Pilno kadro fotoaparatas Panasonic DC-S5M2XE Lumix

Trumpai apie prekę

Prekė: Pilno kadro fotoaparatas Panasonic DC-S5M2XE Lumix. Kategorija: Beveidrodiniai fotoaparatai.

• Gamintojas: Panasonic
• Modelis: DC-S5M2XE
• Spalva: black
• Komplektacija: not specified

DC-S5M2XE

• New 24,2 MP converter with Dual Native ISO technology and next generation mechanism
• Phase detection autofocus and active image stabilization technology
• Unlimited recording in 10-bit C4K/4K 60p/50p 4:2:2
• Raw video data output, ProRes video, ALL-Intra video, recording to external USB-SSD

1. Phase Hybrid AF

Hybrid phase-detection AF significantly increases the effectiveness of tracking and recognition of photographed objects. O

2. Active IS technology

The LUMIX S5IIX works optimally as recording equipment when walking. Watch the video to see its possibilities!

3. Wide range of video expression options

The camera offers a full range of features to expand expression capabilities for creators, including unlimited recording in 10-bit 4:2:2 C4K/4K 60p/50p quality, high resolution 6K (5958x3968, 3:2) (5958x3136, 17:9) and more.

4. A new generation of imaging devices

The first LUMIX mirrorless camera, the LUMIX s5IIX, has a new mechanism with a 24,2 MP CMOS sensor and phase-detection autofocus.

5. Designed for strength

The camera is equipped with a universal and durable HDMI type A connector.

6. Higher degree of visual expression

Enjoy RAW video data output, ProRes recording, All-Intra video and external USB-SSD recording for professional video production.

7. Streaming options

Choose your favorite approach: wireless live streaming (RTMP/RTMPS), USB tethering (RTMP/RTMPS), or wired live streaming (RTP/RTSP).

LUMIX design philosophy: shaping emotions

The new all-black design of the LUMIX S5IIX is designed to encourage the developer to immerse themselves in capturing the object without paying attention to the tools they use. It is designed to harmonize with the environment in which photography takes place and prevent reflections on the aperture or recording medium, thus supporting artistic creativity.

Video data output in RAW format

The LUMIX S5IIX allows you to transfer RAW video data via HDMI to save it as ProRes RAW on ATOMOS NINJA V+, NINJA V and Shogun CONNECT HDR* monitors/recorders. Blackmagic RAW data can also be recorded on a 12G HDR Video Assist device**.

* [ProRes RAW] ･Information on the appropriate firmware version of ATOMOS Ninja V+, ATOMOS Ninja V or ATOMOS Shogun CONNECT can be found on the ATOMOS website. ･ Software that supports ProRes RAW format is required to edit RAW video recorded using ATOMOS Ninja V+, ATOMOS Ninja V or ATOMOS Shogun CONNECT. Apply the LUT (mapping table) available in the following customer support site to give the same color gradation as the V-Log/V-Gamut https://panasonic modes. jp/support/global/cs/dsc/download/lut/s1h_raw_lut/ ･Subject to the situation, some functions may not be available. ** [Blackmagic RAW] ･Visit the Blackmagic Design website for information about the corresponding version of the Blackmagic Video Assist 12G HDR firmware. ･DaVinci Resolve or DaVinci Resolve Studio is required to play and edit Blackmagic RAW data. DaVinci Resolve Studio is required to deliver projects that use Blackmagic RAW data with a resolution exceeding 3840x2160. ･Depending on the situation, some functions may not be available.

Record to an external USB-SSD

The LUMIX S5IIX allows you to record and play back using an external SSD via a USB connection. In addition, the ability to record content in ProRes 422 HQ format (up to 1,9 Gbps) and 10 bit 4:2:2 quality with compression directly on SSDs has contributed to improved portability and capacity, increasing the efficiency of backup and post-processing support.

Ability to start broadcasting anytime, anywhere

Choose your favorite streaming approach to share the latest events in real time! When used outdoors, wireless live streaming (RTMP/RTMPS) can be easily configured using the LUMIX Sync app. Wired live streaming (RTP/RTSP) with high stability is also available indoors.

Generally, it is possible to stream live to RTMP/RTMPS compliant platforms (compliance with all platforms is not guaranteed). In some cases, live streaming may not be possible as a result of changes to the service on the platform. More information can be found in the terms and conditions of the platform. ･Since the speed of live streaming depends on the internet connection, smartphone performance and other factors, it is worth conducting a transmission test in advance. To convert the USB Type-C terminal available on the DC-S5IIX into a LAN terminal, a commercially available USB Ethernet adapter is required.

