Tinklo jungiklis MikroTik CRS328-4C-20S-4S+RM

Trumpai apie prekę

Prekė: Tinklo jungiklis MikroTik CRS328-4C-20S-4S+RM. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: MikroTik
• Modelis: CRS328-4C-20S-4S+RM

MikroTik CRS328-4C-20S-4S+RM is a managed network switch equipped with 20 SFP ports for fiber optic connections, 4 SFP+ ports supporting transmission up to 10 Gbps and 4 combo ports that can work as Gigabit Ethernet (RJ45) or SFP. This configuration provides great flexibility in network infrastructure design. The switch is based on a 800 MHz processor and has 512 MB of RAM, which allows stable and efficient operation even under heavy loads. The 1U enclosure allows for mounting in a 19” rack cabinet. For increased reliability, the device is equipped with dual power supplies (Dual Power Supply). The model supports dual operating system (Dual Boot) – the user can choose between RouterOS (Level 5 license) and SwitchOS, depending on the needs and how the network is managed.

Specification:

• Product code: CRS328-4C-20S-4S+RM
• Architecture: ARM 32-bit
• Processor: 98DX3236
• Number of CPU Cores: 2
• Processor Clock: 800 MHz
• Switch layout model: 98DX3236
• Dimensions: 443 × 194 × 44 mm
• RouterOS License: Level 5
• Operating System: RouterOS / SwitchOS (Dual Boot)
• RAM: 512 MB
• Storage: 16 MB
• Storage Type: FLASH
• Average uptime (MTBF): approximately 200 000 hours at 25°C
• Operating temperature range tested: -20°C to 60°C
• Number of AC Power Inputs: 2
• AC input voltage range: 100 – 240 V
• Number of Power Supply Sockets: 2
• Power Frequency: 50 to 60 Hz
• Maximum power consumption: 43 W
• Cooling Type: 2 Fans
• Number of Ethernet Combo Ports: 4
• Number of SFP ports: 20
• Number of SFP+ ports: 4
• Serial Console Port: RJ45
• CPU Temperature Monitor: Yes
• Voltage monitor: yes
• Mode button (Mode button): yes
• Certificates and Compliance: CE, EAC, RoHS
