Hidraulinis-pneumatinis keltuvas 30/15T WRC

Trumpai apie prekę

Prekė: Hidraulinis-pneumatinis keltuvas 30/15T WRC. Kategorija: Pneumatiniai keltuvai.

• Gamintojas: WRC
• Modelis: 18-05-1290

HYDRAULIC-PNEUMATIC LIFT 30/15T WRC

Professional pneumatic and hydraulic lifter WRC with a lifting capacity of 30/15 tons is a reliable tool designed for work in car workshops, mobile services and in the operation of heavy vehicles. With its robust design and high performance, it enables fast, safe and comfortable lifting of vehicles even in difficult service conditions.

The lift belongs to the group of point lifters, whose task is to lift the vehicle in a vertical axis. The compressed air supply sets in motion the hydraulic pump, which produces the appropriate pressure in the hydraulic cylinder. As a result, the telescopic actuator extends, lifting the vehicle, and after the pressure drops, its controlled lowering occurs.

The most important advantages

• Large lifting capacity – up to 30/15 tons

  Ideal for handling trucks, buses and agricultural machinery.

• Pneumatic and hydraulic drive

  Provides fast and efficient lifting with minimal operator effort.

• Mobility and convenience

  Equipped with wheels, which allow easy movement of the lift in the workshop.

• Adjustable handle in 3 positions

  Allows you to adjust the setting for comfortable work in different conditions.

• Additional lifting tips

  The set includes two tips to increase the lifting height, which allows you to better fit the device to different vehicles.

• Oiling system

  Reduces friction between working elements, reduces wear on parts and protects them from corrosion.

Application

The WRC pneumatic and hydraulic lift is perfect for handling:

• heavy goods vehicles
• buses
• agricultural machinery
• specialised and military vehicles
• construction equipment

Thanks to the longer lift design, it is also possible to work comfortably in vehicles with difficult access to support points.

Technical data

• Leverage: 15 / 30 T
• Minimum height: 195 mm
• Maximum height: 420 mm
• Recommended hydraulic oil: L-HL 46
• Working pressure: 6 – 12 bar