Ready for the most ambitious photo shoots

The most important thing about autofocus is that it is reliable. The new phase hybrid AF provides speed and accuracy, helping you capture your target subject even in the most challenging scenes involving multiple people, as well as in environments with rear lighting or dimly lit.

The new Active I.S. system allows you to shoot and film while walking. The Active I.S. system determines the vibration status of the camera and optimizes correction factors, so it can compensate for even serious camera vibrations by about 200%* better than conventional systems.

* Compared to the LUMIX S5 model. 20 mm focal length when using the S-R2060 lens.

Heat management allows for unlimited recording time

Unlimited recording time* in 10-bit 4:2:2 C4K/4K 60p/50p quality. With the compact housing of the LUMIX S5IIX, comparable to the S5, the new optimized heat dissipation structure allows recording for extended periods of time, even materials that put a heavy strain on the camera (e.g. high definition video over 4K or HFR video).

* The camera may stop recording when used at a temperature lower or higher than the recommended operating temperature (0 to 40 degrees).

Recording stops when the continuous recording time exceeds 30 minutes with the following settings: [MOV] in [6K/29.97p] [6K/25.00p] [5.9K/29.97p] [5.9K/25.00p] or [ProRes] in [5.8K/29.97p] [5.8K/25.00p] [C4K/59.94p] [C4K/50.00p] when the heat management option is set to Standard.

LUMIX commitment to delivering the highest image quality

The new mechanism provides more realistic colors, better resolution and a natural three-dimensional effect, and in combination with Dual Native ISO technology, effective noise suppression even when recording material with high sensitivity, while maintaining fidelity to reproduction even in dark areas.

Easy color gradation with REAL TIME LUT

Photos and videos with the LUT table used can be recorded internally without special software. Even if you don’t have specialized editing skills, the camera will help you expand your expression range to the desired degree.

Lenses for high-quality photographic and video expression

The LUMIX S series delivers superior optical performance, mobility and handling without compromise. Even after changing the lens, all photos will have a consistent reproduction, resulting in high-quality artwork.

Models in the LUMIX S5 series

Now you can choose from the LUMIX S5IIX camera, which provides even better image quality, or the LUMIX S5II model, created for a wider range of photo and video creators.

Flow status — film recorded with LUMIX S5IIX

A content creation project that challenges three content creators to push the boundaries of creativity with the LUMIX S5IIX.

SPECIFICATION:

Type

• Type: Mirrorless digital camera
• Lens mount: L-Mount mount

Image transducer

• Type: Full-frame 35 mm CMOS sensor (35,6 mm x 23,8 mm)
• Effective number of pixels / Total number of pixels: 24,20 megapixels / 25,28 megapixels
• Anti-glare coating: Yes
• Proportions / Color filter: 3:2 / Basic color filter
• Dust reducing system: Type with matrix offset

Range

• Over 14-step characteristics (V-Log)

Photos

• File format: JPEG (DCF, Exif 2.31), RAW
• Aspect Ratio: 4:3 / 3:2 / 16:9 / 1:1 / 65:24 / 2:1

File size (in pixels) when using full-frame lenses

• 3:2: 6000x4000(L) / 4272x2848(M) / 3024x2016(S) / 12000x8000(XL)* / 8496x5664(LL)* *High resolution mode.
• 4:3: 5328x4000(L) / 3792x2848(M) / 2688x2016(S) / 10656x8000(XL)* / 7552x5664(LL)* *High resolution mode.
• 16:9: 6000x3368(L) / 4272x2400(M) / 3024x1704(S) / 12000x6736(XL)* / 8496x4784(LL)* *High resolution mode.
• 1:1: 4000x4000(L) / 2848x2848(M) / 2016x2016(S) / 8000x8000(XL)* / 5664x5664(LL)* *High resolution mode.
• 65:24: 6000x2208(L)
• 2:1: 6000x3000(L)

File size (in pixels) when using APS-C/Super 35 mm lenses

• 3:2: 3984x2656(L) / 2880x1920(M) / 2064x1376(S)
• 4:3: 3536x2656(L) / 2560x1920(M) / 1840x1376(S)
• 16:9: 3984x2240(L) / 2880x1624(M) / 1920x1080(S)
• 1:1: 2656x2656(L) / 1920x1920(M) / 1376x1376(S)
• Image quality: RAW / RAW+Fine / RAW+Standard / Fine / Standard (High Resolution mode: Combined / RAW / RAW+Fine / Fine)
• Color space: sRGB, AdobeRGB

