USB šakotuvas Unitek, 5 Gbps, Cat 6, 100 m, 5x USB-C, 4x USB-A

Trumpai apie prekę

Prekė: USB šakotuvas Unitek, 5 Gbps, Cat 6, 100 m, 5x USB-C, 4x USB-A. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: Unitek
• Modelis: U1337BBK01-EU

Unitek U1337B – extension cable USB 3.0 5Gb/s to 100 m after twisted pair

Unitek U1337B is an advanced USB over Ethernet extension cable, designed for tasks where stability, large range and trouble-free operation with demanding devices count. If you want to move USB equipment away from your computer even at 100 meters, without losing its smoothness, this solution has been designed precisely for such applications.

Large range and fast transmission without compromise

With USB 3.0 technology and up to 5Gb/s bandwidth, you can use devices that need a robust and predictable connection. It's the perfect choice for camera, SSD, measuring equipment, test benches and AV installations where a regular USB cable simply isn't enough.

• up to 100 m transmission via CAT6A U/FTP cable
• USB 3.0 at speeds up to 5Gb/s
• stable signal even in complex installations
• practical solution for offices, laboratories, server rooms and production halls

7 USB ports and flexible architecture for expansion

This model has been prepared to facilitate work with multiple devices at the same time. The design based on the Host and Device modules gives great freedom of configuration, and the available ports allow you to conveniently connect various accessories without the need for additional splitters.

• 2 × USB-A 5Gb/s + 1 × USB-C 5Gb/s on the Host side
• 2 × USB-A 5Gb/s + 2 × USB-C 5Gb/s on the Device side
• additional RJ45 connectors
• USB-C Service port for configuration and maintenance

This is a great solution where one station must support several devices at once, and the wiring is to be readable and ordered.

FSYNC, UART and RS232 – full control in professional applications

Unitek U1337B stands out for its support for FSYNC, UART and RS232, which opens the way to work in more advanced environments. This is especially important for PTZ cameras, vision systems and automation, where not only data transfer, but also precise synchronization and remote control count.

In practice, this means fewer cables, simpler installation and more control over the entire system. Instead of building a complicated installation, you can base it on a single, well-designed connection that combines USB transmission with control signals.

Solid housing and reliability in continuous operation

The metal housing made of aluminum alloy not only looks good, but above all supports heat dissipation and increases the resistance of the entire structure to intensive use. This is important wherever the device is supposed to work 24/7 and must maintain full stability for a long time.

Black, professional design makes the equipment easily integrated into modern workstations, installation cabinets and AV systems.

Applications that really make a difference

This USB 100 m extension cable will work where convenience and no restrictions resulting from the length of traditional cables are important. This equipment is designed for specific, demanding scenarios.

• conference rooms and presentation systems
• recording studio and production positions
• server rooms and IT facilities
• automation and industrial installations
• monitoring, PTZ cameras and vision systems
• laboratories and test benches

If you need a reliable connection over a longer distance, Unitek U1337B gives you the freedom that is lacking in classic USB solutions.

Technical parameters

• Model: Unitek U1337B
• Device type: USB 3.0 over Ethernet extension cable
• Transmission speed: to 5Gb/s
• Maximum distance: to 100 m
• Recommended cable: CAT6A U/FTP
• Upstream – Host: 1 × USB-C, 1 × FSYNC
• Downstream – Host: 2 × USB-A 5Gb/s, 1 × USB-C 5Gb/s, 1 × RJ45
• Downstream – Device: 2 × USB-A 5Gb/s, 2 × USB-C 5Gb/s, 1 × RJ45, 1 × USB-C Service, 1 × FSYNC
• Supported protocols: FSYNC, UART, RS232
• Compatibility: Windows, macOS, Linux
• Power Supply: 12V/2A
• Housing material: aluminum alloy
• Color: black
• Dimensions: 106 × 118 × 24 mm
• Contents of the set: Host module, Device module, 2 × 12V/2A power supply, USB-C to USB-C 1 m cable, USB-A to USB-C 1 m cable, manual
