Kompiuterinė plokštė Raspberry Pi CM4, 4GB RAM, 8GB eMMC

Trumpai apie prekę

Prekė: Kompiuterinė plokštė Raspberry Pi CM4, 4GB RAM, 8GB eMMC. Kategorija: Priedai.

• Gamintojas: Raspberry pi
• Modelis: CM4104008

Raspberry Pi CM4 Compute Module 4 (4GB RAM + 8GB eMMC + WiFi/Bluetooth):

• Module type: CM4
• RAM: 4 GB
• Wifi / Bluetooth module: Yes
• eMMC memory: 8 GB

Raspberry Pi Compute Module 4 (CM4104008) - has the capabilities of a classic microcomputer Raspberry Pi. The interfaces are output to two multi-pin connectors compatible with CM4IO Board sockets.

Raspberry Pi Compute Module 4 - is a microcomputer equipped with a quad-core Broadcom BCM2711 processor, Cortex-A72 core (the same as in Raspberry Pi 4), which operates at a frequency of 1,5 GHz and Broadcom VideoCore VI graphics chip. In the CM4 microcomputer, RAM can range from 1 GB to 8 GB. Depending on the version, the module can be equipped with eMMC memory with a capacity from 8 GB to 32 GB and can have a built-in WiFi network card (IEEE 802.11b/g/n/ac 2,4/5 GHz) and Bluetooth 5.0/BLE module. Compute CM4 modules are mainly designed for industrial applications and are not equipped with USB, HDMI, etc. connectors.

This auction offers a CM4 module with memory: RAM: 4 GB; eMMC memory: 8GB, equipped with Wifi and Bluetooth.

Raspberry Pi Compute Module CM4 microcomputer specification:

• Processor: Broadcom BCM2711 quad-core SoC @ 1.5 GHz; core: Cortex-A72 (ARM v8) 64-bit
• RAM: 4 GB LPDDR4
• eMMC memory: 8 GB
• Wireless Connectivity: WiFi 2.4 GHz and 5.0 GHz 802.11b/g/n/ac and Bluetooth 5.0, BLE
• Built-in antenna on PCB (possibility of connecting an external antenna)
• Gigabit Ethernet PHY compliant with IEEE1588
• Connector on board: 2 x 104 pin
• Interfaces: 1 × USB 2.0 interface, PCIe Gen 2 x1 interface, 28 GPIO ports
• Video interfaces: Dual HDMI (up to 4Kp60); 2-lane MIPI DSI - display interface; 2-lane MIPI CSI - camera interface; 4-lane MIPI DSI - display interface; 4-lane MIPI CSI - camera interface
• Support for codecs: H.265 (4Kp60 decoding) and H.264 (1080p60 decoding, 1080p30 encoding)
• Supply Voltage: 5V DC
• Operating temperature: 0 to +80°C
• Dimensions: 55 × 40 mm

To take full advantage of the capabilities and interfaces of the CM4 board, you need to purchase an additional extension module (Compute Module 4 IO Board) - it allows you to output its interfaces m.in. for GPIO pins, USB, etc. (This module is not the subject of the offer).