Movies

• File format: MOV: H.264/MPEG-4 AVC, H.265/HEVC, Apple ProRes, MP4: H.264/MPEG-4 AVC, H.265/HEVC
• Audio format: MOV: LPCM (2 channels, 48 kHz/24 bits, 96 kHz/24 bits*) (4 channels, 48 kHz/24 bits**, 96 kHz/24 bits**), MP4: AAC (2 channels, 48 kHz/16 bits) * After connecting a Φ3,5 mm microphone or DMW-XLR1 adapter (sold separately). **After connecting the DMW-XLR1 adapter (sold separately).
• System frequency: 59,94 Hz / 50,00 Hz / 24,00 Hz
• Video area: Full / APS-C / PIXEL/PIXEL

Record to an external USB-SSD

• Yes (ON. /OFF )

HDMI RAW Data Output

Compatible external devices

• ATOMOS HDMI monitor/recorder "Ninja V+" /"Ninja V" / "Shogun CONNECT"
• *Visit the ATOMOS website for information about the appropriate firmware version of ATOMOS Ninja V+, ATOMOS Ninja V or ATOMOS Shogun CONNECT.
• *To edit RAW video recorded using ATOMOS Ninja V+ or ATOMOS Ninja V, software that supports ProRes RAW format is required. Apply the LUT (mapping table) available in the following customer support site to give the same color gradation as the V-Log/V-Gamut https://panasonic modes. jp/support/global/cs/dsc/download/lut/s1h_raw_lut/
• *Depending on the situation, some features may not be available.
• Blackmagic Video Assist 5" 12G HDR, Blackmagic Video Assist 7" 12G HDR
• *Visit the Blackmagic Design website for information about the corresponding version of Blackmagic Video Assist 12G HDR firmware.
• *DaVinci Resolve or DaVinci Resolve Studio is required to play and edit Blackmagic RAW data. DaVinci Resolve Studio is required to deliver projects that use Blackmagic RAW data with a resolution exceeding 3840x2160.
• *Depending on the situation, some features may not be available.

Recording quality / 59,94 Hz / FULL

• [5.9K] 5888x3312 (16:9): 29,97p, 12 bits (LPCM) 23,98p, 12 bits (LPCM)

Recording quality / 59,94 Hz / APS-C

• [4,1K] 4128x2176 (17:9): 59,94p, 12 bits (LPCM), 29,97p, 12 bits (LPCM), 23,98p, 12 bits (LPCM)
• [3,5K] 3536x2656 (4:3): 29,97p, 12 bits (LPCM), 23,98p, 12 bits (LPCM)

Recording quality / 50,00 Hz / FULL

• [5.9K] 5888x3312 (16:9): 25,00p, 12 bits (LPCM)

Recording quality / 50,00 Hz / APS-C

• [4,1K] 4128x2176 (17:9): 50,00p, 12 bits (LPCM), 25,00p, 12 bits (LPCM)
• [3,5K] 3536x2656 (4:3): 50,00p, 12 bits (LPCM), 25,00p, 12 bits (LPCM)

Audio format

• LPCM (2 channels, 48 kHz/24 bits, 96 kHz/24 bits*) (4 channels, 48 kHz/24 bits**, 96 kHz/24 bits**)
• *After connecting the microphone Φ3,5 mm or DMW-XLR1 (sold separately). **After connecting the DMW-XLR1 adapter (sold separately).

Viewfinder

• Type: OLED Live View Finder
• Pixels: About 3,68 million points
• Field of view / Magnification: About 100% / About 0,78x with 50mm lens set to infinity; -1,0m-1 when aspect ratio is set to 3:2
• Viewing distance / Diopter adjustment: About 21 mm when set to infinity; -1,0 m-1 / -4,0 - +2,0 (dpt)
• Eye sensor: Yes
• Display speed: 120 fps. /s / 60 kl. /s

Rear display

• Type: TFT LCD display with static touch panel
• Monitor size: About freely adjustable angle, 7,6cm (3 inches), 3:2 aspect ratio
• Pixels: About 1,84 million points
• Field of view: About 100%

Status LCD Display

• -

Focus adjustment (*³)

