Pramoninis USB hubas Waveshare, 3x USB 2.0, Ethernet RJ45

Trumpai apie prekę

Prekė: Pramoninis USB hubas Waveshare, 3x USB 2.0, Ethernet RJ45. Kategorija: USB šakotuvai.

• Gamintojas: WaveShare
• Modelis: 23079

The industrial USB HUB and external Ethernet network card model USB-HUB-3U-ETH (SKU: 23079) by Waveshare is an advanced expansion device designed for reliable and stable operation in demanding industrial, workshop and laboratory environments. The module allows you to simultaneously duplicate one USB-B input port to three independent USB 2.0 output ports and an integrated RJ45 Fast Ethernet network adapter. The implemented industrial-grade integrated circuits provide transparent data transmission with speeds up to 480 Mbps on a USB bus and adaptive 10/100 Mbps LAN communication. The device eliminates the problem of a limited number of interfaces in control computers, single board computers or industrial controllers, offering a stable platform for simultaneous support of multiple peripherals and network transmission.

The hub design has been optimized for maximum protection and safety of connected electronics, offering advanced ESD electrostatic protection for each USB port and TVS diodes for effective suppression of voltage spikes and surges. The device operates at a standard 5V input voltage supplied via a durable USB-B connector, and the output USB-A ports are able to deliver current with a maximum total intensity of up to 1.2A, which allows for trouble-free power supply to demanding modems, external drives or sensors. Robust metal housing with high mechanical resistance, equipped with dedicated handles, allows easy wall installation or on machine panels. The hub is characterized by an extremely wide operating temperature range from -40°C to 85°C, finding ideal use in production lines, embedded systems, building automation, measurement laboratories and external IoT installations.

Key specification

- Brand: Waveshare

- Model: USB-HUB-3U-ETH (SKU: 23079)

- Input interface: 1 x USB-B (5 V)

- Output interfaces: 3 x USB-A 2.0, 1 x RJ45 Ethernet

- USB bus speed: USB 2.0 up to 480 Mbps compliant

- Network card: 10/100 Mbps Fast Ethernet

- Output port current capacity: 5 V @ Imax up to 1.2 A total load

- Integrated security features and layouts:

= ESD electrostatic protection dedicated to each USB serial port

= TVS diode absorbing voltage spikes and power surges

- Durable metal housing with mounting holes

- Ambient operating temperature: -40°C to 85°C

- Supported operating systems: Windows 11 / 10 / 8.1 / 8 / 7 / XP, Linux (2.4.20+), Mac OS (8.6+)

- External dimensions: 86.20 × 65.00 × 23.30 mm

- Weight of the device: approx. 110 g

Most important features:

• Multifunctional industrial USB hub with built-in Ethernet interface.
• It allows you to simultaneously expand the number of USB ports and add a LAN network connection.
• Robust metal housing suitable for industrial applications.
• Built-in ESD and TVS protection for increased resistance to interference and surges.
• Wide operating temperature range from -40°C to 85°C.

USB HUB input:

• Operating voltage: 5 V.
• USB-B connector.
• USB 2.0 standard.
• Full backward compatibility with previous USB standards.

USB Outputs:

• 3 USB-A 2.0 ports.
• Maximum data transfer rate up to 480 Mbps.
• Maximum output current: 5V/1,2A total for all ports.
• Ability to connect multiple USB devices at the same time.

Ethernet port:

• RJ45 connector.
• Support 10/100 Mbps Ethernet network.
• Automatic adaptation of connection speed.
• Stable wired LAN communication.

Protection and safety:

• Independent ESD protection for each USB port.
• Integrated TVS surge protection diode.
• Increased resistance to interference in industrial environments.

Construction:

• Durable metal housing.
• Contoured mounting brackets for easy installation of the device.
• The structure is adapted to work in demanding industrial conditions.

Working conditions:

• Ambient temperature: -40°C to 85°C.

Supported operating systems:

• Windows 11.
• Windows 10.
• Windows 8.1.
• Windows 8.
• Windows 7.
• Windows XP.
• Linux 2.4.20 and above.
• macOS 8.6 and later.

Application:

• Industrial automation.
• Service and diagnostic stations.
• Industrial computers and embedded systems.
• Expansion of the number of USB ports in devices equipped with a single USB connector.
• Integration of USB devices with Ethernet network.
• Monitoring, control and data acquisition systems.

The set includes

- 1 x Industrial USB HUB 3x USB 2.0 + Ethernet RJ45 Waveshare

- 1 x Dedicated USB-B to USB-A connection cable

- 1 x Original packaging
