PoE komutatorius TBC-PS4310N, 10 prievadų, 100 Mbps

Trumpai apie prekę

Prekė: PoE komutatorius TBC-PS4310N, 10 prievadų, 100 Mbps. Kategorija: Jungikliai ir koncentratoriai.

• Gamintojas: no brand
• Modelis: 4016406826935

Basic Product Positioning

This device is a 10-port 100Mbps unmanaged POE switch, model TBC-PS4310N, with a total POE power of 120W. It offers plug-and-play, long-distance transmission and stable silence. It is designed to monitor projects, homes and small offices, while also being able to power IP cameras, wireless access points and VoIP+ phone cables simultaneously transfer data.

Hardware ports and core power supply configuration

1. Port layout: a total of 10 RJ45 network ports with a speed of 100Mbps; the first 8 ports are POE power ports, and the last 2 are independent uplink ports; The device is equipped with an Extend switch for switching transmission distance modes.

2. POE power supply specifications: maximum power of 30W single POE port, full load 120W, compatibility with national POE receiving equipment standards, simultaneous power transmission and data transmission over network cable.

3. Network Standards: Meets IEEE802.3 10M and IEEE802.3u 100M 100M Ethernet standards; ports support 10/100Mbps adaptive and AutoMDI/MDIX automatic line switching.

Product structure and appearance advantages

1. Fanless and quiet design: low power consumption chip, the whole machine operates without fan, no noise, suitable for long-term use in bedrooms, offices and home low voltage cans.

2. Integrated steel alloy body: Electrostatically painted metal housing, densely filled with heat dissipation holes on both sides of the body, based on natural cooling convection, ensuring stable performance without overheating during long-term operation under full load.

3. Compact and compact housing: lightweight and does not take up space in a low current box, suitable for mounting on desks and walls.

Three main transmission modes (switching knob)

1. Standard mode: transmission distance of 100 meters, full speed 10/100Mbps, preferred choice for short range cameras in ordinary rooms;

2. Port isolation mode: maximum transmission distance of 250 meters, speed reduced to 10Mbps, 8 POE ports isolated from each other, connected only to upstream ports to prevent broadcast storms;

3. Link extension mode: also long distance transmission at 10Mbps by 250 meters, suitable for long-range IPC cabling in factory and outdoor areas.

Relevant scenarios and support services

1. Common use scenarios

- Security monitoring: centralized power supply and IP camera network for parks, shops and homes;

- Office network: Enterprise wireless access point, VoIP IP;

- Low voltage systems for small projects, dorms and workshops.

2. Support Services: The brand offers free network solution design and a technical team to provide engineering support.

Summary of the most important products

1. Ready to use without configuration: Unmanaged switch, without debugging, can work as soon as turned on, with low learning curve;

2. Stable high power supply: The whole device has 120W power, with 8 ports fully equipped with POE devices, each port up to 30W, meeting the needs of high definition camera power supply;

3. Ultra-far transmission: With one click, DIP enables transmission on a 250-meter long-line, eliminating the need for repeaters and reducing wiring costs;

4. Stable operation in all weather conditions: wide temperature operation, lightning protection at ports, metal cooling and quiet body, suitable for long-term stable operation both indoors and outdoors;

5. Multi-Survey Compatibility: Suitable for homes, offices, and security projects, with flexible desk and wall mounting options.