• Type: Phase Detection Autofocus System / Contrast Detection Autofocus System
• DFD technology: Yes
• Focus mode: AFS (single) / AFC (continuous) / MF
• AF Mode: Tracking / Full AF Area / Zone (Vertical/Horizontal) / Zone / 1-Area+ / 1-Area / Pinpoint * Automatic detection can be enabled to switch between Human / Face / Eyes / Animal+Man modes. Except for Pinpoint enabled.
• AF detection range: EV -6 - 18 (F1,4, equivalent to ISO100, AFS)
• Custom AF setting: AF sensitivity, AF area switching sensitivity, object forecasting in motion
• AF Assist Lamp: Yes
• AF lock: Set the Fn button in the custom menu to AF lock
• Focus ring control: Non-linear / Linear (90°/ 120°/ 150°/ 180°/ 210°/ 240°/ 270°/ 300°/ 330°/ 360°/ 720°/ 1080°/ Maximum)
• Other: AF-ON, AF-ON: Close, AF-ON: Do dali,Focus Limiter, Focus Peaking, 1-area AF swipe speed,Micro, continuous AF (when recording videos), focus/snapshot priority,vertical/horizontal focus switching, AF/AE lock holding,AF+MF, MF Assist, MF Guide, focus ring lock,display/hide AF mode, AF shutter, release shutter when the button is pressed halfway,fast AF, AF with eye proximity detection, loop focus frame,enlarged live display (video), touch shutter,Touch AF/AE function, AF touch panel, lens focus recovery

Exposure control

• Light measurement system: 1 728-zone multi-point detection system
• Light measurement mode: Multiple / Centrally weighted / Point / Highlighted weighted
• Measurement range: EV 0-18 (F2,0 lens, equivalent to ISO100)
• Mode knob: AE program (P) / AE aperture priority (A) / AE shutter priority (S) Manual exposure (M) / Creative Video (P/A/S/M)* / Custom 1, 2, 3, 4 / intelligent automatic * The same exposure operations are available as in P/A/S/M mode.
• Exposure compensation: 1/3 EV step ±5EV (±3EV for movies)

ISO sensitivity (standard output sensitivity)

• [Normal] Auto / 50* / 100-51200 / 102400* / 204800* (step 1/3 or 1 EV) * Extended ISO
• [V-Log] Auto / 320* / 640-51200 (step 1/3 or 1 EV) * Extended ISO
• [HLG] Auto / 400-51200 / 102400* / 204800* (step 1/3 or 1 EV) * Extended ISO

Dual native ISO

• [Normal]: Native ISO: 100, 640, Auto: Auto / 50* / 100-51200 / 102400* / 204800* *Extended ISO, Low: Auto /50* / 100-800 *Extended ISO, High: Auto / 320* / 640-51200 / 102400* / 204800* *Extended ISO
• [V-Log]: Native ISO: 640, 4000, Auto: Auto /320* / 640–51200 * Extended ISO, Low: Auto /320* / 640-5000 * Extended ISO, High: Auto /2000* / 4000–51200 * Extended ISO
• [HLG]: Native ISO: 400, 2500, Auto: Auto / 400–51200 / 102400* / 204800* *Extended ISO, Low: Auto / 400–3200, High: Auto / 2500–51200 / 102400* / 204800* * Extended ISO
• [Cinelike D2 / Cinelike V2]: Native ISO: 200, 1250, Auto: Auto / 100* / 200–51200 / 102400* / 204800* * Extended ISO, Low: Auto /100* / 200-1600 * Extended ISO, High : Auto / 640* / 1250–51200 / 102400* / 204800* * Extended ISO
• AE lock: Set the Fn button in the custom menu to AE lock

Image stabilization system

• B.I.S. (5 axes / 5 points*) * According to the CIPA standard [direction of deviation: focusing distance f=60 mm when using the S-R2060 lens].
• Dual I.S. 2 (6,5 points*) * According to CIPA standard [direction of deviation: focusing distance f=200 mm when using S-E70200 lens].

