SSD diskas KIOXIA EXCERIA PRO G2 NVMe M.2 1TB PCIe Gen5 x4

Trumpai apie prekę

Prekė: SSD diskas KIOXIA EXCERIA PRO G2 NVMe M.2 1TB PCIe Gen5 x4. Kategorija: SSD diskai.

• Gamintojas: Kioxia
• Modelis: KIOXIA EXCERIA PRO G2

EXCERIA PRO G2 NVMe™ SSD

SSD KIOXIA EXCERIA PRO G2 NVMe M.2 1TB PCIe Gen5 x4

Do you need more speed? Meet the EXCERIA PRO G2 SSD Series, the fastest KIOXIA SSD. Using tomorrow’s interface technology, the PCI Express® 5.0 series delivers energy-efficient performance for demanding games and creative environments.

THE MOST IMPORTANT PARAMETERS

• Capacity: 1TB
• BiCS FLASH™
• Enc 2.0d NVMe technology
• M.2 2280 Form Factor
• PCIe® Gen5 x4
• SSD Utility management software

Unleash the AI

The EXCERIA PRO G2 SSD series, compliant with PCI Express® 5.0, delivers the performance required by today’s creative environments. Offering up to 14.400 MB/s sequential read speeds*¹ and up to 12.700 MB/s sequential write speeds*¹, this series takes AI applications, CG production and high-performance gaming to the next level.

Energy Efficiency

The EXCERIA PRO G2 series delivers higher performance without excessive power consumption or cooling requirements. It generates less heat and uses less energy. At maximum read speeds, it offers up to 110% more energy efficiency compared to the previous generation. *

* These values represent the read speed relative to energy consumption obtained in the Kioxia Corporation test environment. Energy efficiency means a useful result measured in tasks per watt.

Beat the Heat

EXCERIA PRO G2 SSDs feature innovative labels for improved heat dissipation for stability during load. Don't let excessive heat ruin your experience.

State-of-the-art 3D flash memory

The use of BiCS FLASH™ memory in EXCERIA SSDs and the technology of vertical memory cell structure allows to achieve the highest performance.

SSD Utility management software

The task of SSD Utility management software is to ensure optimal operation of the drive. It enables maintenance, monitoring, performing improvements on SSDs and much more!

We strongly recommend installing it and upgrading to the latest version to increase disk performance and check the remaining percentage of device life on the status indicator.

SPECIFICATION

Capacity/dimensions

• Capacity: 1 024GB
• Connector: 1 024GB: M.2 Type 2280-S3-M
• Interface: PCI Express® Basic Specification Version 5.0 (PCIe®)
• Flash memory type: BiCS FLASH™ TLC
• Maximum interface speed: 128 GT/s (PCIe® Gen5x4)
• Dimensions (max.: L x sz. x H ): 1 024GB: 80,15 x 22,15 x 2,38 mm
• Interface Protocol: NVM Express™ Base Specification 2.0d
• Weight: 7,3 g (Typ. )

Performance

• Max. Sequential read speed*: 1 024GB: 14 400 MB/s
• Max. Sequential write speed*: 1 024GB: 12 700 MB/s
• Max. Random read speed*: 1 024GB: 2 000 000 IOPS
• Max. Random write speed*: 1 024GB: 1 900 000 IOPS
• Lifespan: TBW*: 1 024GB: 600 TB
• MTTF: 1,5 million hours

Working environment / protection efficiency

• Operating temperature: from 0 ℃ (temp. environment) up to 0 ℃ (temp. housings)
• Storage temperature: -40 ℃ to 85 ℃
• Certificates: RoHS*5 compliant
• Shock resistance: 9,806 km/s2 {1 000 G} half-period of sine wave 0,5 ms
• Vibration: 25.4mm peak-to-peak (10Hz to 20Hz), 20G peak (20Hz to 2000Hz), (20min/Axis) x 3 Axis
• Supply voltage: 3,3 V ±5 %
• Power consumption: PS3: 50 mW (type. ), PS4: 5 mW (Typ. )
• Power consumption (active): 1 024GB: 9,6W (Typ. )

Compliance

• Connector Type: M.2 M key Socket
• Application: Desktops and client laptops

Other

• Performance Optimization: TRIM, Idle Time Garbage Collection
