminis

Cena:
€448,78
Noliktava:
Ir noliktavā

Trumpai apie prekę

Prekė: Suvirinimo aparatas MAGNUM MIG 208, 200A, 230V, MMA/TIG LIFT, FLUX, IGBT, aliuminis. Kategorija: Pusiau automatiniai suvirinimo aparatai.

  • Gamintojas: Magnum
  • Modelis: MIG 208 MMA

Manufacturer: MAGNUM ║ Welding methods: MIG/MAG, FLUX, MMA, TIG LIFT ║ Power supply: 230V ║ Welding current: 200A

PROVEN AND TROUBLE-FREE MIGOMAT MIG/MAG WELDING MACHINE INVEST IN A WELDING MACHINE THAT GIVES YOU A GUARANTEE OF QUALITY AND LONG-TERM WORK!

  • Welding with current 200A in 60% duty cycle
  • Welding by MIG/MAG, FLUX, MMA, TIG Lift
  • IGBT inverter technology - minimum electromagnetic interference small power losses
  • For welding low carbon, low alloy, alloy and aluminium steels and alloys thereof
  • 2-roller feeder, supporting wire spool up to 5kg
  • Smooth regulation of welding parameters
  • Adjustable wire feed speed
  • Easy to use, easy to read control panel
  • Contact (Lift) glow arch in TIG method
  • Possibility of welding without cylinders - FLUX
  • For workshop, industrial, hobbistic, economic-home
  • Optimal weight and portability device
  • Hand for easy transport
  • Built-in protection against overheating
  • Efficient cooling with fan
  • Metal body to protect against mechanical damage

The MAGNUM MIG 208 MMA NV inverter welder is an easy-to-use migomat that allows smooth regulation of welding current. The device was built on the basis of the latest IGBT technologies, thanks to which we gained weight, dimensions and functionality. The device is very efficient and allows welding with a maximum current of 200A. This power source allows you to use the welding machine for any, even demanding work! The device has manual control with 3 dedicated knobs, each responsible for a different parameter: MMA welding current, MIG welding current and wire feeding speed. This solution provides great simplicity of settings and their adjustment during work. The device has a mechanism of change of polarity. It allows you to connect classic welding wires and welding with a wrapped electrode, turning a semi-automatic into an electrode welding machine MMA, but also allows for welding without gas with self-shielding wires (FCAW).

IGBT - the welding machine uses modern transistors, a solution that provides a minimum of electromagnetic interference small power losses in basic systems, enabling increased efficiency and reliability of the power source.

FLUX (FCAW) - arc welding with powder wire, not requiring the use of gas cylinders. We use self-shielding wire, which is filled with flux or a chemical that produces protective gases during welding.

TIG LIFT - possibility of TIG LIFT touch welding. Arch ignition is carried out by lightly rubbing the non-melting electrode against the welded material.

OVERLOAD SWITCH - built-in protection against overheating of the device, prolonging its service life.

POWER SUPPLY PARAMETERS

  • Power supply: 230V
  • Quantity phase: 1ph
  • Frequency: 50Hz
  • Power protection: 20A

TECHNICAL PARAMETERS

  • MIG/MAG welding current: 40 ÷ 200A
  • Welding current MMA/TIG Lift: 160A
  • Idle voltage: 60 V
  • Power consumption max: 5,7 kVA
  • Efficiency: 60% (for temp. 40°C)
  • Feeder: 2R
  • Spool diameters with wire: up to 200mm
  • Max. spool size: 5kg
  • Wire diameter: 0,6/0,8/0,9/1,0 mm

ADDITIONAL FUNCTIONS

  • Flux : Yes
  • IGBT: Yes
  • Protection against overheating: Yes

PHYSICAL PARAMETERS

  • Housing protection: IP21S
  • Cooling: fan
  • Weight: 10.3 kg

BY BUYING FROM US YOU WILL RECEIVE

  • Welding machine MAGNUM 208 MMA NV
  • Handle for welding by MIG/MAG Type MB15 - 3m
  • Electrode holder for MMA welding,
  • Bulk Holder
  • Operating instructions

Specifications

Group Name Value
Parametry Condition new
Parametry Invoice With VAT invoice
Parametry Brand Magnum
Parametry Power consumption 5.7 kVA
Parametry Supply voltage (V) 230
Parametry Duty cycle time 60%
Parametry Maximum electrode diameter 4 mm
Parametry Wire diameter (mm) 0,6-1,0
Parametry Device weight 16 kg
Parametry Welding range 30–200 A
Parametry Length of ground cable 300 cm
Parametry Welding cable length 200 cm
Parametry Product weight with unit packaging 20 kg
Parametry Manufacturer code MIG 208 MMA
Parametry EAN (GTIN) 5901217100451
Parametry Packaging status original
Parametry Welding methods MIG/MAG,MMA,TIG
Parametry Additional features infinitely adjustable welding current,EURO handle,LCD display