White balance

• White balance: AWB / AWBc / AWBw / daylight / cloudy / shadow / bulb / flash / white setting 1, 2, 3, 4 / color temperature setting 1, 2, 3, 4
• White balance adjustment: blue/amber staining, magenta/green staining
• Color temperature setting: 2500 – 10000 K in 100 K

Snapshot

• Type: Slot shutter
• Shutter speed: Photos: Bulb (max. 30 minutes), 1/8 000 – 60, Electronic front curtain: Bulb (max. 30 minutes), 1/2 000 – 60, Electronic aperture: Bulb (max. 60 s), 1/8000–60, Videos: 1/16 000–1/25, Creative Video Mode M / MF Mode: 1/16 000–1/2
• Self-timer: 10 s, 3 images / 2 s / 10 s / custom time
• Remote control: Remote control via DMW-RS2 (sold separately)
• Silent mode / Shutter mode: Yes / Yes (Automatic / Mechanical / Electronic front curtain / Electronic / Electronic+NR)

BRACKETING

• AE range: 3, 5, 7 photos with step 1/3, 2/3 or 1 EV, max. ±3 EV, single/serial
• Bracketing aperture: 3, 5 or all positions
• Focus bracketing: 1–999 photos, focus steps can be set in 10 levels
• White balance range: Three images in blue/amber axis or magenta/green axis, color temperature setting

Taking serial photos

• Speed of continuous shooting
• Mechanical / electronic front curtain aperture: H: 9 kl. /s (AFS/MF), 7 frames /s (AFC) (with Live View), M: 5 fps. /s (AFS/MF) (with Live View), 5 fps. /s (AFC) (with Live View), L: 2 fps. /s (AFS/AFC/MF) (with Live View)
• Electronic aperture: SH30: 30 fps. /s (AFS/AFC/MF), H: 9 fps. /s (AFS/MF), 8 frames /s (AFC) (with Live View), M: 5 fps. /s (AFS/MF) (with Live View), 5 fps. /s (AFC) (with Live View), L: 2 fps. /s (AFS/AFC/MF) (with Live View)

Number of images recorded

• H/M/L*
• RAW+JPEG: more than 200 photos
• RAW: more than 200 photos
• JPEG: more than 300 photos
• * Until the speed of continuous shooting drops. When registering under the test conditions specified by Panasonic.
• * When using an SD card with speed class "UHS-II Speed Class 3 (U3)".
• SH
• RAW / RAW+JPEG / JPEG: 200 photos

Flash

• Type of flash: External TTL flash (sold separately)
• Sync speed: Under 1/250 s * The guide number decreases at 1/250 s. Only after setting the M or S mode.
• Flash mode: Auto* / Auto/Reduction of red eyes* / On. extortion / On. forcing/Reduce red eyes / Slow synchronization / Slow synchronization/Reduce red eyes / Off. extortion * Only in iA mode.
• Sync flash: Sync on 1. Curtain, synchronization on 2. curtain
• Adjustable flash power: 1/3 EV with step ±3 EV
• Wireless control: Yes (when using DMW-FL200L / FL360L / FL580L lamp (optional)), wireless channel: 1 can./2 can./3 can./4 can.

Virtual zoom range enhancement

• 2,0x (EX S) (when using full-frame lenses), 1,9x (EX S) (when using APS-C / Super 35 mm lenses), 1,4x (EX M) * Only when recording photos.

Movie recording function

• Time-lapse photography: Yes
• Time-lapse animation: Yes
• Live cropping: Yes (support clipping from 5,9K video (FULL) 30p/25p/24p to 4K/FHD size)
• SS/amplification mode: Snapshot/ISO / Angle/ISO / Shutter/dB
• Luminance level: 8 bits: 0-255 / 16-235 / 16-255, 10 bits: 0-1023 / 64-940 / 64-1023
• Sync scanning function: Yes
• Master Pedestal function level: 31 degrees
• Color bars / 1 kHz test area: Yes (SMPTE / EBU / ARIB) / Yes
• LUT preview: Supported file types: . vlt, . cube, Display / HDMI
• HLG preview: Display (MODE1/MODE2/OFF. ) / HDMI (AUTO / MODE1 / MODE2 / OFF. )
• Anamorphic view with Desqueeze function: 2,0x / 1,8x / 1,5x / 1,33x / 1,30x / OFF
• Way Monitor / Vector Range: Selectable
• Knee Control: Tak (in Like709 mode)
• Red recording frame indicator: On. / off.

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	Panasonic
Parametry	Model	DC-S5M2XE
Parametry	Resolution	25.28 Mpx
Parametry	Included	not specified
Parametry	Sensor type	CMOS
Parametry	Sensor size	full frame
Parametry	Color	black
Parametry	Stabilization	digital
Parametry	Supported memory cards	SDXC
Parametry	Communications	Bluetooth
Parametry	EAN (GTIN)	5025232951840
Parametry	Manufacturer code	DC-S5M2XE
Parametry	Batteries included	no
