Diagnostikos įrenginys THINKTOOL MAX / PAD III PassThru, ONLINE funkcijos PL

Trumpai apie prekę

Prekė: Diagnostikos įrenginys THINKTOOL MAX / PAD III PassThru, ONLINE funkcijos PL. Kategorija: Diagnostiniai testeriai ir sąsajos.

• Gamintojas: Thinkcar
• Modelis: THINKCAR THINKTOOL MAX

Version of the device intended for the European market.

When you buy from an authorized in Poland you are guaranteed a certain purchase.

You buy equipment from an authorized distribution of the THINKCAR on Polish territory.

The device has support for the Polish language, most of the devices have translated Polish. If no translation required Internet access for online translation.

THINKTOOL MAX 13 in.

Diagnostic tester device.

This is the latest tester, the diagnostic device has been equipped with an advanced diagnostic system.

It has a comprehensive system covering more than 120 makes and models worldwide, both in 12V and 24V cars, small commercial vehicles and hybrid vehicles. Professional device for full diagnostics, execution tests, can encode control units, has 28 service functions and supports TPMS service, module replacement, modification, personalization, anti-theft adaptation and key programming.

This intelligent diagnostic system has been developed specifically for medium or large car workshops.

THINKTOOL MAX

Supports the latest DoIP and CAN FD protocols and J2534(Pass Thru), D-PDU and RP1210 protocols.

And other protocols that are required for diagnostics ISO-14229 UDS, SAE-J2411 Single Wire Can (GMLAN), ISO-11898-2, ISO-11898-3, SAE-J2819 (TP2.0), ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART with clock, BMW DS2, BMW DS1, kwp128, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2).

The device has FCA group authorization access to the SGW gate

(additional fee option)

Wi-Fi connections to two areas.

The tablet communicates with the Smartlink diagnostic box via Wi-Fi or bluetooth, so that the operator can quickly carry out the diagnosis, check error codes and use other special service functions.

Online programming for Audi, BMW, LANDROVER, Mercedes-Benz, Nissan, Porsche, Seat, Skoda, Subaru, VW.

It has functions for vehicles from the V.A.G. group.

Wi-Fi connections to two areas. The tablet communicates with the diagnostic box over Wi-Fi, so technicians can quickly diagnose, check error codes and use other features.

An example screenshot of the online programming function.

THINKTOOL MAX

Additional modules are included in the factory set;

- oscilloscope

- endoscopic camera

-Think TPMS G1

-Battery battery tester

35 service functions:

• Adaptation of the fuel-air mixture
• Brake Reset
• Oil service and control
• Turn angle sensor
• Battery replacement
• Brake venting
• Throttling valve
• Tyre pressure monitoring system
• Particulate filter
• Reset AD Blue
• Adaptive traffic light system
• Airbag
• Ventilation cooling system
• Exhaust gas recirculation
• Crankshaft sensor
• Transmission adaptation
• Immobiliser
• Coding of injectors
• Language setting
• Adaptive NOX sensor
• Kilometre counter
• Sunroof
• Calibration of suspension
• Electronic seat adjustment
• Deactivation start/stop
• Changing the circumference of the wheel
• Activation of the means of transport
• Initialization of the window regulator
• engine angle calibration
• intelligent cruise control system
• diagnostics of the high voltage system
• engine balance calibration
• installation and calibration of the air conditioning system
• TPMS database

Screenshot of service functions.

Below are some screenshots of the functions of the device and the capabilities of the presented device.

Standard equipment THINKTOOL MAX 13 inch diagnostic tablet in armored housing EU charger adapter connector set

--- SmartLInk--- PassThru online coding programming

--- Endoscopic camera

--- 4 channel oscilloscope

--- AGM Battery Tester, GEL,EFB,SPIRAL TRADITIONAL

--- THINKTPMS G1 TPMS sensor programmer teaches, activates, programs.

Supported languages:

English, French, German, Italian, Spanish, Portuguese, Russian, Turkish, Dutch, Hungarian and Polish.

Update:

2 years free software update from the date of activation

Technical data:

• Operating System: Android 10
• Processor: 8-core 2,0 GHz processor
• Storage: 8 GB RAM
• Hard Drive: 256 GB built-in memory
• Display: touch screen 13,3″, 1280 × 800
• Camera: rear: 13,0 megapixels
• Battery: 9300 mAH / 7,6 V
• Network: Wi-Fi, WLAN 802.11 b/g/n
• Bluetooth: Bluetooth 5.0

The contents of the set;

1 x THINKTOOL MAX

1 x Adapter Connector Cable Set

1 x SmartLink C

1 x USB Cable with Charger

1 x Suitcase

1 x Activation Code Card

1 x Oscilloscope

1 x Endoscopic Camera

1 x Battery Tester

1 x Think TPMS G1

You buy equipment from an authorized distribution of the THINKCAR on Polish territory.

Thank you for your interest in our offer.
